      Bently Nevada 330851-02-000-070-90-00-05
      Bently Nevada 330851-02-000-070-90-00-05
      Bently Nevada 330851-02-000-070-90-00-05
      Bently Nevada 330851-02-000-070-90-00-05
      Bently Nevada 330851-02-000-070-90-00-05
      Bently Nevada 330851-02-000-070-90-00-05
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330851-02-000-070-90-00-05

      25 mm Proximity Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330851-02-000-070-90-00-05 is a 3300 XL 25 mm proximity probe for a matched differential-expansion transducer system. Its metric threaded case, FluidLoc cable and high-temperature ClickLoc connector support steam-turbine installations.

      Ask our team:

      Get a quick price for： 330851-02-000-070-90-00-05
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330851-02-000-070-90-00-05

      Technical specifications for 330851-02-000-070-90-00-05

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330851-02-000-070-90-00-05
      • Estimated shipping dimensions:
        119x4x4.6cm
      • Weight:
        0.36 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Component:
        3300 XL 25 mm Proximity Probe
      • Case Style:
        Metric threaded case
      • Armor:
        None
      • Agency Approval:
        Multiple Approvals
      • Probe Tip Material:
        PEEK
      • Probe Case Material:
        AISI 304 stainless steel
      • Probe Cable:
        75-ohm triaxial, PFA-insulated FluidLoc
      • Connector:
        High-temperature ClickLoc
      • Continuous Probe Temperature:
        -35 to +200 °C
      • Short-Term Probe Temperature:
        Up to +250 °C for less than 24 h
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330851-02-000-070-90-00-05 is a metric threaded 3300 XL 25 mm proximity probe for a matched differential-expansion measurement system.
      • PEEK sensing tip
      • AISI 304 stainless-steel probe case
      • FluidLoc probe cable
      • High-temperature ClickLoc connection

      The probe observes an approved turbine rotor collar or ramp without contact. The extension cable and 3300 XL 25 mm Proximitor Sensor complete the measurement chain; system performance depends on correct component matching.

      Important Notice: Confirm the complete 330851-02-000-070-90-00-05 marking, metric case, target arrangement, cable and matched Proximitor Sensor before commissioning.

      330851-02-000-070-90-00-05 Manuals & Downloads
      330851-02-000-070-90-00-05 Technical Reference (PDF)330851-02-000-070-90-00-05 Installation & Commissioning Guide (PDF)

      The first document contains model-specific technical data. The second sets out installation, pairing, verification and release checks.

      Steam-Turbine Differential ExpansionMonitor rotor-to-stator growth with the matched 25 mm transducer chain.
      Collar ObservationObserve one collar side in the manufacturer-described redundant arrangement.
      Complementary InputUse opposing collar-side probes where the system is engineered for it.
      Ramp CompensationUse a second measurement to account for radial motion in an approved ramp installation.
      Before installing Bently Nevada 330851-02-000-070-90-00-05, verify the complete nameplate, metric mounting, matched 3300 XL 25 mm transducer system and approved plant work procedure.
      1
      Record the full 330851-02-000-070-90-00-05 nameplate and verify the metric threaded case.
      2
      Isolate the protection channel under the plant-approved work procedure.
      3
      Inspect the PEEK tip, stainless-steel case and turbine target before mounting.
      4
      Route the FluidLoc cable without damage or unapproved strain.
      5
      Inspect, mate and protect the high-temperature ClickLoc connector.
      6
      Match the probe with its 3300 XL 25 mm extension cable and Proximitor Sensor.
      7
      Confirm the target, bracket, alignment and monitor settings.
      8
      Record static output and a controlled differential-expansion function test before release.

      Technical notes

      Technical notes

      Use this 3300 XL 25 mm probe only with the documented matching extension cable and Proximitor Sensor. Confirm the metric case, ClickLoc connection, target geometry and differential-expansion channel response against Bently Nevada datasheet 163236 Rev. M before commissioning.

      FAQS

      • What is 330851-02-000-070-90-00-05?
        It is a 3300 XL 25 mm proximity probe within the matched differential-expansion transducer system described in Bently Nevada datasheet 163236 Rev. M.
      • What case style does 330851-02-000-070-90-00-05 use?
        Its 02 case option identifies the metric M30x2 threaded probe case.
      • Does 330851-02-000-070-90-00-05 include armor?
        No. The 00 armor option denotes no stainless-steel armor.
      • What agency approval option applies to 330851-02-000-070-90-00-05?
        The final 05 option denotes multiple agency approvals.
      • What connector design is used on 330851-02-000-070-90-00-05?
        The 3300 XL 25 mm probe family uses high-temperature ClickLoc connectors and connector protectors.
      • What is the probe-tip material of 330851-02-000-070-90-00-05?
        The official 3300 XL 25 mm datasheet identifies PEEK as the probe-tip material.
      • How should 330851-02-000-070-90-00-05 be paired for a differential-expansion channel?
        Match the probe with the 3300 XL 25 mm extension cable and Proximitor Sensor required by the documented system configuration; verify operation after installation.
