      Bently Nevada 330851-06-000-070-10-00-05
      Bently Nevada 330851-06-000-070-10-00-05
      Bently Nevada 330851-06-000-070-10-00-05
      Bently Nevada 330851-06-000-070-10-00-05
      Bently Nevada 330851-06-000-070-10-00-05
      Bently Nevada 330851-06-000-070-10-00-05
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330851-06-000-070-10-00-05

      25 mm Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330851-06-000-070-10-00-05 is an unarmored M39 x 1.5 3300 XL 25 mm probe with a 70 mm case, 1.0 m lead and multiple agency approvals.

      Ask our team:

      Get a quick price for： 330851-06-000-070-10-00-05
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330851-06-000-070-10-00-05

      Technical specifications for 330851-06-000-070-10-00-05

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330851-06-000-070-10-00-05
      • Estimated shipping dimensions:
        110x5x5cm
      • Weight:
        0.66 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • probe family:
        3300 XL 25 mm
      • mounting thread:
        M39 x 1.5
      • unthreaded length:
        0 mm
      • overall case length:
        70 mm
      • total probe-lead length:
        1.0 m
      • armor option:
        00, without armor
      • agency-approval option:
        05, multiple approvals
      • linear measurement range:
        12.7 mm (500 mils)
      • incremental scale factor:
        0.787 V/mm (20 mV/mil)
      • frequency response:
        0 to 2.7 kHz
      • minimum target diameter:
        61 mm
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330851-06-000-070-10-00-05 is an unarmored M39 x 1.5 3300 XL 25 mm probe with a 70 mm case, 1.0 m lead and multiple agency approvals.
      • Provides the 25 mm long-range transducer function
      • Uses an M39 x 1.5 threaded case
      • Retains a 1.0 m unarmored lead
      • Carries the documented approval option

      330851-06-000-070-10-00-05 operates with matched 3300 XL 25 mm extension cable, compatible 3300 XL 25 mm Proximitor Sensor, approved large target surface, configured position channel.

      Engineered applications include Large-range axial position, Differential expansion, Long-range displacement measurement, Exact 25 mm probe replacement.

      Important Notice: Verify the 61 mm minimum target, M39 x 1.5 mounting, 70 mm case, system length, gap and matched 25 mm Proximitor Sensor before release.

      330851-06-000-070-10-00-05 Manuals & Downloads
      330851-06-000-070-10-00-05 Technical Reference (PDF)330851-06-000-070-10-00-05 Installation & Commissioning Guide (PDF)

      The first document presents exact-model technical and engineering data. The second provides a separate installation, connection, commissioning and acceptance workflow.

      Large-range axial position
      Measures documented rotor axial position over the long linear range.
      Differential expansion
      Supports approved turbine differential-expansion arrangements.
      Long-range displacement measurement
      Provides non-contacting displacement measurement for the specified large target.
      Exact 25 mm probe replacement
      Restores the exact thread, case, lead and approval identity.
      Read the applicable Bently Nevada instructions before work. Verify 330851-06-000-070-10-00-05, the installed system and every configured interface before isolation, wiring or commissioning.
      1
      Verify the complete 330851-06-000-070-10-00-05 marking and its assigned 3300 XL 25 mm Proximity Transducer System position before work.
      2
      Place the connected large-range axial position process in the approved maintenance state.
      3
      Isolate the documented power, signal and stored-energy sources before disconnecting the transducer or module.
      4
      Record every connector, cable route, shield, polarity, channel assignment and host configuration before removal.
      5
      Use ESD-safe handling and protect coaxial, terminal and keyed interfaces from contamination or mechanical damage.
      6
      Confirm the installed matched 3300 XL 25 mm extension cable and compatible 3300 XL 25 mm Proximitor Sensor against the approved project record.
      7
      Restore power in a controlled sequence and review transducer, monitor and host diagnostics.
      8
      Prove the intended differential expansion function and retain the final controlled acceptance result.

      Technical notes

      Technical notes

      Verify the 61 mm minimum target, M39 x 1.5 mounting, 70 mm case, system length, gap and matched 25 mm Proximitor Sensor before release.

      FAQS

      • Which probe family identifies Bently Nevada 330851-06-000-070-10-00-05?
        3300 XL 25 mm Proximity Transducer System Datasheet documents the probe family as 3300 XL 25 mm. Confirm the complete 330851-06-000-070-10-00-05 marking and the installed-system record before service.
      • What mounting thread is published for Bently Nevada 330851-06-000-070-10-00-05?
        3300 XL 25 mm Proximity Transducer System Datasheet documents the mounting thread as M39 x 1.5. Confirm the complete 330851-06-000-070-10-00-05 marking and the installed-system record before service.
      • How must the unthreaded length of Bently Nevada 330851-06-000-070-10-00-05 be matched?
        3300 XL 25 mm Proximity Transducer System Datasheet documents the unthreaded length as 0 mm. Confirm the complete 330851-06-000-070-10-00-05 marking and the installed-system record before service.
      • Which overall case length must technicians retain for Bently Nevada 330851-06-000-070-10-00-05?
        3300 XL 25 mm Proximity Transducer System Datasheet documents the overall case length as 70 mm. Confirm the complete 330851-06-000-070-10-00-05 marking and the installed-system record before service.
      • What does the official record state for the total probe-lead length of Bently Nevada 330851-06-000-070-10-00-05?
        3300 XL 25 mm Proximity Transducer System Datasheet documents the total probe-lead length as 1.0 m. Confirm the complete 330851-06-000-070-10-00-05 marking and the installed-system record before service.
      • How should the armor option be verified on Bently Nevada 330851-06-000-070-10-00-05?
        3300 XL 25 mm Proximity Transducer System Datasheet documents the armor option as 00, without armor. Confirm the complete 330851-06-000-070-10-00-05 marking and the installed-system record before service.
      • Which exact agency-approval option distinguishes Bently Nevada 330851-06-000-070-10-00-05?
        3300 XL 25 mm Proximity Transducer System Datasheet documents the agency-approval option as 05, multiple approvals. Confirm the complete 330851-06-000-070-10-00-05 marking and the installed-system record before service.
      • What linear measurement range is used when commissioning Bently Nevada 330851-06-000-070-10-00-05?
        3300 XL 25 mm Proximity Transducer System Datasheet documents the linear measurement range as 12.7 mm (500 mils). Confirm the complete 330851-06-000-070-10-00-05 marking and the installed-system record before service.
