      Bently Nevada 330104-00-08-05-02-05
      Bently Nevada 330104-00-08-05-02-05
      Bently Nevada 330104-00-08-05-02-05
      Bently Nevada 330104-00-08-05-02-05
      Bently Nevada 330104-00-08-05-02-05
      Bently Nevada 330104-00-08-05-02-05
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330104-00-08-05-02-05

      Proximity Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330104-00-08-05-02-05 is a proximity probe for the 3300 XL 8 mm proximity transducer system. It is a armored M10 x 1 3300 XL 8 mm probe with a 80 mm case and 0.5 m integral lead.

      Ask our team:

      Get a quick price for： 330104-00-08-05-02-05
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330104-00-08-05-02-05

      Technical specifications for 330104-00-08-05-02-05

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330104-00-08-05-02-05
      • Estimated shipping dimensions:
        1.8x1.6x59cm
      • Weight:
        0.08 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Manufacturer:
        Bently Nevada
      • Product family:
        3300 XL 8 mm proximity transducer system
      • Probe part family:
        330104
      • Mounting thread:
        M10 x 1
      • Cable armor:
        Armored
      • Unthreaded length:
        0 mm
      • Overall case length:
        80 mm
      • Probe lead length:
        0.5 m
      • Connector and cable option:
        ClickLoc standard cable
      • Approval option:
        Multiple approvals
      • System linear range:
        2.0 mm (80 mils)
      • Scale factor:
        7.87 V/mm (200 mV/mil)
      • Frequency response:
        0 to 10 kHz
      • Nominal gap:
        1.27 mm (50 mils)
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      It is a armored M10 x 1 3300 XL 8 mm probe with a 80 mm case and 0.5 m integral lead.
      • Uses the M10 x 1 probe construction
      • Retains the 80 mm case identity
      • Includes a 0.5 m integral probe lead
      • Uses the clickloc standard cable option

      330104-00-08-05-02-05 operates with a matched 3300 XL extension cable, a compatible 3300 XL Proximitor Sensor, an approved conductive target, the configured machinery-monitor channel.

      Engineered applications include Radial shaft vibration, Axial position, Phase reference, Exact probe replacement.

      Important Notice: Verify 330104-00-08-05-02-05, the installed extension cable and Proximitor Sensor, target material, system length and gap before replacement.

      Bently Nevada 330104-00-08-05-02-05 Manuals & Downloads
      Bently Nevada 330104-00-08-05-02-05 Technical Reference (PDF)Bently Nevada 330104-00-08-05-02-05 Installation & Commissioning Guide (PDF)

      The first document presents exact-model technical and engineering data. The second provides a separate installation, connection, commissioning and acceptance workflow.

      Radial shaft vibration
      Measures non-contacting shaft vibration in a matched 8 mm system.
      Axial position
      Tracks shaft position where the engineered target and mounting geometry support the measurement.
      Phase reference
      Supports phase-reference service when the monitor project assigns this probe accordingly.
      Exact probe replacement
      Preserves the published thread, case, lead and connector identity during maintenance.
      Read the applicable Bently Nevada instructions before work. Verify 330104-00-08-05-02-05, the installed system and every configured interface before isolation, wiring or commissioning.
      1
      Confirm the complete 330104-00-08-05-02-05 marking before removal.
      2
      Check the installed M10 x 1 mounting and preserve the mechanical reference.
      3
      Isolate the monitoring channel and protect the probe tip from impact.
      4
      Record the 0 mm unthreaded and 80 mm case geometry.
      5
      Preserve the 0.5 m lead routing and minimum bend radius.
      6
      Protect the clickloc standard cable interface from contamination.
      7
      Match the probe to the documented extension cable and Proximitor Sensor.
      8
      Set the gap under controlled conditions and verify gap voltage and signal response.

      Technical notes

      Technical notes

      Verify 330104-00-08-05-02-05, the installed extension cable and Proximitor Sensor, target material, system length and gap before replacement.

      FAQS

      • Why does Bently Nevada 330104-00-08-05-02-05 require an M10 x 1 mounting position?
        The 330104 probe construction uses an M10 x 1 thread, so the bracket or machine tapping must preserve that interface without adapters that alter probe position.
      • Which mechanical lengths must match when replacing Bently Nevada 330104-00-08-05-02-05?
        Match the 0 mm unthreaded section and 80 mm overall case; either value changes the installed tip location and available adjustment.
      • How should the armored lead on Bently Nevada 330104-00-08-05-02-05 be routed?
        Route the 0.5 m integral lead without twisting the armor, protect its bend radius, and keep the ClickLoc connection clean and strain-free.
      • What does the final 05 option change for Bently Nevada 330104-00-08-05-02-05?
        Option 05 carries the multiple-approval identity. The replacement must agree with the certification record for the installed location.
      • What travel should be checked for the matched 330104-00-08-05-02-05 system?
        A correctly matched 3300 XL 8 mm chain provides a 2.0 mm (80 mil) linear range; check the full intended travel without driving the probe outside that range.
      • Which sensitivity belongs in the monitor channel for Bently Nevada 330104-00-08-05-02-05?
        Configure and verify 7.87 V/mm (200 mV/mil) for the matched probe, extension cable, and Proximitor Sensor.
      • How does the 10 kHz response limit affect Bently Nevada 330104-00-08-05-02-05 commissioning?
        The transducer chain is specified from 0 to 10 kHz, while the monitor filter still has to match the machinery measurement being commissioned.
      • What evidence closes installation of Bently Nevada 330104-00-08-05-02-05?
        Release the channel after confirming the 1.27 mm nominal gap, stable gap voltage, correct polarity, and repeatable vibration or position response.
