      Bently Nevada 330930-040-00-05
      Bently Nevada 330930-040-00-05
      Bently Nevada 330930-040-00-05
      Bently Nevada 330930-040-00-05
      Bently Nevada 330930-040-00-05
      Bently Nevada 330930-040-00-05
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330930-040-00-05

      3300 XL NSv Extension Cable
      In Stock

      Product Describe：

      Bently Nevada 330930-040-00-05 is a four-metre 3300 XL NSv extension cable without stainless-steel armor. It completes the matched electrical length between an NSv proximity probe and Proximitor Sensor.

      Ask our team:

      Get a quick price for： 330930-040-00-05
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330930-040-00-05

      Technical specifications for 330930-040-00-05

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330930-040-00-05
      • Estimated shipping dimensions:
        18x18x2cm
      • Weight:
        0.08 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Cable length:
        4.0 m (13.1 ft)
      • Cable construction:
        Without stainless-steel armor
      • Approval option:
        Multiple approvals
      • Cable impedance:
        75 ohm
      • Operating temperature:
        -52 to +177 degC
      • Storage temperature:
        -52 to +177 degC
      • Typical cable mass:
        45 g/m
      • Connector family:
        Gold-plated ClickLoc coaxial
      • System linear range:
        1.5 mm (60 mils)
      • Incremental scale factor:
        7.87 V/mm (200 mV/mil)
      • Recommended system gap:
        1.0 mm (40 mils)
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      3300 XL NSv Extension Cable provides the documented interface for its installed Bently Nevada 3300 XL NSv Proximity Transducer System system.
      • Extends an NSv probe connection by four metres
      • Completes the selected five- or seven-metre transducer-system length
      • Carries the proximity signal through a 75-ohm coaxial path
      • Uses the unarmored cable execution with multiple approvals

      330930-040-00-05 carries the NSv eddy-current probe signal across a four-metre field connection while completing the approved probe-plus-cable length for the selected Proximitor Sensor. The installation uses the manufacturer-specified host position, companion hardware and field/control wiring for the intended industrial application.

      System commissioning includes identity checks, connection verification, controlled energization and functional diagnostics for 330930-040-00-05.

      Important Notice: Confirm the complete 330930-040-00-05 marking, approved system arrangement, connection records and controlled functional test before commissioning or replacement.

      Apter Power 330930-040-00-05 Manuals and Guides
      Apter Power 330930-040-00-05 Product Technical Reference PDF330930-040-00-05 Engineering Installation and Verification Workbook
      The first document organizes model-specific technical identity and engineering data. The second provides a separate field workflow for installation, connection checks and commissioning records.
      Remote NSv Proximitor cabinet routing3300 XL NSv proximity probe supports the engineered 330930-040-00-05 arrangement.
      Process-compressor probe extension3300 XL NSv Proximitor Sensor supports the engineered 330930-040-00-05 arrangement.
      Confined bearing-housing signal connectionClickLoc connector protection supports the engineered 330930-040-00-05 arrangement.
      NSv cable replacement in matched loopsApproved cable supports and routing supports the engineered 330930-040-00-05 arrangement.
      Read the applicable Bently Nevada installation instructions before work. Verify 330930-040-00-05 and the installed-system configuration.
      1Verify 330930-040-00-05, its four-metre length and unarmored execution before routing.
      2Isolate the assigned monitor input and place machine protection in maintenance state.
      3Inspect both ClickLoc contacts and keep them free of oil, moisture and debris.
      4Do not pull, twist or support the cable by either coaxial connector.
      5Route the unarmored cable away from abrasion, hot surfaces and high-current conductors.
      6Confirm probe length plus extension length matches the Proximitor Sensor system length.
      7Secure and protect both connector joints before restoring the monitor channel.
      8Verify continuity, gap voltage, polarity and dynamic response after reconnection.

      Technical notes

      Technical notes

      Add the four-metre length of 330930-040-00-05 to the installed probe length and confirm the result matches the selected NSv Proximitor Sensor. Support the unarmored cable, protect both ClickLoc interfaces and verify continuity, gap voltage and dynamic response.

      FAQS

      • What is the ordered length of 330930-040-00-05?
        The 040 length code specifies a four-metre, 13.1-foot NSv extension cable.
      • Does 330930-040-00-05 include stainless-steel armor?
        No. The 00 connector-and-cable option identifies the version without stainless-steel armor.
      • Which transducer family uses 330930-040-00-05?
        It is an extension cable for the Bently Nevada 3300 XL NSv Proximity Transducer System.
      • How is the correct system length calculated for 330930-040-00-05?
        Add the installed probe cable length to the four-metre extension cable and match that total to the selected NSv Proximitor Sensor.
      • What connectors are used on 330930-040-00-05?
        The NSv probe and extension-cable system uses corrosion-resistant gold-plated ClickLoc coaxial connectors.
      • How should 330930-040-00-05 be routed?
        Support the unarmored cable along its route and protect it from sharp bends, abrasion, hot surfaces and tensile loading.
      • What should be checked before reconnecting 330930-040-00-05?
        Inspect connector condition, verify cable identity and continuity, and confirm the approved probe-plus-extension length.
      • What commissioning checks follow replacement of 330930-040-00-05?
        Verify gap voltage, polarity, dynamic response, monitor diagnostics and alarm action under controlled conditions.
