      Bently Nevada 330101-00-36-10-01-00
      Bently Nevada 330101-00-36-10-01-00
      Bently Nevada 330101-00-36-10-01-00
      Bently Nevada 330101-00-36-10-01-00
      Bently Nevada 330101-00-36-10-01-00
      Bently Nevada 330101-00-36-10-01-00
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330101-00-36-10-01-00

      Proximity Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330101-00-36-10-01-00 is an unarmored 3300 XL 8 mm probe with a 3/8-24 UNF case, a 3.6-inch overall case length and a 1.0 m standard cable. Its ClickLoc connector includes a protector for use in a matched non-contacting proximity transducer system.

      Ask our team:

      Get a quick price for： 330101-00-36-10-01-00
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330101-00-36-10-01-00

      Technical specifications for 330101-00-36-10-01-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330101-00-36-10-01-00
      • Estimated shipping dimensions:
        5.3x3.2x10cm
      • Weight:
        0.3 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe family:
        3300 XL 8 mm
      • Base model:
        330101
      • Mounting thread:
        3/8-24 UNF
      • Armor:
        Without armor
      • Unthreaded length:
        0.0 in
      • Overall case length:
        3.6 in
      • Total probe length:
        1.0 m (3.3 ft)
      • Connector:
        Miniature coaxial ClickLoc
      • Connector protector:
        Included
      • Cable type:
        Standard cable
      • Agency approval option:
        No approvals
      • System linear range:
        2.0 mm (80 mil)
      • System scale factor:
        7.87 V/mm (200 mV/mil)
      • Recommended initial gap:
        1.27 mm (50 mil)
      • Minimum cable bend radius:
        25.4 mm (1.0 in)
      • Maximum connector torque:
        0.565 N m (5 in-lb)
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330101-00-36-10-01-00 is an unarmored 3300 XL 8 mm probe with a 3/8-24 UNF case, a 3.6-inch overall case length and a 1.0 m standard cable. Its ClickLoc connector includes a protector for use in a matched non-contacting proximity transducer system.
      • Unarmored 3300 XL 8 mm probe
      • 3/8-24 UNF case with 3.6 in overall length
      • 1.0 m cable and protected ClickLoc connector
      • Component of a matched proximity system

      The 1.0 m probe is one component of a complete matched 3300 XL 8 mm system; select the extension cable and Proximitor Sensor for the required system length. Protect the ClickLoc connection and verify the final gap within the 2.0 mm linear range.

      Important Notice: Confirm the exact 330101-00-36-10-01-00 marking, matching system components, installed configuration and controlled output before release.

      330101-00-36-10-01-00 Manuals & Downloads

      These documents are different: the first consolidates verified product and system data; the second provides installation checks, commissioning steps and acceptance records.

      Short probe-cable installations
      A 1.0 m probe cable suits the documented extension-cable and sensor combination.
      Radial vibration channels
      Non-contacting radial motion monitoring on a suitable shaft target.
      Axial position channels
      Position measurement with the approved target and mounting geometry.
      System replacements
      Preserves the matching cable, sensor and installation configuration.
      Read the applicable Bently Nevada instructions before work. Verify 330101-00-36-10-01-00 and its complete matched system before installation or commissioning.
      1
      Check the full 330101-00-36-10-01-00 code, including its 3.6 in case length.
      2
      Confirm the 3/8-24 UNF mounting accepts the installed unarmored probe.
      3
      Pair its 1.0 m cable with the extension cable and Proximitor Sensor for the chosen system length.
      4
      Protect the ClickLoc protector and keep both connector halves clean and seated.
      5
      Keep cable bends above the documented 25.4 mm minimum radius.
      6
      Confirm the target, probe spacing and shaft geometry before setup.
      7
      Adjust the initial gap near 1.27 mm and test within the 2.0 mm linear range.
      8
      Record the controlled output and final monitor diagnostics.

      Technical notes

      Technical notes

      The 1.0 m probe is one component of a complete matched 3300 XL 8 mm system; select the extension cable and Proximitor Sensor for the required system length. Protect the ClickLoc connection and verify the final gap within the 2.0 mm linear range.

      FAQS

      • How does 330101-00-36-10-01-00 differ from an armored 8 mm probe?
        Its 330101 base code specifies a 3/8-24 UNF 3300 XL 8 mm probe without armor.
      • What physical length is encoded by 36 in 330101-00-36-10-01-00?
        Option 36 denotes a 3.6-inch overall case length, while the preceding 00 denotes 0.0-inch unthreaded length.
      • How long is the attached probe cable on 330101-00-36-10-01-00?
        The 10 option specifies a 1.0 m (3.3 ft) total probe length.
      • What is supplied by connector option 01 on 330101-00-36-10-01-00?
        It specifies the miniature coaxial ClickLoc connector, standard cable and connector protector.
      • Does 330101-00-36-10-01-00 carry the optional agency approvals?
        No. Its final 00 option means no agency approval option was selected.
      • Can the 1 m 330101-00-36-10-01-00 cable alone identify the full transducer-system length?
        No. Match the probe and extension cable to the selected 3300 XL 8 mm Proximitor Sensor system length.
      • What measurement span applies to a correctly matched 330101-00-36-10-01-00 system?
        The 3300 XL 8 mm system linear range is 2.0 mm (80 mil), with a nominal scale factor of 7.87 V/mm.
      • What cable-routing limit matters for 330101-00-36-10-01-00?
        Maintain at least the published 25.4 mm (1.0 in) cable bend radius.
