Technical specifications for 6DS1717-8RR
-
Manufacturer:Siemens
-
Product Category:DCS Systems
-
Spare Part Number:6DS1717-8RR
-
Estimated shipping dimensions:24.3x18.9x3cm
-
Weight:0.32 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product family:TELEPERM M
-
Module type:Binary calculator module
-
Configuration:Structurable
-
Integration context:Connecting TELEPERM M I/O to PCS 7
-
TPM 478 processing time:10 ms without analog values
-
TPM 478 processing time with analog values:18 ms
-
Cycle guidance:Use a slow cycle, for example 1 s
-
DB 1 rule:Configured processing cycle faster than the PLC cycle of corresponding driver blocks
Information
Overview
Manuals
Common Applications
Product Precautions
Siemens 6DS1717-8RR provides a structurable binary-calculation position in TELEPERM M, with the PCS 7/TM manual specifying driver processing time and cycle-order constraints.
- Is identified as a structurable TELEPERM M binary calculator module.
- Uses a TPM 478 processing time of 10 ms without analog values.
- Uses a TPM 478 processing time of 18 ms when analog values are included.
- Requires the DB 1 processing cycle to remain faster than the associated PLC driver cycle.
TPM 478 processing takes 10 ms without analog values and 18 ms with analog values. A slow cycle such as 1 s is recommended, and the processing cycle configured in DB 1 must remain faster than the PLC cycle of the corresponding driver blocks.
Important Notice: preserve the complete 6DS1717-8RR identity, binary structure, driver blocks, analog-value use and DB 1/PLC cycle relationship before replacement.
Siemens 6DS1717-8RR Manuals & Downloads
Siemens 6DS1717-8RR Official PCS 7/TM Manual Excerpt (PDF)Siemens 6DS1717-8RR Installation & Commissioning Guide (PDF)
The documents separate exact product evidence from the field sequence for identity, isolation, installation, verification and controlled handover.
Binary calculation
Runs the retained structurable binary function for the TELEPERM M position.
PCS 7/TM integration
Represents the exact RR module and driver-cycle relationship in the migrated configuration.
Cycle-controlled execution
Applies the processing-time and DB 1 cycle requirements.
Legacy logic maintenance
Restores the recorded binary structure without copying a nearby module configuration.
Apply these checks to the exact Siemens 6DS1717-8RR position before isolation, replacement or release.
1
Confirm the complete Siemens 6DS1717-8RR marking before work.
2
Place every dependent binary function in the approved maintenance state.
3
Back up the complete binary structure and associated driver-block assignments.
4
Record whether the structure uses analog values before calculating cycle demand.
5
Verify the applicable 10 ms or 18 ms TPM 478 processing-time case.
6
Confirm the DB 1 processing cycle is faster than the associated PLC driver cycle.
7
Review module, interface and cycle diagnostics after controlled energization.
8
Functionally test the retained binary calculation before service release.
Technical notes
Back up the binary structure, driver assignments, analog-value use and DB 1/PLC cycle settings before exchange. After energization, confirm cycle diagnostics and test the retained calculation.
FAQ View All FAQ
-
What function does Siemens 6DS1717-8RR provide?The Siemens table identifies it as a structurable binary calculator module.
-
Which product family includes Siemens 6DS1717-8RR?It is listed in the TELEPERM M I/O configuration for PCS 7/TM integration.
-
What processing time applies to Siemens 6DS1717-8RR without analog values?The TPM 478 processing time is 10 ms.
-
What processing time applies to Siemens 6DS1717-8RR with analog values?The TPM 478 processing time is 18 ms.
-
Which cycle guidance applies to Siemens 6DS1717-8RR?Use a slow cycle, for example 1 second, for this driver context.
-
How should the DB 1 cycle relate to Siemens 6DS1717-8RR driver blocks?The DB 1 processing cycle must be faster than the PLC cycle of the corresponding driver blocks.
-
What must be recorded before replacing Siemens 6DS1717-8RR?Record the binary structure, driver assignments, analog-value use and DB 1/PLC cycle relationship.
-
What verifies Siemens 6DS1717-8RR after installation?Review interface and cycle diagnostics, then functionally test the retained binary calculation.
