Technical specifications for 6DS1703-8RR
-
Manufacturer:Siemens
-
Product Category:DCS Systems
-
Spare Part Number:6DS1703-8RR
-
Estimated shipping dimensions:24.3x19x3cm
-
Weight:0.22 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product family:TELEPERM M
-
Module class:Measurement-point expansion module
-
Function:Measurement-point expansion for 1731
-
Companion context:TELEPERM M 1731 analog-input module
-
Available-module row:14 thermal elements for 6DS1703-8AB
-
Approved execution:6DS1703-8RR listed as compatible approved version
-
Configuration identity:Use the complete MLFB shown in the PCS 7/TM table
-
Integration context:Connecting TELEPERM M I/O to PCS 7
Information
Overview
Manuals
Common Applications
Product Precautions
Siemens 6DS1703-8RR extends the TELEPERM M measurement-point arrangement associated with the 1731 module and serves as the approved RR execution for the corresponding 14-thermal-element position.
- Carries the exact 6DS1703-8RR MLFB in the Siemens configuration table.
- Provides measurement-point expansion for the 1731 module context.
- Is the approved RR execution for the associated 14-thermal-element module row.
- Requires preservation of the PCS 7/TM mapping and every affected measurement point.
The PCS 7/TM configuration uses 6DS1703-8RR for measurement-point expansion with 1731. The 8RR execution aligns with the 6DS1703-8AB 14-thermal-element row, so the exact MLFB and retained companion-module mapping must be verified together.
Important Notice: preserve the complete 6DS1703-8RR identity, paired 1731 position, terminal records and PCS 7/TM channel mapping before replacement.
Siemens 6DS1703-8RR Manuals & Downloads
Siemens 6DS1703-8RR Official PCS 7/TM Manual Excerpt (PDF)Siemens 6DS1703-8RR Installation & Commissioning Guide (PDF)
The documents separate exact product evidence from the field sequence for identity, isolation, installation, verification and controlled handover.
TELEPERM measurement expansion
Retains the measurement-point expansion position associated with the 1731 module.
PCS 7/TM integration
Uses the exact RR identity when the legacy TM I/O position is represented in PCS 7.
Thermal-measurement maintenance
Restores the approved execution for the associated 14-thermal-element module row.
Legacy I/O verification
Separates module identity, companion context and configured measurement-point mapping.
Apply these checks to the exact Siemens 6DS1703-8RR position before isolation, replacement or release.
1
Confirm the complete Siemens 6DS1703-8RR marking before work.
2
Place the affected TELEPERM M and PCS 7 path in the approved maintenance state.
3
Record the paired 1731 position and every configured measurement point.
4
Preserve terminal, channel and cabinet records before removing the module.
5
Verify that the PCS 7/TM configuration uses the exact 6DS1703-8RR identity.
6
Check the approved RR execution against the retained 14-thermal-element position.
7
Review interface and process diagnostics after controlled energization.
8
Functionally verify every affected measurement point before service release.
Technical notes
Record the paired 1731 position, terminal map and PCS 7/TM assignment before removal. After energization, review interface diagnostics and verify each affected measurement point against the retained record.
FAQ View All FAQ
-
What function does Siemens 6DS1703-8RR provide?It provides measurement-point expansion for the 1731 module.
-
Which product family includes Siemens 6DS1703-8RR?It is listed among the TELEPERM M I/O modules used in the PCS 7/TM integration path.
-
Which companion context applies to Siemens 6DS1703-8RR?Its function is tied to the TELEPERM M 1731 analog-input module context.
-
How is Siemens 6DS1703-8RR represented in the available-module table?It is the compatible approved RR execution for the 6DS1703-8AB 14-thermal-element row.
-
How should Siemens 6DS1703-8RR be entered in the configuration?Use the complete 6DS1703-8RR MLFB shown in the Siemens PCS 7/TM table.
-
Which Siemens manual covers Siemens 6DS1703-8RR?It appears in Connecting TM I/O to PCS 7, C79000-G8076-C710-04.
-
What must be recorded before replacing Siemens 6DS1703-8RR?Record the paired 1731 position, terminals, channel mapping and every affected measurement point.
-
What verifies Siemens 6DS1703-8RR after installation?Verify the exact identity, PCS 7/TM mapping, diagnostics and every affected measurement point.
