Product image is representative; revision or series may vary. Contact us to request a specific version.
Get a quick price for 6DS1606-8BA
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 6DS1606-8BA
-
Manufacturer:Siemens
-
Product Category:DCS Systems
-
Spare Part Number:6DS1606-8BA
-
Estimated shipping dimensions:24.3x18.2x3cm
-
Weight:0.74 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product family:TELEPERM M / AS 235 H
-
Module type:Testable relay output module (PRA)
-
Driver context:PRA function block
-
Fault coverage:Module-fault detection including contact monitoring
-
Supported structures:1-out-of-1, 1-out-of-2 and 2-out-of-2
-
Output interface:Relay outputs wired to the actuator for the application
-
1-out-of-1 behavior:Immediate hardware-fault detection
-
1-out-of-2 objective:Retain the ability to issue ON after one module fault under the configured logic
-
2-out-of-2 objective:Retain the ability to issue OFF after one module fault under the configured logic
-
Fault-default caution:Coordinate the master-driver freeze bit with the configured fault value
-
Exact article:6DS1606-8BA
Information
Overview
Manuals
Common Applications
Product Precautions
Within the AS 235 H architecture, Siemens 6DS1606-8BA provides testable relay outputs whose PRA driver supports module-fault detection, contact monitoring and redundant structures.
- Uses the PRA driver context for testable relay outputs.
- Includes module-fault detection and contact-monitoring functions.
- Supports 1-out-of-1, 1-out-of-2 and 2-out-of-2 structures.
- Requires application-specific relay wiring and coordinated fault-default logic.
The 1-out-of-1, 1-out-of-2 and 2-out-of-2 arrangements produce different fault responses, while the relay outputs connect to the actuators for the specific application. The selected structure and fault-default logic therefore belong to the engineered safety behavior of the installed position.
Important Notice: preserve the complete 6DS1606-8BA identity, PRA driver assignment, output wiring, redundancy structure, freeze-bit state and fault-default values before replacement.
Siemens 6DS1606-8BA Manuals & Downloads
Siemens 6DS1606-8BA Official AS 235 H Manual Excerpt (PDF)Siemens 6DS1606-8BA Installation & Commissioning Guide (PDF)
The documents separate exact product evidence from the field sequence for identity, isolation, installation, verification and controlled handover.
Fault-monitored relay outputs
Maintains the PRA output position where contact and module-fault detection are required.
Redundant actuator paths
Implements the selected 1oo2 or 2oo2 behavior only with the retained external wiring and driver logic.
AS 235 H maintenance
Restores the exact module and PRA-driver relationship during controlled cabinet service.
Output-path diagnostics
Separates module, contact, driver and actuator-wiring faults before service release.
Apply these checks to the exact Siemens 6DS1606-8BA position before isolation, replacement or release.
1
Confirm the complete Siemens 6DS1606-8BA marking before work.
2
Place every connected actuator in the approved maintenance state.
3
Record the PRA driver, addresses, relay wiring and selected redundancy structure.
4
Document the master-driver freeze bit and every affected fault-default value.
5
Inspect relay-output conductors and contact-monitoring paths before reconnection.
6
Restore the exact 1oo1, 1oo2 or 2oo2 arrangement without borrowing settings.
7
Review PRA driver and module-fault indications after controlled energization.
8
Prove every affected actuator path before returning the process to service.
Technical notes
Freeze outputs and capture PRA driver addresses, relay wiring, redundancy mode and fault-default values before exchange. After energization, clear module faults and prove each contact-monitoring and actuator path under the approved test plan.
FAQ View All FAQ
-
What function does Siemens 6DS1606-8BA provide?It is the AS 235 H testable relay output module used with the PRA driver block.
-
Which fault functions does Siemens 6DS1606-8BA provide?It includes complete module-fault detection and contact monitoring.
-
Which structures can Siemens 6DS1606-8BA use?It supports 1-out-of-1, 1-out-of-2 and 2-out-of-2 structures.
-
How are the relay outputs of Siemens 6DS1606-8BA connected?They must be wired to the actuators according to the application and the selected structure.
-
Why is the freeze bit important for Siemens 6DS1606-8BA?The 1oo2 behavior requires the master-driver freeze bit and channel fault-default value to be coordinated.
-
What must be recorded before replacing Siemens 6DS1606-8BA?Record the PRA driver, addresses, relay wiring, redundancy structure, freeze bit and fault-default values.
-
Can Siemens 6DS1606-8BA settings be copied from a nearby output module?No. Restore the exact installed wiring and driver logic for this position.
-
What verifies Siemens 6DS1606-8BA after installation?Review PRA and module-fault indications, then functionally prove every affected actuator path.
