Technical specifications for 6DS1300-8AB
-
Manufacturer:Siemens
-
Product Category:DCS Systems
-
Spare Part Number:6DS1300-8AB
-
Estimated shipping dimensions:24.3x1.4x18.2cm
-
Weight:0.34 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product family:TELEPERM
-
Module type:Monitor interface module
-
Display context:Monochrome monitor
-
Electrical interface:20 mA line-current interface
-
Supply status:Spare-part article
-
Lifecycle:End of product lifecycle
-
Replacement rule:Match exact article and installed wiring
Information
Overview
Manuals
Common Applications
Product Precautions
Siemens 6DS1300-8AB forms the documented electrical interface between a TELEPERM system position and its monochrome monitor through a 20 mA line-current path.
- Connects the documented TELEPERM position to a monochrome monitor.
- Uses the stated 20 mA line-current interface rather than a generic video connection.
- Is identified by the complete 6DS1300-8AB article number.
- Requires preservation of the original wiring and cabinet assignment during service.
The exact article is an end-of-lifecycle spare part. Acceptance must therefore preserve the installed monitor, line-current wiring, cabinet position and system configuration rather than treating the module as a generic display adapter.
Important Notice: match the complete 6DS1300-8AB marking, monochrome-monitor role and retained 20 mA line-current wiring before replacement.
Siemens 6DS1300-8AB Manuals & Downloads
Siemens 6DS1300-8AB Technical Reference (PDF)Siemens 6DS1300-8AB Installation & Commissioning Guide (PDF)
The documents separate exact product evidence from the field sequence for identity, isolation, installation, verification and controlled handover.
Legacy operator display
Maintains the specified monochrome monitor path in an installed TELEPERM system.
Display-interface maintenance
Restores the documented 20 mA line-current connection after exact-article verification.
Cabinet spare replacement
Replaces the recorded interface position without changing monitor or system topology.
Fault isolation
Separates module, line-current wiring and monitor faults during controlled diagnostics.
Apply these checks to the exact Siemens 6DS1300-8AB position before isolation, replacement or release.
1
Confirm the complete Siemens 6DS1300-8AB marking before work.
2
Place the TELEPERM system and monitor path in the approved maintenance state.
3
Record the cabinet position, monitor identity and every connected conductor.
4
Prove the 20 mA line-current circuit safe before disconnecting the module.
5
Inspect connector condition and preserve the original wiring assignment.
6
Do not substitute a generic display or video interface for the documented path.
7
Review module and monitor indications after controlled energization.
8
Verify stable display operation before returning the station to service.
Technical notes
Preserve the complete Siemens 6DS1300-8AB identity, the installed position, wiring and configuration record. After controlled energization, review diagnostics and functionally verify every affected channel or process path before release.
FAQ View All FAQ
-
What is the purpose of Siemens 6DS1300-8AB?It is an interface module for the documented monochrome monitor position.
-
Which electrical interface is specified for Siemens 6DS1300-8AB?The official product record states a 20 mA line-current interface.
-
Which system family uses Siemens 6DS1300-8AB?The article belongs to the Siemens TELEPERM product context.
-
Is Siemens 6DS1300-8AB a current production item?Siemens lists it as an end-of-lifecycle spare-part article.
-
Can Siemens 6DS1300-8AB be treated as a generic monitor adapter?No. Match the exact article, monitor role and 20 mA line-current wiring.
-
What should be recorded before replacing Siemens 6DS1300-8AB?Record the cabinet position, monitor identity, connector orientation and every conductor assignment.
-
What should be inspected while servicing Siemens 6DS1300-8AB?Inspect connector condition, retained line-current wiring and the associated monitor path.
-
What verifies Siemens 6DS1300-8AB after installation?Review system indications and prove stable monitor operation before service release.
