Technical specifications for 3636R
-
Manufacturer:Invensys
-
Product Category:DCS Systems
-
Spare Part Number:3636R
-
Estimated shipping dimensions:2.2x40.6x39.8cm
-
Weight:2.42 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Product role:Non-triplicated relay output module
-
Output contacts:32, non-commoned
-
Contact state:Normally open
-
Isolation:Galvanically isolated
-
Maximum voltage:155 VAC/VDC
-
Maximum load current:2 A
-
Hot-spare support:Supported
-
External termination:Separate ETP and cable required
-
Standard panel:9668-110
-
Basic panel:9651-110
-
Typical use:Non-critical points such as annunciator interfaces
-
LED behavior:Only the primary module asserts point LEDs
Information
Overview
Manuals
Common Applications
Product Precautions
TRICONEX 3636R supplies dry-contact switching for auxiliary circuits that require isolated relay outputs rather than solid-state high-side drivers.
- Provides 32 non-commoned normally open contacts
- Uses galvanic isolation between individual output circuits
- Supports contact voltages up to 155 VAC or VDC
- Allows a hot-spare arrangement for the non-triplicated module
The module is intended for non-critical duties such as annunciator interfaces and requires a separate external termination panel and cable. Contact current, reactive-load derating and the selected 9668-110 or 9651-110 termination should be checked against the circuit design; only the primary module drives the point LEDs.
