DS200TCQAG1A

Turbine Control I/O Card
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

GE DS200TCQAG1A is a TCQA turbine-control I/O card for a configured SPEEDTRONIC Mark V system. Its function must be interpreted together with the installed processor, PROM set and field wiring.
  • Manufacturer part number
    DS200TCQAG1A
  • Shipping
    Swift global dispatch
  • Condition
    New, original product
  • Shipping size (est.)
    27.8cm × 21.2cm × 2cm
  • Country of Origin
    USA
Get a quick price for DS200TCQAG1A
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 0

    Review your reference

    Send the full DS200TCQAG1A marking, quantity and label photos. We review the item and any version details that need clarification.

  • 1

    Confirm the offer

    Check the quoted DS200TCQAG1A reference, condition, included items and expected dispatch date before approving your order.

  • 2

    Arrange dispatch

    Confirm delivery details and receive the tracking number when it becomes available for DS200TCQAG1A.

  • Match the complete marking

    Include DS200TCQAG1A and any revision or assembly number visible on the item. Keep the exact reference on your enquiry and quotation.

  • Check the offered item before ordering

    Request current label, board and connector photos of DS200TCQAG1A. Compare the offered reference and host configuration with the installed equipment before approval.

Technical specifications for DS200TCQAG1A

  • Manufacturer:
    General Electric
  • Product Category:
    General Automation
  • Spare Part Number:
    DS200TCQAG1A
  • Weight:
    0.65 kg
  • Tariff Code:
    8537101190
  • Thermocouple path:
    JA; inputs and cold-junction reference
  • Current-loop path:
    JB; 4–20 mA inputs and outputs via TBQC
  • Position-feedback path:
    JF; LVDT and LVDR inputs
  • Vibration / voltage path:
    JG; vibration and ±10 V dc inputs
  • Actuator / speed path:
    JE; servo, relay-driver and pulse signals
  • Trip-signal path:
    JD; R1 core to TCTG only
  • Milliamp circuit selection:
    Hardware jumpers J1 and J2
  • Milliamp output range:
    J5 and J6: 20 mA or 200 mA maximum

Information

Overview Downloads Applications / Compatibility Product Precautions
  • The Mark V maintenance architecture treats TCQA as one card within the control-core signal chain. The exact signal allocation is determined by the host cabinet and site-specific configuration, rather than by the G1A base label alone.
Host: SPEEDTRONIC Mark V
Card: TCQA controller I/O
Configuration: PROM and cabinet dependent
GE DS200TCQAG1A is a TCQA turbine-control I/O card for a configured SPEEDTRONIC Mark V system. Its function must be interpreted together with the installed processor, PROM set and field wiring.

The Mark V maintenance architecture treats TCQA as one card within the control-core signal chain. The exact signal allocation is determined by the host cabinet and site-specific configuration, rather than by the G1A base label alone.

For a controlled exchange, record PROM identities and all board markings, preserve cable positions and compare diagnostic indications before and after installation. Commissioning must follow the approved turbine-control procedure.
Controller platform reference: GE SPEEDTRONIC Mark V. Match the installed configuration and interfaces.
GE DS200TCQAG1A technical reference and installation verification downloads for Turbine Control I/O Card. Check the installed assembly, configuration and project records before service.
Match DS200TCQAG1A with the complete installed marking, connector layout and approved equipment documentation before commissioning.
Installation and commissioning checks for General Electric DS200TCQAG1A.
