      Bently Nevada 330851-02-000-060-50-00-00
      Bently Nevada 330851-02-000-060-50-00-00
      Bently Nevada 330851-02-000-060-50-00-00
      Bently Nevada 330851-02-000-060-50-00-00
      Bently Nevada 330851-02-000-060-50-00-00
      Bently Nevada 330851-02-000-060-50-00-00
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330851-02-000-060-50-00-00

      25 mm Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330851-02-000-060-50-00-00 is a 25 mm probe for the 3300 XL 25 mm proximity transducer system. It is an M30 x 2 unarmored 3300 XL 25 mm probe with a 60 mm case, 5.0 m lead and no approvals.

      Ask our team:

      Get a quick price for： 330851-02-000-060-50-00-00
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330851-02-000-060-50-00-00

      Technical specifications for 330851-02-000-060-50-00-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330851-02-000-060-50-00-00
      • Estimated shipping dimensions:
        23x23x4.5cm
      • Weight:
        0.54 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Product family:
        3300 XL 25 mm proximity transducer system
      • Probe thread:
        M30 x 2
      • Unthreaded length:
        0 mm
      • Overall case length:
        60 mm
      • Total probe length:
        5.0 m
      • Armor option:
        No armor
      • Approval option:
        No approvals
      • Linear range:
        12.7 mm (500 mils)
      • Scale factor:
        0.787 V/mm (20 mV/mil)
      • Frequency response:
        0 to 2.7 kHz
      • Recommended nominal gap:
        7.0 mm (275 mils)
      • Minimum target diameter:
        61 mm
      • Cable type:
        FluidLoc
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330851-02-000-060-50-00-00 is a 25 mm probe for the 3300 XL 25 mm proximity transducer system. It is an M30 x 2 unarmored 3300 XL 25 mm probe with a 60 mm case, 5.0 m lead and no approvals.
      • Probe thread: M30 x 2
      • Unthreaded length: 0 mm
      • Overall case length: 60 mm
      • Total probe length: 5.0 m

      330851-02-000-060-50-00-00 is documented as a 25 mm Probe within the 3300 XL 25 mm proximity transducer system.

      Use the complete model identity and published parameter set for integration, replacement and commissioning.

      Important Notice: Verify 330851-02-000-060-50-00-00, the M30 x 2 mounting, 60 mm case, 5.0 m matched system, target diameter and approval record before replacement.

      Bently Nevada 330851-02-000-060-50-00-00 Manuals & Downloads
      Bently Nevada 330851-02-000-060-50-00-00 Technical Reference (PDF)Bently Nevada 330851-02-000-060-50-00-00 Installation & Commissioning Guide (PDF)

      The first document presents exact-model technical and engineering data. The second provides a separate installation, connection, commissioning and acceptance workflow.

      Exact 25 mm Probe replacement
      Preserves the complete 330851-02-000-060-50-00-00 identity and published configuration.
      Documented system integration
      Uses the official product-family and interface values for the installed system.
      Commissioning verification
      Checks the exact electrical, mechanical and signal parameters before release.
      Maintenance diagnostics
      Supports controlled troubleshooting while retaining the as-found installation record.
      Read the applicable Bently Nevada instructions before work. Verify 330851-02-000-060-50-00-00 and every installed interface before isolation, wiring or commissioning.
      1
      Confirm the complete 330851-02-000-060-50-00-00 marking before work.
      2
      Isolate the installed system and document the maintenance state.
      3
      Verify probe thread: M30 x 2.
      4
      Verify unthreaded length: 0 mm.
      5
      Verify overall case length: 60 mm.
      6
      Verify total probe length: 5.0 m.
      7
      Protect connectors, wiring and exposed interfaces from damage or contamination.
      8
      Complete a controlled functional test and retain the final acceptance record.

      Technical notes

      Technical notes

      Verify 330851-02-000-060-50-00-00, the M30 x 2 mounting, 60 mm case, 5.0 m matched system, target diameter and approval record before replacement.

      FAQS

      • Which mounting profile must match Bently Nevada 330851-02-000-060-50-00-00?
        The probe uses an M30 x 2 thread, no unthreaded section, and a 60 mm overall case; all three details control its installed position.
      • How should the 5.0 m FluidLoc lead be protected on Bently Nevada 330851-02-000-060-50-00-00?
        Route the unarmored lead away from abrasion and strain, preserve its bend radius, and keep the coaxial interface sealed and clean.
      • What does the final 00 option mean for Bently Nevada 330851-02-000-060-50-00-00?
        It specifies no approval option, so this exact probe must not be placed where the project requires the separately approved 05 variant.
      • What target surface is needed for the 330851-02-000-060-50-00-00 probe?
        Use the documented conductive target with at least 61 mm diameter and maintain the engineered alignment throughout the measurement travel.
      • How much linear displacement can this 25 mm system cover?
        The matched probe and Proximitor Sensor provide a 12.7 mm (500 mil) linear range.
      • Where should Bently Nevada 330851-02-000-060-50-00-00 be initially gapped?
        Begin near the 7.0 mm (275 mil) nominal gap, then refine the setting using stable voltage and the required travel window.
      • Which sensitivity confirms correct pairing of the unapproved 25 mm probe?
        A controlled displacement should produce 0.787 V/mm (20 mV/mil) through the usable range.
      • What final motion test should follow installation of Bently Nevada 330851-02-000-060-50-00-00?
        Sweep the required travel and confirm linearity, direction, nominal gap, stable signal, and the assigned monitor alarms.
