1794-OV32

FLEX I/O Digital Sinking Output Module
Allen-Bradley 1794-OV32
Allen-Bradley 1794-OV32
Allen-Bradley 1794-OV32
Allen-Bradley 1794-OV32
Allen-Bradley 1794-OV32
Allen-Bradley 1794-OV32
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

FLEX I/O Digital Sinking Output Module
Digital Output Modules
RIUP - Removal and
Insertion Under Power
Get a quick price for 1794-OV32
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 1

    Requirement review

    We review the part number, quantity and delivery requirements and ask for any missing details.
  • 2

    Quotation and availability

    We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
  • 3

    Order confirmation and dispatch

    Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 1794-OV32

  • Manufacturer:
    Allen-Bradley
  • Product Category:
    PLC Systems
  • Spare Part Number:
    1794-OV32
  • Estimated shipping dimensions:
    10.2x5.1x5.1cm
  • Weight:
    0.1 kg
  • Tariff Code:
    8537101190
  • Counliy of origin:
    USA
  • Number of outputs:
    32, current, sinking
  • Output voltage, min:
    10V DC
  • Output voltage, nom:
    24V DC
  • Output voltage, max:
    31.2V DC
  • On-state current:
    1.0 mA min per channel 500 mA max per channel
  • Surge current:
    2 A for 50 ms each, repeatable every 2 seconds
  • Off-state leakage, max:
    0.5 mA
  • Flexbus current:
    110 mA @ 5V DC
  • Power dissipation, max:
    4.4 W @ 31.2V DC

Information

Overview Manuals Common Applications Product Precautions
The 1794-OV32 is a high-density digital output module. Its core design philosophy is "flexibility and structure," and it is mainly used in the entire control system to receive logic instructions from the PLC and drive DC loads in the field.
    • High Density
    • Modular Design
    • Industrial Durability
 The Allen-Bradley FLEX I/O system offers a flexible, modular, and cost-effective solution for your industrial automation and control. The space saving design offers rack based I/O functionality of up to eight modules and provides digital, analogue, HART analogue, and specialty I/O with 4...32 points per module with flexible mounting and wiring options.FLEXI/O is a Distributed I/O System that connects to several Networks including EtherNet/IP, ControlNet and DeviceNet. Flexible, low-cost, modular I/O for distributed applications. FLEX I/O offers all the functions of larger, rack-based I/O without the space requirements. Independently select the I/O, termination style, and network to meet your application needs.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
 Allen Bradley 1794-OV32 FLEX I/O Digital Sinking Output Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Pulp & Paper
Controls numerous nozzle solenoid valves in the dry and wet ends of paper machines.

Power & Energy
Drives isolation valves and status feedback signals in auxiliary workshops (e.g.,coal handling,ash removal).

Automotive Assembly
Controls cylinder solenoid valves and fixture positioners on body-in-white welding lines.

Water & Wastewater
Controls dosing pump starts/stops and filter backwash valves in distributed control cabinets.

Food & Beverage
Manages gate operations and conveyor status pilot lights on filling lines.

Semiconductor Equipment
Controls vacuum valves and cooling water switches in auxiliary systems of wafer processing equipment.

 When using the 1794-OV32, prioritize its sinking output characteristics by ensuring correct load wiring polarity, and strictly limit both per-channel and total module current (4A) to prevent overheating. During physical installation, ensure the module is fully locked onto the terminal base and exercise caution during Removal and Insertion Under Power to avoid electrical arcing. Furthermore, given its high-density 32-point design, maintain proper heat dissipation and ventilation within the enclosure, while periodically checking the stability of the external 24V DC power supply to ensure logical reliability under heavy loads.

FAQ View All FAQ

  • What is 1794-OV32?
    It is a high-density digital (discrete) output module from the Allen-Bradley FLEX I/O family, used to drive field devices based on controller commands.
  • How to use the 1794-OV32?
    It is used by snapping it onto a compatible FLEX I/O Terminal Base (e.g., 1794-TB32). It then connects to a PLC via a communication adapter (like Ethernet or ControlNet).
  • What is the current capacity per channel for 1794-OV32?
    Each channel supports a maximum current of 0.5A. If your load exceeds this value, an interposing relay may be required to protect the module.
  • How to check 1794-OV32 status via indicators?
    There are multiple yellow LEDs on the front of the module. A lit LED means the channel output is ON, and an unlit LED means it is OFF.
  • Which terminal base should be used with 1794-OV32?
    Since it is a 32-point module, it is typically used with the 1794-TB32 or 1794-TB32S terminal base to provide sufficient wiring terminals.
