1794-IV32

Digital Input Module
In Stock
Allen-Bradley 1794-IV32
Allen-Bradley 1794-IV32
Allen-Bradley 1794-IV32
Allen-Bradley 1794-IV32
Allen-Bradley 1794-IV32
Allen-Bradley 1794-IV32
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

Digital Input Module

24 VDC Discrete input module

32 yellow status indicator

Overvoltage Category II

Get a quick price for 1794-IV32
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 1

    Requirement review

    We review the part number, quantity and delivery requirements and ask for any missing details.
  • 2

    Quotation and availability

    We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
  • 3

    Order confirmation and dispatch

    Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 1794-IV32

  • Manufacturer:
    Allen-Bradley
  • Product Category:
    PLC Systems
  • Spare Part Number:
    1794-IV32
  • Estimated shipping dimensions:
    10.2x7.6x5.1cm
  • Weight:
    0.1 kg
  • Tariff Code:
    8537101190
  • Counliy of origin:
    USA
  • No. of Channels:
    thirty-Two (32)
  • No. of Inputs:
    Thirty-Two (32)
  • Maximum pollution level:
    Pollution Degree 2
  • Wiring configuration:
    Source wiring
  • Minimum On-state voltage:
    19.2 VDC
  • Mounting base:
    1794 Mounting Base

Information

Overview Manuals Common Applications Product Precautions
The 1794-IV32 is a 24V DC high-density sourcing digital input module. It is primarily used to detect switching signals in industrial environments and transmit these signals to a PLC controller.
    • Sourcing Input Design
    • Flexible Modular Structure
    • Real-Time Status Monitoring
The Allen-Bradley FLEX I/O system offers a flexible, modular, and cost-effective solution for your industrial automation and control. Its space-saving design delivers rack-based I/O functionality for up to eight modules per assembly, covering a comprehensive range of Digital, Analogue, HART Analogue, and Specialty I/O with 4 to 32 points per module.A key advantage is its decoupled architecture, which separates field wiring from the logic module via various Terminal Base options, allowing for module replacement without disturbing existing wiring. Furthermore, the system supports RIUP, significantly enhancing system uptime and maintenance efficiency. With broad compatibility across major industrial networks including EtherNet/IP, ControlNet, and DeviceNet, FLEX I/O seamlessly integrates into applications ranging from simple machine control to complex distributed process environments, helping you reduce installation costs while maximizing overall system versatility.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
 Allen Bradley 1794-IV32 Digital Input Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Food Processing & Sterilization
Collects safety door locking limits for retorts, container/bottle counting pulses on conveyors, and valve position feedback from Clean-In-Place (CIP) systems.

Automotive Welding & Assembly
Detailed monitoring of sensing for welding fixture position, locking, and unclamping, while collecting start button and safety light curtain signals from multiple manual operator stations.

Water Treatment & Water Reuse
Receives operational limits for bar screens, multiple high/low pool level float switch signals, and overheat protection contacts for multiple pump motors.

Printing & Converting
Monitors high-speed color mark detection signals, full-roll sensors in the rewinding section, and web tension limit switches in the unwinding section.

Cement & Building Materials Production
Monitors numerous lubricant level switches, bearing temperature limit switches, and conveyor limit feedbacks in raw meal mill and rotary kiln systems.

 When using the 1794-IV32, prioritize its sourcing input characteristics by ensuring sensors are sinking (NPN) output to match the current flow. Given its 32-point high-density design, it must be used with 1794-TB32 terminal bases, and proper ventilation within the enclosure is critical to prevent heat accumulation. While the module supports Removal and Insertion Under Power (RIUP), always ensure it is securely locked onto the base. Additionally, maintain a stable external 24V DC power supply to guarantee sufficient drive current for all input channels at logic-high levels (minimum 10V DC).

FAQ View All FAQ

  • What is 1794-IV32?
    It is a Digital Input Module in the Allen-Bradley FLEX I/O series. It is specifically designed to receive 24V DC switching signals from field devices (like pushbuttons and sensors) and transmit them to the PLC.
  • How to use products like 1794-IV32?
    You need to install it onto a compatible Terminal Base (e.g., 1794-TB32), then connect it to the PLC host via a Network Adapter (e.g., Ethernet adapter) and configure the address in the software.
  • What is the operating voltage range of 1794-IV32?
    The nominal voltage is 24V DC. The actual allowable operating range is typically between 10V DC and 31.2V DC.
  • What is the purpose of the LED indicators on 1794-IV32?
    The yellow LEDs on the panel are used to display the ON/OFF status of the 32 channels. A lit LED indicates a signal input (ON), while an unlit LED indicates no signal (OFF).
  • How does 1794-IV32 reduce maintenance costs?
    Through its modular design, when a module fails, only the unit itself needs to be swapped out without removing the existing wiring, greatly reducing repair time.
