How many ControlNet ports does the 1756-CN2R have?

The 1756-CN2R has dual ControlNet communication interface.

What is the appropriate ControlNet cable used by the 1756-CN2R?

The 1756-CN2R requires use of 1786-RG6 quad shield RG6 coaxial cable.

What are compatible chassis for installations of the 1756-CN2R?

Compatible ControlLogix chassis are 1756-A4, 1756-A7, 1756-A10, 1756-A13 and 1756-A17.

Does the 1756-CN2R support redundant ControlNet topology?

Yes. The 1756-CN2R support redundant ControlNet network.

How many slots f the chassis does this module occupy?

The 1756-CN2R is a single slot module.

What is the maximum number of ControlLogix connection does this module support?

Up to 128 Logix connections is supported by the 1756-CN2R.

Product image is representative; revision or series may vary. Contact us to request a specific version.

1756-CN2R

MUNICATION MODULE

In Stock

Product Describe：

1756-CN2R
COMMUNICATION MODULE
CONTROLLOGIX
1300 MA AT 5.1 VDC
A/B to backplane
970 mA at 5.1 VDC
1.7 mA at 24 VDC
30 V (Continuous)

Ask our team:

Phone:
+86 180 3023 5313
E-Mail:
sales13@apterpower.com

Get a quick price for： 1756-CN2R

Quantity*

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy.

Technical specifications FAQ

Technical specifications for 1756-CN2R

Manufacturer:

Allen-Bradley
Product Category:

PLC Systems
Spare Part Number:

1756CN2R
Estimated shipping dimensions:

14x13.2x3.5cm
Weight:

0.25 kg
Tariff Code:

8537101190
Counliy of origin:

USA
Maximum Connections:

131
Communication Port:

Two (2) ControlNet; One (1) USB
ControlNet Data Transfer speed:

5 Mbps
Input Current:

1300 milliamps at 5.1 Volts DC, 3 milliamps at 24 Volts DC
Power Dissipation:

6.7 Watts
Backplane current:

1.3 A at 5.1 VDC; 3 mA at 24VDC
Thermal dissipation:

21.28 BTU/hr

Ask for Quote

FAQS

How many ControlNet ports does the 1756-CN2R have?

The 1756-CN2R has dual ControlNet communication interface.
What is the appropriate ControlNet cable used by the 1756-CN2R?

The 1756-CN2R requires use of 1786-RG6 quad shield RG6 coaxial cable.
What are compatible chassis for installations of the 1756-CN2R?

Compatible ControlLogix chassis are 1756-A4, 1756-A7, 1756-A10, 1756-A13 and 1756-A17.
Does the 1756-CN2R support redundant ControlNet topology?

Yes. The 1756-CN2R support redundant ControlNet network.
How many slots f the chassis does this module occupy?

The 1756-CN2R is a single slot module.
What is the maximum number of ControlLogix connection does this module support?

Up to 128 Logix connections is supported by the 1756-CN2R.
