The 8V1090.001-2 is a member of B&R's modular ACOPOS family, primarily used to execute motion trajectories, synchronous control, and position allocation within multi-axis linkage systems. Regarding its hardware configuration, the 8V1090.001-2 integrates a line filter and a braking resistor internally. This single-unit hardware construction eliminates the need to install bulky external filtering units and separate heat-dissipating resistors inside the electrical control cabinet.
Modular mechanical design using plug-in modules
All connections are made using plug-in connectors
Partially-coated circuit boards - more robust in regard to environmental influences
The internal printed circuit boards of the 8V1090.001-2 utilize a partial conformal coating insulation process. This physical protective layer is specifically applied to block non-conductive dust, high-humidity oil mist, moisture, and chemical residues from directly corroding the electronic circuits. In dusty, humidity-variable industrial workshops, the coating establishes a physical barrier for the drive's core internal hardware, preventing circuit board short circuits or corrosion caused by external debris accumulation. This extends the actual service life of the equipment and ensures the drive maintains a continuous operational state in fluid, challenging industrial sites.
The 8V1090.001-2 features four dedicated hardware plug-in slots on its front panel, providing modular functionality expansion. Without changing the drive's main controller unit, the factory can insert corresponding functional expansion modules based on specific machine tool or production line architectures to make it compatible with CAN bus interfaces, the POWERLINK real-time Ethernet protocol, or mainstream high-resolution encoder feedback signals like EnDat and BiSS. This provides the necessary conditions for long-term on-site upgrades and modifications.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
B&R 8V1090.001-2 ACOPOS servo drive Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Packaging Machinery Industry
Used to control film feeding, sealing, cutting, and multi-axis synchronous filling systems in Form-Fill-Seal (FFS) machines.
Lithium Battery Manufacturing Industry
Used for high-speed, high-precision coating, roller pressing, slitting, and multi-axis electronic gear synchronization in stacking/winding machines.
Photovoltaic and Semiconductor Industry
Drives ultra-precise XYZ positioning modules in wafer dicing machines, die bonders, and wafer handling systems.
Automotive Manufacturing Industry
Applied to joint drives of car body welding robots, as well as precision servo tightening and press-fit units on powertrain assembly lines.
Food and Beverage Industry
Controls electronic cam-based rotary sorting in high-speed bottling lines or pitch-control grouping systems in conveyors.
Pharmaceutical Machinery Industry
Used for high-precision fixed-length and quantitative dispensing control in capsule filling machines, blister packaging machines, and integrated bottling lines.
When using the 8V1090.001-2 servo drive, ensure safety by wiring only after complete power-off and DC bus discharge. Maintain good ventilation and prevent conductive dust inside the cabinet. Strictly use shielded cables and separate signal from power lines to avoid EMC interference. Finally, properly match motor parameters and back them up in time.
Operating on a three-phase 400–480 VAC main supply with a continuous current draw of 8.8 A, the 8V1090.001-2 requires specific adjustment of its UDC_NOMINAL parameter whenever it is hooked up to a 230 VAC network. For field protection, the drive must be grounded directly to a low-inductance PE rail.
The 8V1090.001-2 is an industrial-grade, all-digital AC servo drive from B&R's ACOPOS 1090 series, primarily used to drive medium-to-high power three-phase AC servo motors.
What is the main difference between the 8V1090.001-2 and the 8V1022.001-2 in the same series?
The core difference lies in their power and current ratings. The 8V1090.001-2 offers a continuous current of 22A, whereas the 8V1022.001-2 provides only 2.2A, making the 8V1090 suitable for driving larger torque and higher power motors.
What are the main industrial application industries for the 8V1090.001-2?
Due to its higher power, it is widely used in heavy-duty packaging machines, metal rolling and shearing equipment, large injection molding robots, printing press cylinder controls, and rubber tire building machines.
How to use a high-power drive like the 8V1090.001-2 in an industrial system?
Mount it vertically on the control cabinet wall, connect the three-phase high-voltage main power and 24V DC control power, attach the servo motor's heavy-duty power cable and encoder wire, and connect to the PLC via network plug-in cards.
What software does the 8V1090.001-2 rely on for configuration and programming?
It is fully integrated into B&R's Automation Studio software platform, which is used to configure motor parameters, adjust control loops, and perform fault diagnostics.
