Technical specifications for 6ES7315-2EG10-0AB0
-
Manufacturer:Siemens
-
Product Category:PLC Systems
-
Spare Part Number:6ES7315-2EG10-0AB0
-
Estimated shipping dimensions:4x12.2x12.4cm
-
Weight:0.3 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
CPU designation:CPU 315-2 PN/DP
-
Working memory:128 KB
-
Interface 1:MPI/DP, 12 Mbit/s
-
Interface 2:Ethernet PROFINET
-
Load memory:Micro Memory Card required
-
Supply voltage:24 V DC
-
Operating temperature:0 to 60 °C
-
Product lifecycle:Discontinued; successor 6ES7315-2EH14-0AB0
Information
Overview
Manuals
Common Applications
Product Precautions
6ES7315-2EG10-0AB0 combines S7-300 program execution, PROFIBUS/MPI coordination and PROFINET communication in a CPU 315-2 PN/DP.
- Executes the configured S7 control program
- Coordinates the installed distributed-I/O topology
- Maintains deterministic communication with configured automation peers
- Provides CPU and network diagnostic evidence for commissioning
The CPU works with an S7-300 mounting rail, power supply, signal modules and the configured PROFIBUS and PROFINET devices. Commissioning follows the documented S7-300 installation sequence and includes MMC compatibility, hardware configuration, address checks, diagnostic-buffer review and controlled I/O proof testing.
Important Notice: Confirm 6ES7315-2EG10-0AB0, CPU hardware and firmware, S7-300 rack and power supply, Micro Memory Card, MPI/DP and PROFINET topology, connector assignment, 24 V wiring, grounding, STEP 7 hardware configuration, project version, diagnostics and controlled output-test results before commissioning.
Apter Power 6ES7315-2EG10-0AB0 Manuals and Guides
- Apter Power 6ES7315-2EG10-0AB0 CPU and Network Technical Reference PDF
- Apter Power 6ES7315-2EG10-0AB0 S7-300 Migration and Acceptance Workbook PDF
The first document is the model-specific technical and system reference. The second is a distinct field workbook for installation, wiring, commissioning and acceptance records.
S7-300 process-control stations
Runs sequence, interlock and regulatory-control logic in a documented S7-300 station.
PROFINET machine coordination
Exchanges cyclic data with configured Ethernet-based automation devices.
PROFIBUS distributed-I/O systems
Coordinates DP devices through the configured MPI/DP interface.
Legacy CPU replacement projects
Restores a documented CPU 315-2 PN/DP station while preserving its validated project.
Read the applicable Siemens installation instructions before work. Verify 6ES7315-2EG10-0AB0, the installed host system and all configured field interfaces before isolation, wiring or commissioning.
1
Confirm the complete 6ES7315-2EG10-0AB0 marking, hardware release and rack position.
2
Place the machine and all controlled outputs in the approved maintenance state.
3
Archive the STEP 7 project, Micro Memory Card contents and diagnostic buffer.
4
Isolate the 24 V DC supply and record every front connector and network cable.
5
Use ESD controls and inspect the backplane and front connectors before installation.
6
Restore the exact MPI/DP, PROFINET, station-name and IP configuration.
7
Verify every configured distributed-I/O station and communication peer.
8
Complete controlled input, output, interlock and restart tests before release.
Technical notes
Install 6ES7315-2EG10-0AB0 in the documented S7-300 rack position with the required Micro Memory Card and 24 V DC supply. Before replacement, archive the STEP 7 project, MPI/DP and PROFINET identities and diagnostic buffer; after startup, verify distributed I/O, network peers and controlled process outputs.
FAQ View All FAQ
-
What exact function does 6ES7315-2EG10-0AB0 perform as a SIMATIC S7-300 CPU 315-2 PN/DP?It executes the S7 program and coordinates the documented MPI/DP and PROFINET interfaces.
-
Which host system must be confirmed before installing 6ES7315-2EG10-0AB0?Confirm the documented Siemens SIMATIC S7-300 host and the complete 6ES7315-2EG10-0AB0 marking before work.
-
Which connection checks are required for 6ES7315-2EG10-0AB0?Verify the S7-300 backplane, 24 V supply, front connectors and both communication interfaces.
-
How should the installed configuration for 6ES7315-2EG10-0AB0 be preserved?Restore the validated STEP 7 hardware configuration, station identity and network parameters.
-
Which diagnostic evidence should be reviewed for 6ES7315-2EG10-0AB0?Review the diagnostic buffer, DP station state, PROFINET device state and module diagnostics.
-
What must be recorded before replacing 6ES7315-2EG10-0AB0?Record the complete order number, hardware and firmware versions, MMC, rack slot, network addresses and diagnostic baseline.
-
How should 6ES7315-2EG10-0AB0 be commissioned after installation?Power up in the approved sequence, verify all configured peers, then prove inputs, outputs and interlocks.
-
Which model-specific limitation applies to 6ES7315-2EG10-0AB0?The module requires a compatible Micro Memory Card and the successor CPU must not be treated as an identical drop-in without migration validation.
