Technical specifications for BMXP341000
-
Manufacturer:Schneider Electric
-
Product Category:PLC Systems
-
Spare Part Number:BMXP341000
-
Estimated shipping dimensions:3.1x10.5x10.2cm
-
Weight:0.2 kg
-
Tariff Code:8537101190
-
Counliy of origin:France
-
Racks:2
-
Discrete I/O capacity:512
-
Analog I/O capacity:128
-
Application-specific channels:20
-
Serial protocol:Modbus RTU/ASCII master or slave
-
Serial physical layers:RS232C and RS485
-
Serial rate:0.3 to 19.2 kbit/s
-
USB rate:12 Mbit/s
-
Communication modules:Up to 2 Ethernet or 2 AS-Interface modules
-
Modbus addresses:0 to 248
-
Internal RAM:2 MB
-
Program storage:Memory card support
Information
Overview
Manuals
Common Applications
Product Precautions
Schneider Electric BMXP341000 coordinates an M340 control application through its USB and configurable RS232/RS485 serial interfaces.
- Archive the complete M340 application and data.
- Record serial protocol, physical layer, address and baud rate.
- Retain the two-rack module inventory and channel allocation.
- Preserve memory-card identity and contents.
The processor executes the M340 application, coordinates two racks and exchanges data over its configured serial and USB services. Rack inventory, project revision, memory card and communication settings form one controlled baseline.
Important Notice: BMXP341000 serial parameters and physical layer must match the installed network; restore the exact project, memory card and two-rack configuration.
Schneider Electric BMXP341000 Manuals & Downloads
Schneider Electric BMXP341000 Technical Reference (PDF)Schneider Electric BMXP341000 Official Manual Excerpt (PDF)The technical reference presents exact-model engineering data and maintenance boundaries. The official excerpt contains selected unchanged Schneider Electric source pages for this exact model or its documented product family.
M340 machine control
Executes the validated application across two racks.
Modbus serial integration
Communicates over configured RS232 or RS485 links.
Mixed I/O coordination
Supports the documented discrete and analog capacity.
Processor renewal
Restores project, memory card and serial settings together.
Schneider Electric BMXP341000 installation checks: verify exact identity, retain configuration evidence and record the complete functional acceptance.
1
Verify the complete Schneider Electric BMXP341000 marking before any selection or field work.
2
Record the installed position, connectors, conductors and configuration assigned to BMXP341000.
3
Place the connected equipment in its approved safe state and isolate all relevant energy sources.
4
Protect the plc processor and its mating interfaces from contamination, static discharge and mechanical damage.
5
Back up the project and identify the installed memory card.
6
Record both racks and all application-specific channels.
7
Label the serial cable and capture protocol, address and baud rate.
8
Verify rack diagnostics, serial exchange and process response after startup.
Technical notes
BMXP341000 serial parameters and physical layer must match the installed network; restore the exact project, memory card and two-rack configuration.
FAQ View All FAQ
-
How many racks are documented for Schneider Electric BMXP341000?The manufacturer record for BMXP341000 specifies 2. Preserve it through selection, installation and acceptance.
-
How does Schneider Electric define the discrete i/o capacity of BMXP341000?Schneider Electric identifies the discrete i/o capacity as 512; keep that exact entry in the BMXP341000 record.
-
What manufacturer value is recorded for BMXP341000 analog i/o capacity?The published BMXP341000 value is 128. The installed configuration must remain within that boundary.
-
How many application-specific channels are documented for Schneider Electric BMXP341000?For BMXP341000, the manufacturer states 20. Do not replace it with a nearby suffix value.
-
Which serial protocol must be retained for Schneider Electric BMXP341000?Record Modbus RTU/ASCII master or slave for BMXP341000 and verify the field arrangement against the controlled drawing or project.
-
How does Schneider Electric define the serial physical layers of BMXP341000?The exact-model source gives RS232C and RS485. Use it together with the actual BMXP341000 nameplate and installation record.
-
What serial rate rating is specified for Schneider Electric BMXP341000?BMXP341000 is documented with 0.3 to 19.2 kbit/s; this value belongs to the verified product configuration.
-
What usb rate rating is specified for Schneider Electric BMXP341000?Use 12 Mbit/s as the BMXP341000 usb rate reference and resolve any field discrepancy before release.
