Product image is representative; revision or series may vary. Contact us to request a specific version.
Get a quick price for 140CPU65150C
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 140CPU65150C
-
Manufacturer:Schneider Electric
-
Product Category:PLC Systems
-
Spare Part Number:140CPU65150C
-
Estimated shipping dimensions:8x13x25cm
-
Weight:1.2 kg
-
Tariff Code:8537101190
-
Counliy of origin:France
-
Processor class:Unity processor; conformal coated
-
Clock frequency:166 MHz
-
Internal memory:768 kB
-
Local racks:2
-
Distributed I/O stations:63 per Modbus Plus network
-
Remote I/O stations:31
-
Optional modules:Up to 6
-
Local Ethernet connections:Up to 6
-
Integrated USB:1
-
Integrated Modbus:RS232/485 Modbus or ASCII
-
Integrated Modbus Plus:1 local port
-
Application services:Time stamping, interrupts, serial link and counter
Information
Overview
Manuals
Common Applications
Product Precautions
Schneider Electric 140CPU65150C controls local, distributed and remote Quantum I/O from a two-local-rack Unity architecture.
- Back up the complete Unity application and retained data.
- Record both local racks and all remote/distributed station relationships.
- Preserve Ethernet, Modbus and Modbus Plus addresses.
- Keep the conformal-coated C suffix in the replacement identity.
The processor executes the Unity application and coordinates multiple Quantum I/O paths. Its C suffix, project revision, rack inventory and communication configuration must remain consistent across maintenance.
Important Notice: Retain the complete 140CPU65150C identifier, including the coated C suffix, and restore only the validated Unity project and communication baseline.
Schneider Electric 140CPU65150C Manuals & Downloads
Schneider Electric 140CPU65150C Technical Reference (PDF)Schneider Electric 140CPU65150C Official Manual Excerpt (PDF)The technical reference presents exact-model engineering data and maintenance boundaries. The official excerpt contains selected unchanged Schneider Electric source pages for this exact model or its documented product family.
Quantum PLC control
Runs the validated Unity application.
Distributed I/O management
Coordinates documented Modbus Plus stations.
Remote I/O management
Operates the approved S908 or Ethernet remote-I/O arrangement.
Coated processor renewal
Retains the exact C-suffix environmental execution.
Schneider Electric 140CPU65150C installation checks: verify exact identity, retain configuration evidence and record the complete functional acceptance.
1
Verify the complete Schneider Electric 140CPU65150C marking before any selection or field work.
2
Record the installed position, connectors, conductors and configuration assigned to 140CPU65150C.
3
Place the connected equipment in its approved safe state and isolate all relevant energy sources.
4
Protect the plc processor and its mating interfaces from contamination, static discharge and mechanical damage.
5
Create a verified backup of program, data and communication settings.
6
Record the complete rack and station inventory.
7
Confirm the coated C suffix on both removed and replacement processors.
8
Prove networks, I/O scans and the controlled sequence after restoration.
Technical notes
Retain the complete 140CPU65150C identifier, including the coated C suffix, and restore only the validated Unity project and communication baseline.
FAQ View All FAQ
-
What device identity or role does Schneider Electric 140CPU65150C publish?The exact-model source gives Unity processor; conformal coated. Use it together with the actual 140CPU65150C nameplate and installation record.
-
What clock frequency rating is specified for Schneider Electric 140CPU65150C?140CPU65150C is documented with 166 MHz; this value belongs to the verified product configuration.
-
When reviewing 140CPU65150C, what is the published internal memory?Use 768 kB as the 140CPU65150C internal memory reference and resolve any field discrepancy before release.
-
How many local racks are documented for Schneider Electric 140CPU65150C?The manufacturer record for 140CPU65150C specifies 2. Preserve it through selection, installation and acceptance.
-
How many distributed i/o stations are documented for Schneider Electric 140CPU65150C?Schneider Electric identifies the distributed i/o stations as 63 per Modbus Plus network; keep that exact entry in the 140CPU65150C record.
-
How many remote i/o stations are documented for Schneider Electric 140CPU65150C?The published 140CPU65150C value is 31. The installed configuration must remain within that boundary.
-
When reviewing 140CPU65150C, what is the published optional modules?For 140CPU65150C, the manufacturer states Up to 6. Do not replace it with a nearby suffix value.
-
Which local ethernet connections configuration belongs to Schneider Electric 140CPU65150C?Record Up to 6 for 140CPU65150C and verify the field arrangement against the controlled drawing or project.
