      Schneider Electric 140CRP93100
      Schneider Electric 140CRP93100
      Schneider Electric 140CRP93100
      Schneider Electric 140CRP93100
      Schneider Electric 140CRP93100
      Schneider Electric 140CRP93100
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      140CRP93100

      Modicon Quantum RIO Head-End Adapter Module
      In Stock
      Ships by Sunday, October 18
      Fast Shipping Available

      Product Describe：

      Schneider Electric 140CRP93100 is a Modicon Quantum remote-I/O head-end adapter with one channel and a single-cable connector. It links the controller to the documented coaxial RIO network.

      Ask our team:

      Get a quick price for： 140CRP93100
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 140CRP93100

      Technical specifications for 140CRP93100

      • Manufacturer:
        Schneider Electric
      • Product Category:
        PLC Systems
      • Spare Part Number:
        140CRP93100
      • Estimated shipping dimensions:
        5.1x10.2x25.4cm
      • Weight:
        0.3 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        France
      • Product designation:
        RIO head-end adapter module
      • Automation platform:
        Modicon Quantum
      • Remote-I/O channels:
        1
      • External connection:
        1 connector with single cable
      • Bus current required:
        600 mA
      • Power dissipation:
        3 W
      • Comparison reference:
        140CRP93200 provides two channels
      • System role:
        Quantum remote-I/O head-end communication
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Schneider Electric 140CRP93100 provides head-end communication between a Quantum controller and one documented remote-I/O coaxial channel in a documented Modicon Quantum installation.
      • Single-channel RIO head-end adapter
      • One connector for a single cable
      • 600 mA bus-current requirement
      • 3 W power dissipation

      The component remains matched to its documented cabinet position, power source, interfaces and approved engineering configuration. Commissioning restores that architecture and verifies the affected control or communication function under controlled conditions.

      Important Notice: Confirm 140CRP93100, its exact Modicon Quantum host, power source, installed position, interfaces, configuration, diagnostics and controlled acceptance evidence before release.

      Schneider Electric 140CRP93100 Manuals & Downloads

      These documents are different: the first consolidates exact product and system data; the second provides model-specific installation checks, commissioning steps and acceptance guidance.

      Quantum remote-I/O head end
      Connects the controller rack to the documented coaxial RIO network.
      Single-cable RIO architecture
      Maintains the one-channel topology assigned to the 140CRP93100.
      Legacy RIO replacement
      Restores the exact drop map, addressing and cable termination.
      RIO commissioning
      Verifies communication to every configured remote drop before release.
      Read the applicable Schneider Electric installation instructions before work. Verify 140CRP93100, the installed host system and all configured field interfaces before isolation, wiring or commissioning.
      1
      Confirm the complete 140CRP93100 marking and the documented Modicon Quantum RIO Head-End Adapter Module execution.
      2
      Place the machine, controller and affected process in the approved maintenance state.
      3
      Isolate all hazardous energy and prove the safe state before disconnecting hardware.
      4
      Record the installed position, every terminal or port, and the active engineering configuration.
      5
      Verify the exact electrical, interface and environmental limits in the manufacturer evidence.
      6
      Restore protective earth, shielding, wiring, communications and the approved project or parameters.
      7
      Energize under control and review all device, rack, network and process diagnostics.
      8
      Complete a controlled functional test of head-end communication between a Quantum controller and one documented remote-I/O coaxial channel before release.

      Technical notes

      Technical notes

      Install 140CRP93100 only in the documented Modicon Quantum position and preserve its exact wiring, interfaces and configuration. After controlled energization, verify diagnostics and head-end communication between a Quantum controller and one documented remote-I/O coaxial channel before service release.

      FAQS

      • How many remote-I/O channels does Schneider Electric 140CRP93100 provide?
        140CRP93100 provides one remote-I/O channel with one connector for a single cable.
      • What distinguishes 140CRP93100 from the 140CRP93200 RIO head-end module?
        The official Schneider Electric comparison identifies 140CRP93100 as the one-channel unit, while 140CRP93200 provides two channels.
      • What Quantum bus current must be reserved for 140CRP93100?
        Reserve 600 mA of Quantum backplane bus current for 140CRP93100.
      • How much power does 140CRP93100 dissipate in the rack?
        The official Schneider Electric FAQ specifies 3 W power dissipation for 140CRP93100.
      • Which cable architecture must be preserved when replacing 140CRP93100?
        Preserve the documented single-channel coaxial remote-I/O architecture, including the drop map and termination arrangement.
      • What should be recorded before removing 140CRP93100 from a Quantum rack?
        Record the slot, coaxial route, connector condition, remote-drop addresses and controller configuration before removal.
      • Which checks are required after energizing replacement 140CRP93100?
        Review module and network diagnostics, then verify communication with every configured remote-I/O drop.
      • When can a 140CRP93100 replacement be returned to service?
        Release it only after the exact model, one-channel topology, terminations, addressing and controlled remote-I/O response have been verified.
