      Schneider Electric 140XTS00200
      Schneider Electric 140XTS00200
      Schneider Electric 140XTS00200
      Schneider Electric 140XTS00200
      Schneider Electric 140XTS00200
      Schneider Electric 140XTS00200
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      140XTS00200

      Screw Terminal Block
      In Stock
      Ships by Sunday, October 18
      Fast Shipping Available

      Product Describe：

      Schneider Electric 140XTS00200 is the separately ordered 40-point screw terminal block used with compatible Modicon Quantum I/O modules.

      Ask our team:

      Get a quick price for： 140XTS00200
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 140XTS00200

      Technical specifications for 140XTS00200

      • Manufacturer:
        Schneider Electric
      • Product Category:
        PLC Systems
      • Spare Part Number:
        140XTS00200
      • Estimated shipping dimensions:
        20x4.5x4.3cm
      • Weight:
        0.2 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        France
      • Component type:
        Screw terminal block
      • Terminal count:
        40 points
      • Platform:
        Modicon Quantum
      • Ordering condition:
        Ordered separately from I/O module
      • Field interface:
        Removable screw connections
      • Door-label reference:
        31000207
      • Selection basis:
        Exact I/O module wiring diagram
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Schneider Electric 140XTS00200 provides the removable forty-point field-wiring interface for a documented Quantum module position.
      • 40-point terminal block
      • Screw-clamp field connections
      • Separately ordered Quantum accessory
      • Module-specific terminal assignment

      The terminal block carries field conductors to the installed Quantum module. Its safe use depends on the exact module wiring diagram, conductor labels, torque practice and separation of supply, common and signal circuits.

      Important Notice: 140XTS00200 is ordered separately from the Quantum I/O module. Confirm the exact module-terminal pairing and its wiring diagram before transferring conductors; the 40-point format alone does not prove compatibility.

      Schneider Electric 140XTS00200 Manuals & Downloads
      Schneider Electric 140XTS00200 Technical Reference (PDF)Schneider Electric 140XTS00200 Official Manual Excerpt (PDF)

      The technical reference is specific to 140XTS00200. The official Schneider Electric Quantum hardware manual directly lists 140XTS00200 and documents the terminal-block applications and module connections.

      Quantum field termination
      Connects field conductors to a compatible 40-point Quantum I/O module.
      Module replacement preparation
      Allows labeled wiring to remain organized during controlled I/O service.
      Cabinet wiring maintenance
      Provides accessible screw terminals for inspection and retorque under procedure.
      Terminal-block renewal
      Replaces the exact removable block while preserving conductor order and module pairing.
      Schneider Electric 140XTS00200 installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Confirm 140XTS00200 and the exact Quantum I/O module reference.
      2
      Place all connected field circuits in their approved safe state.
      3
      Photograph and label every conductor before loosening screws.
      4
      Record supply, common, shield and signal terminal assignments.
      5
      Remove rack and field power and verify absence of voltage.
      6
      Inspect the block, screws, conductor ends and mating connector.
      7
      Transfer one labeled conductor at a time using the module wiring diagram.
      8
      Torque, inspect and prove every affected field circuit before release.

      Technical notes

      Technical notes

      For 140XTS00200, retain the exact manufacturer identifier with the installed drawing, software or wiring baseline. Return the equipment to service only after the relevant diagnostics and model-specific field response have been recorded.

      FAQS

      • What is Schneider Electric 140XTS00200?
        It is a removable 40-point screw terminal block for compatible Modicon Quantum I/O modules.
      • Is Schneider Electric 140XTS00200 supplied with every Quantum I/O module?
        No. Schneider Electric states that this connector is ordered separately.
      • How is Schneider Electric 140XTS00200 selected?
        Match it to the exact I/O module documentation and terminal diagram, not only the connector shape.
      • What label is associated with Schneider Electric 140XTS00200?
        A Schneider Electric FAQ identifies 31000207 as the 40-point terminal-block door label.
      • What must be recorded before moving Schneider Electric 140XTS00200 wiring?
        Capture conductor labels, terminal numbers, supply and common groups, shields and the source drawing.
      • Can Schneider Electric 140XTS00200 wiring be transferred by color alone?
        No. Use positive conductor identification and the exact module wiring diagram.
      • What inspection applies to Schneider Electric 140XTS00200?
        Check screw condition, conductor preparation, contamination, damage and the mating connector before reuse.
      • How is Schneider Electric 140XTS00200 accepted?
        Verify torque and conductor placement, then prove every affected field circuit against the PLC or module indication.
