      Schneider Electric 140ARI03010
      Schneider Electric 140ARI03010
      Schneider Electric 140ARI03010
      Schneider Electric 140ARI03010
      Schneider Electric 140ARI03010
      Schneider Electric 140ARI03010
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      140ARI03010

      RTD Input Module
      In Stock
      Ships by Sunday, October 18
      Fast Shipping Available

      Product Describe：

      Schneider Electric 140ARI03010 is a Modicon Quantum analog input module with eight RTD channels for supported nickel and platinum resistance sensors.

      Ask our team:

      Get a quick price for： 140ARI03010
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 140ARI03010

      Technical specifications for 140ARI03010

      • Manufacturer:
        Schneider Electric
      • Product Category:
        PLC Systems
      • Spare Part Number:
        140ARI03010
      • Estimated shipping dimensions:
        31x16.5x5cm
      • Weight:
        0.45 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        France
      • Input count:
        8 analog channels
      • Sensor families:
        Ni/Pt 100, 200, 500 and 1000
      • Input type:
        Differential
      • Resolution:
        13 bits
      • Input impedance:
        >= 10 MOhm
      • Linearity error:
        +/-0.01% full scale; +/-0.5 degrees C
      • Bus current:
        200 mA
      • Power dissipation:
        1 W
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Schneider Electric 140ARI03010 converts eight supported RTD inputs into rack data for temperature monitoring and control.
      • Eight RTD input channels
      • Ni and Pt sensor support
      • 13-bit input resolution
      • Differential measurement inputs

      The module occupies a Quantum rack slot and receives field resistance measurements through its terminal block. Sensor type, wiring method, channel scaling and the PLC address map must all match the application design.

      Important Notice: For 3-wire or 4-wire RTDs the published maximum cable distance is 200 m. Two-wire use is limited by the accuracy acceptable to the application; document lead resistance and engineering approval.

      Schneider Electric 140ARI03010 Manuals & Downloads
      Schneider Electric 140ARI03010 Technical Reference (PDF)Schneider Electric 140ARI03010 Official Manual Excerpt (PDF)

      The technical reference is specific to 140ARI03010. The official Schneider Electric Quantum hardware manual directly lists 140ARI03010 and provides module configuration and wiring guidance.

      RTD temperature acquisition
      Reads supported nickel or platinum sensors on eight channels.
      Process temperature control
      Supplies scaled temperature values to the Quantum application.
      Condition monitoring
      Tracks machine or utility temperatures through the configured RTD ranges.
      Exact module renewal
      Restores channel type, wiring method and PLC mapping without borrowing another suffix.
      Schneider Electric 140ARI03010 installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Confirm 140ARI03010 and the installed terminal-block identity.
      2
      Place all affected temperature loops in the approved maintenance condition.
      3
      Record sensor type, channel range, scaling and alarm limits.
      4
      Identify two-, three- or four-wire field circuits before disconnection.
      5
      Remove rack and field power before module or terminal work.
      6
      Maintain shield, grounding and lead-resistance practices from the design.
      7
      Restore channel configuration and verify raw and engineering values.
      8
      Compare each channel with a known condition before returning control to service.

      Technical notes

      Technical notes

      For 140ARI03010, retain the exact manufacturer identifier with the installed drawing, software or wiring baseline. Return the equipment to service only after the relevant diagnostics and model-specific field response have been recorded.

      FAQS

      • How many inputs does Schneider Electric 140ARI03010 provide?
        It provides eight analog input channels for supported RTD sensors.
      • Which sensor materials does Schneider Electric 140ARI03010 support?
        The exact product page lists nickel and platinum RTDs in the supported 100, 200, 500 and 1000 ranges.
      • What is the Schneider Electric 140ARI03010 input resolution?
        Schneider Electric specifies 13-bit resolution.
      • How far can a three- or four-wire RTD be located from Schneider Electric 140ARI03010?
        The manufacturer FAQ gives a maximum cable distance of 200 m for three- and four-wire connections.
      • What limits a two-wire RTD on Schneider Electric 140ARI03010?
        Allowable lead resistance depends on the accuracy accepted by the application and must be engineered accordingly.
      • What configuration data must be retained for Schneider Electric 140ARI03010?
        Keep sensor type, channel range, scaling, alarm limits, wiring method and PLC address mapping.
      • What should be checked after installing Schneider Electric 140ARI03010?
        Review module diagnostics and compare each raw and scaled value with a known sensor condition.
      • Can Schneider Electric 140ARI03010C data be applied automatically to 140ARI03010?
        No. Preserve the complete exact identifier and do not transfer suffix-specific facts without exact evidence.
