      140DDI35310

      Discrete Input Module
      In Stock

      Product Describe：

      Schneider Electric 140DDI35310 is a Modicon Quantum 32-channel 24 V DC discrete input module arranged as four groups with negative, source-logic field behavior.

      Ask our team:

      Get a quick price for： 140DDI35310
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 140DDI35310

      Technical specifications for 140DDI35310

      • Manufacturer:
        Schneider Electric
      • Product Category:
        PLC Systems
      • Spare Part Number:
        140DDI35310
      • Estimated shipping dimensions:
        4.1x10.5x25cm
      • Weight:
        0.3 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        France
      • Input count:
        32
      • Signal:
        24 V DC
      • Logic:
        Negative / source
      • Groups:
        4 groups
      • I/O mapping:
        2 input words
      • Supply range:
        19.2 to 30 V DC
      • Response:
        1 ms maximum
      • Bus current:
        330 mA
      • Platform:
        Modicon Quantum
      • Operating temperature:
        0 to 60 degrees C
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Schneider Electric 140DDI35310 is a Modicon Quantum 32-channel 24 V DC discrete input module arranged as four groups with negative, source-logic field behavior.
      • Input count: 32
      • Signal: 24 V DC
      • Logic: Negative / source
      • Groups: 4 groups

      140DDI35310 operates only with the documented system configuration and connected hardware.

      Important Notice: Preserve field polarity, four group commons and the two-word controller map.

      Schneider Electric 140DDI35310 Manuals & Downloads
      140DDI35310 Technical Reference (PDF)140DDI35310 Manufacturer Datasheet (PDF)

      The first document presents model-specific technical and service content. The second preserves the unchanged manufacturer product data.

      High-density DC inputs
      Acquires thirty-two 24 V DC points in a Quantum rack.
      Grouped field circuits
      Retains the four documented groups and their common wiring.
      Fast status capture
      Uses the published maximum input response for deterministic panel logic.
      Exact module renewal
      Preserves the two-word map and negative-logic field identity.
      Read the applicable Schneider Electric instructions before work. Verify 140DDI35310, the installed system and every configured interface before isolation, wiring or commissioning.
      1
      Confirm the complete Schneider Electric 140DDI35310 identity and installed position before work.
      2
      Place the connected machine or process in the approved maintenance state.
      3
      Isolate every documented supply and field circuit before disconnection.
      4
      Record terminal, cable, shield, network and companion-hardware identities.
      5
      Retain input count and signal requirements from the installed design.
      6
      Protect connectors, electronics and keyed interfaces from contamination or damage.
      7
      Restore power in the approved sequence and review diagnostics.
      8
      Prove the intended 32-channel 24 v dc negative-logic discrete input module response and retain the acceptance record.

      Technical notes

      Technical notes

      Preserve field polarity, four group commons and the two-word controller map.

      FAQS

      • What distinguishes 140DDI35310 from a positive-logic input?
        Its field circuit is documented as negative/source logic; polarity must match the installed design.
      • How are the 32 inputs grouped?
        The module uses four groups and maps its states into two input words.
      • What supply window applies?
        The field supply range is 19.2 to 30 V DC.
      • How quickly does an input respond?
        The maximum response is 1 ms under the documented conditions.
      • What should be labelled before removal?
        Label every terminal, group common, cable and controller address before disconnecting the module.
      • Is 140DDI35300 interchangeable?
        No interchangeability claim is made; confirm the complete 140DDI35310 order identity.
