With more than 30.000 high-quality spare parts, they can be sold immediately. Our large inventory allows us to quickly meet customer needs, thereby reducing downtime and protecting production schedules. Our timely delivery time provides you with security and save money.
The 114M5335-01 is a low-voltage DC power supply module in the Bentley Nevada 3500/15 series mechanical condition monitoring and protection system.
LVDC Power Supply Module
Low Voltage DC Power Supply
Standard 24 Vdc Industrial Supply
The Bently Nevada 3500/15 AC and DC Power Supplies are half-height modules and must be installed in designated slots on the left side of the rack. The 3500 rack can contain one or two power supplies with any combinations of AC and DC. Either supply can power a full rack. When two power supplies are installed in a rack, the one in the lower slot acts as the primary supply, and the other in the upper slot acts as the backup supply. If installed, the second supply is the backup for the primary one. Removing or inserting either power supply module does not disrupt operation of the rack as long as a second power supply is installed. The 3500/15 AC and DC Power Supplies accepts a wide range of input voltages and converts them to voltages acceptable for use by other 3500 modules. Specifically, the 114M5335-01 is the Low Voltage DC Power Input Module (PIM) for this system, providing the interface for a 20 to 30 Vdc input range.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 114M5335-01 Low Voltage DC PIM Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Oil & Gas
Providing DC power entry for compressor monitoring systems on offshore platforms equipped with battery banks.
Nuclear Power
Serving as the physical wiring interface for independent DC supply loops in redundant power configurations.
Steel & Metallurgy
Providing fused DC input for high-reliability vibration protection systems of blast furnace blowers.
Thermal Power
Providing 24V DC terminal connections for protection devices of turbine bypass systems and emergency oil pumps.
Chemical Industry
Providing LVDC (Low Voltage DC) entry for monitoring systems of critical agitators or reactors in production lines.
Pulp & Paper
Ensuring electrical isolation and secure termination for DC power lines in high-temperature paper machine sections.
When using the 114M5335-01, ensure the input voltage strictly matches the 20-30 Vdc specification and follow the correct polarity for wiring. During installation, keep terminal screws tightened to prevent heating or power drops caused by poor contact, and periodically inspect the status of the internal fuses. Before performing any maintenance, ensure the external DC source is de-energized or the system is secured via a redundant power supply.
114M5335-01 is the Power Input Module (PIM) for the power supply system.
What is the main function of the 114M5335-01?
Its primary function is to serve as the physical interface for external 24V DC power cables, transferring electricity to the front-mounted power supply module (such as the 114M5330-01) while providing initial circuit protection.
How to wire the 114M5335-01?
It features a screw-type terminal block. Users must secure the external DC cables to the terminals according to the correct polarity (Positive +, Negative -, and Ground GND).
How to configure redundancy for the 114M5335-01?
Redundancy is achieved by installing two 114M5335-01 modules (upper and lower). Each module receives an independent DC power feed to ensure dual-source redundancy.
What happens if the polarity of the 114M5335-01 is reversed?
The module has some reverse-polarity protection, but it will prevent the system from starting. Prolonged reversal may damage internal components.
