Product image is representative; revision or series may vary. Contact us to request a specific version.
Get a quick price for 330905-00-10-10-02-00
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for 330905-00-10-10-02-00
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:330905-00-10-10-02-00
-
Estimated shipping dimensions:2x1.6x125cm
-
Weight:0.08 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Thread:M10 x 1
-
Lead armor:No
-
Unthreaded length:0 mm
-
Overall case length:100 mm
-
Total length:1.0 m
-
Connector and cable:ClickLoc connector; standard cable
-
Measurement:Relative vibration or position within the NSv system boundary
-
Matched electronics:Use a compatible NSv Proximitor or documented transmitter
-
Field modification:Do not splice or shorten the lead
-
Acceptance:Verify static gap and dynamic response
-
Probe construction:M10 x 1 NSv probe without armor
-
Signal-chain role:Compact non-contact displacement sensing element
Information
Overview
Manuals
Common Applications
Product Precautions
Bently Nevada 330905-00-10-10-02-00 provides a documented nsv proximity probe function within its intended control or monitoring system.
- Uses the 330905 M10 x 1 no-armor NSv probe family.
- Combines 0 mm unthreaded length with a 100 mm overall case.
- Provides a 1.0 m standard lead with ClickLoc termination.
- Operates only in a compatible, electrically matched NSv signal chain.
The NSv probe, extension cable and signal-conditioning electronics must match the documented system length and scale. Mechanical installation and electrical commissioning are therefore verified as one chain.
Important Notice: Verify the complete 330905-00-10-10-02-00 identity, mating hardware and controlled system procedure before installation.
Bently Nevada 330905-00-10-10-02-00 Manuals & Downloads
Official 3300 NSv System Datasheet Excerpt (PDF)Bently Nevada 330905-00-10-10-02-00 Installation & Commissioning Guide (PDF)
The Technical Reference organizes the exact ordering identity, applicable characteristics and system boundary for this nsv proximity probe. The Installation & Commissioning Guide covers identification, pre-installation checks, connections, functional verification and the acceptance record.
Axial position
Measure shaft position where the compact NSv probe is specified.
Relative vibration
Observe shaft motion at a qualified NSv installation point.
991 transmitter input
Provide the compatible transducer signal for a documented 991 thrust transmitter arrangement.
Machine monitoring
Feed the matched NSv signal to the designated monitoring channel.
Use the complete Bently Nevada 330905-00-10-10-02-00 identity and the applicable controlled procedure before work.
1
Verify the complete 330905-00-10-10-02-00 identifier before replacing another NSv probe.
2
Confirm the M10 x 1 machine thread and 100 mm case envelope.
3
Check the 0 mm unthreaded section against the mounting bracket.
4
Match the 1.0 m lead with the NSv extension cable and signal conditioner.
5
Protect the ClickLoc connection from moisture, dirt and side load.
6
Do not twist, splice or shorten the calibrated lead.
7
Set gap using the matched NSv system response and machine procedure.
8
Verify gap voltage, OK state and approved dynamic response before release.
Technical notes
Verify the complete 330905-00-10-10-02-00 identity, mating hardware and controlled system procedure before installation.
FAQ View All FAQ
-
Which family includes Bently Nevada 330905-00-10-10-02-00?It belongs to the 3300 NSv proximity transducer family.
-
Which thread is used on Bently Nevada 330905-00-10-10-02-00?The probe case uses an M10 x 1 thread.
-
Is Bently Nevada 330905-00-10-10-02-00 armored?No. The 330905 execution is supplied without armor.
-
What mechanical lengths belong to Bently Nevada 330905-00-10-10-02-00?It has 0 mm unthreaded length and a 100 mm overall case.
-
What lead is selected on Bently Nevada 330905-00-10-10-02-00?The code selects a 1.0 m standard lead with ClickLoc termination.
-
Can Bently Nevada 330905-00-10-10-02-00 be used with any Proximitor?No. Use a compatible NSv signal-conditioning arrangement with the correct electrical length.
-
Can the lead of Bently Nevada 330905-00-10-10-02-00 be shortened?No. Do not splice or shorten the calibrated lead.
-
What confirms commissioning of Bently Nevada 330905-00-10-10-02-00?Verify the matched NSv chain, static gap, OK state and approved dynamic response.
