      Bently Nevada 330173-00-04-10-02-00
      Bently Nevada 330173-00-04-10-02-00
      Bently Nevada 330173-00-04-10-02-00
      Bently Nevada 330173-00-04-10-02-00
      Bently Nevada 330173-00-04-10-02-00
      Bently Nevada 330173-00-04-10-02-00
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330173-00-04-10-02-00

      Proximity Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330173-00-04-10-02-00 is an unarmored M8 x 1 3300 5 mm proximity probe with a 40 mm case and 1.0 m standard cable. It connects to a matched 3300 XL extension cable and Proximitor Sensor for non-contacting vibration or position measurement.

      Ask our team:

      Get a quick price for： 330173-00-04-10-02-00
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330173-00-04-10-02-00

      Technical specifications for 330173-00-04-10-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330173-00-04-10-02-00
      • Estimated shipping dimensions:
        118x1.3x1.3cm
      • Weight:
        0.04 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe family:
        3300 5 mm
      • Base model:
        330173
      • Mounting thread:
        M8 x 1
      • Armor:
        Without armor
      • Unthreaded length:
        0 mm
      • Overall case length:
        40 mm
      • Total probe length:
        1.0 m (3.3 ft)
      • Connector:
        Miniature coaxial ClickLoc
      • Connector protector:
        Not included
      • Cable type:
        Standard cable
      • Agency approval option:
        No approvals
      • Probe tip diameter:
        5.2 mm
      • System linear range:
        2.0 mm (80 mil)
      • Recommended gap:
        1.27 mm (50 mil)
      • System scale factor:
        7.87 V/mm (200 mV/mil)
      • System frequency response:
        0 to 10 kHz (+0, -3 dB)
      • 1 m probe DC resistance:
        7.59 +/- 0.50 ohm
      • Minimum flat target diameter:
        15.2 mm
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330173-00-04-10-02-00 is an unarmored M8 x 1 3300 5 mm proximity probe with a 40 mm case and 1.0 m standard cable. It connects to a matched 3300 XL extension cable and Proximitor Sensor for non-contacting vibration or position measurement.
      • 3300 5 mm probe family
      • Unarmored M8 x 1 mounting
      • 40 mm case with 1.0 m cable
      • Matched 5 mm transducer system

      Use the 5 mm probe only in a matched 3300 5 mm transducer system; the smaller probe tip does not relax the documented target and probe-spacing requirements. Set the initial gap near 1.27 mm and confirm the connected 5 m or 9 m system response before release.

      Important Notice: Confirm the exact 330173-00-04-10-02-00 marking, matching system components, installed configuration and controlled output before release.

      330173-00-04-10-02-00 Manuals & Downloads

      These documents are different: the first consolidates verified product and system data; the second provides installation checks, commissioning steps and acceptance records.

      Compact mounting points
      The M8 x 1, 40 mm case fits documented compact probe locations.
      Radial vibration monitoring
      Non-contacting shaft motion measurement with a matched 5 mm system.
      Axial position monitoring
      Position sensing on an approved target and probe-spacing geometry.
      Replacement maintenance
      Preserve the installed 5 mm probe, extension cable and Proximitor matching.
      Read the applicable Bently Nevada instructions before work. Verify 330173-00-04-10-02-00 and its complete matched system before installation or commissioning.
      1
      Read the complete 330173-00-04-10-02-00 marking before removing the old probe.
      2
      Confirm the M8 x 1 threaded hole and 40 mm case envelope.
      3
      Do not substitute an 8 mm probe for this documented 5 mm installation.
      4
      Use the matching 3300 XL extension cable and Proximitor Sensor for the selected length.
      5
      Keep the coaxial ClickLoc connection clean and seated.
      6
      Confirm target size, probe spacing and mounting stability.
      7
      Gap the 5 mm system near the published 1.27 mm initial setting.
      8
      Verify channel response and final monitoring diagnostics before release.

      Technical notes

      Technical notes

      Use the 5 mm probe only in a matched 3300 5 mm transducer system; the smaller probe tip does not relax the documented target and probe-spacing requirements. Set the initial gap near 1.27 mm and confirm the connected 5 m or 9 m system response before release.

      FAQS

      • Which metric thread is used by 330173-00-04-10-02-00?
        The 330173 base model is a 3300 5 mm probe with an M8 x 1 case and no armor.
      • How short is the case of 330173-00-04-10-02-00?
        The 04 code specifies a 40 mm overall case length; 00 specifies zero unthreaded length.
      • What cable is supplied with 330173-00-04-10-02-00?
        Option 10 is a 1.0 m standard probe cable, terminated by the miniature coaxial ClickLoc connector selected by option 02.
      • What does option 02 omit on 330173-00-04-10-02-00?
        It omits the connector protector; the option is the standard-cable ClickLoc connection without a protector.
      • Does the 5 mm tip of 330173-00-04-10-02-00 permit a smaller target?
        The published minimum flat-target diameter is 15.2 mm; the smaller tip does not by itself reduce the required target size.
      • What is the center-conductor resistance for a 1 m 330173-00-04-10-02-00 probe?
        For a 1.0 m 3300 5 mm probe, the datasheet lists 7.59 +/- 0.50 ohm from center to outer conductor.
      • Where should the initial gap be set for a matched 330173-00-04-10-02-00 loop?
        The 3300 5 mm system recommends 1.27 mm (50 mil), within its 2.0 mm linear range.
      • What upper frequency is specified for the 330173-00-04-10-02-00 transducer system?
        The system frequency response is 0 to 10 kHz at +0, -3 dB with up to 305 m of field wiring.
