With more than 30.000 high-quality spare parts, they can be sold immediately. Our large inventory allows us to quickly meet customer needs, thereby reducing downtime and protecting production schedules. Our timely delivery time provides you with security and save money.
The 330104-00-08-05-02-00 is a 3300 XL series 8mm eddy current reverse-mount probe manufactured by Bentley Nevada, USA. It is a core safety monitoring accessory used in industry to monitor large rotating machinery, mainly for non-contact, high-precision measurement of shaft vibration, displacement, speed, or eccentricity.
One 3300 XL 8 mm probe
One 3300 XL extension cable
One 3300 XL Proximitor Sensor
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components. Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable with other non XL 3300 series 5 mm and 8 mm transducer system components. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330104-00-08-05-02-00 Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Power Generation Industry
Monitors shaft conditions of critical generator sets to prevent blackouts caused by severe vibration. Equipment Examples: Steam Turbine Generators, Gas Turbines, Hydro Turbines.
Oil & Gas
Monitors axial displacement of high-power compressors in long-distance pipelines to ensure safe energy transmission. Equipment Examples: Pipeline Centrifugal Compressors, Natural Gas Booster Pumps.
Petrochemical and Refining
Provides high-precision monitoring for critical rotating reactors to prevent toxic or flammable media leaks caused by bearing failure. Equipment Examples: Flue Gas Turbines, Rich Gas Compressors, Cracking Gas Compressors.
Iron & Steel and Metallurgy
Monitors shaft vibration of blast furnace air supply and high-heat recovery equipment to prevent unscheduled mill shutdowns. Equipment Examples: Blast Furnace Blowers, TRT (Blast Furnace Top Gas Recovery Turbines).
Pulp and Paper Industry
Monitors drive bearings of core press and dryer rolls in high-speed paper machines to avoid paper break accidents. Equipment Examples: High-speed Paper Machine Dryer Bearings, Rewinder Drive Systems.
When using the 330104-00-08-05-02-00 probe you must never strike the probe tip and you need to strictly adjust the initial gap by monitoring the Proximitor output voltage to prevent rubbing during machine operation, while also ensuring the total system length of the probe and extension cable and Proximitor matches perfectly, and finally you must adequately protect the ClickLoc connector against water and oil and ground shorts.
330104-00-08-05-02-00 is a 3300 XL 8 mm Proximity Probes.
What are 330104-00-08-05-02-00 probes used for?
Proximity probes are sensors that measure relative proximity. Proximity probes use changes in voltage to measure rotating or reciprotcating shaft surfaces. Because proximity probes are non-contacting transducers, mount proximity probes on a reasonably stationary mechanical structure, such as a bearing housing
How to correctly use the 330104-00-08-05-02-00?
The probe tip must face the measured metal surface. Thread it into the reverse mount bracket, adjust the insertion depth to set the initial gap (voltage value), and finally connect it to an extension cable and a Proximitor sensor.
Does 330104-00-08-05-02-00 require contact with the measured object during measurement?
No. It utilizes the eddy current principle for completely non-contact measurement, so it causes no wear or tear to the rotating shaft.
What industry standards does 330104-00-08-05-02-00 comply with?
When forming a standard 5-meter or 9-meter system, it fully complies with the API 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability.
