      Bently Nevada 330101-00-20-50-02-05
      Bently Nevada 330101-00-20-50-02-05
      Bently Nevada 330101-00-20-50-02-05
      Bently Nevada 330101-00-20-50-02-05
      Bently Nevada 330101-00-20-50-02-05
      Bently Nevada 330101-00-20-50-02-05
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330101-00-20-50-02-05

      Proximity Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330101-00-20-50-02-05 is an unarmored 3300 XL 8 mm proximity probe with a 3/8-24 UNF case and a 5.0 m standard cable. It works with the matched 3300 XL 8 mm Proximitor system for non-contacting shaft vibration and position measurement.

      Ask our team:

      Get a quick price for： 330101-00-20-50-02-05
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330101-00-20-50-02-05

      Technical specifications for 330101-00-20-50-02-05

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330101-00-20-50-02-05
      • Estimated shipping dimensions:
        18x18x2cm
      • Weight:
        0.2 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Probe family:
        3300 XL 8 mm
      • Base model:
        330101
      • Mounting thread:
        3/8-24 UNF
      • Armor:
        Without armor
      • Unthreaded length:
        0.0 in
      • Overall case length:
        2.0 in
      • Total probe length:
        5.0 m (16.4 ft)
      • Connector:
        Miniature coaxial ClickLoc
      • Connector protector:
        Not included
      • Cable type:
        Standard cable
      • Agency approval option:
        CSA, ATEX and IECEx
      • Matched system length:
        5 m
      • System linear range:
        2.0 mm (80 mil)
      • System scale factor:
        7.87 V/mm (200 mV/mil)
      • Recommended initial gap:
        1.27 mm (50 mil)
      • Minimum cable bend radius:
        25.4 mm (1.0 in)
      • Maximum connector torque:
        0.565 N m (5 in-lb)
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330101-00-20-50-02-05 is an unarmored 3300 XL 8 mm proximity probe with a 3/8-24 UNF case and a 5.0 m standard cable. It works with the matched 3300 XL 8 mm Proximitor system for non-contacting shaft vibration and position measurement.
      • Unarmored 3300 XL 8 mm probe
      • 3/8-24 UNF threaded case
      • 5.0 m standard cable with ClickLoc connector
      • Matched 5 m proximity transducer system

      Use the complete five-option order code when matching the probe to the extension cable and 5 m Proximitor Sensor. Keep the miniature coaxial ClickLoc connector clean and observe the 25.4 mm minimum cable bend radius.

      Important Notice: Confirm the exact 330101-00-20-50-02-05 marking, matching system components, installed configuration and controlled output before release.

      330101-00-20-50-02-05 Manuals & Downloads

      These documents are different: the first consolidates verified product and system data; the second provides installation checks, commissioning steps and acceptance records.

      Radial shaft vibration
      Non-contacting shaft motion measurement in a matched 3300 XL 8 mm system.
      Axial position
      Shaft-position monitoring when target and mounting geometry meet the documented system requirements.
      Displacement measurement
      Use of the 2.0 mm linear range with the matching Proximitor Sensor.
      Machinery protection
      Integration with the documented 5 m cable and sensor configuration.
      Read the applicable Bently Nevada instructions before work. Verify 330101-00-20-50-02-05 and its complete matched system before installation or commissioning.
      1
      Confirm the complete 330101-00-20-50-02-05 ordering code and the unarmored 3/8-24 UNF mounting.
      2
      Use the 5.0 m probe only with the correct matched 5 m 3300 XL 8 mm system.
      3
      Keep the ClickLoc connector clean, dry and fully seated before energizing.
      4
      Maintain at least the 25.4 mm minimum cable bend radius and prevent cable crushing.
      5
      Set the initial gap near the published 1.27 mm recommendation.
      6
      Verify the target material and mounting geometry against the datasheet.
      7
      Confirm cable routing, grounding and monitor scaling before service.
      8
      Record the final probe response within the documented 2.0 mm linear range.

      Technical notes

      Technical notes

      Use the complete five-option order code when matching the probe to the extension cable and 5 m Proximitor Sensor. Keep the miniature coaxial ClickLoc connector clean and observe the 25.4 mm minimum cable bend radius.

      FAQS

      • What identifies 330101-00-20-50-02-05 as an unarmored probe?
        The 330101 base code specifies the 3300 XL 8 mm probe with a 3/8-24 UNF thread and without armor.
      • Does the 20 option on 330101-00-20-50-02-05 specify the cable length?
        No. It specifies the 2.0-inch overall case length; the 50 option specifies the 5.0 m total probe length.
      • Which Proximitor length matches the 50 option in 330101-00-20-50-02-05?
        The probe has a 5.0 m cable and is used in a matched 5 m 3300 XL 8 mm transducer system.
      • Is a connector protector included with 330101-00-20-50-02-05?
        No. Connector/cable option 02 is a miniature coaxial ClickLoc connector with standard cable and no protector.
      • What does approval option 05 mean for 330101-00-20-50-02-05?
        Option 05 designates the CSA, ATEX and IECEx approvals listed for the probe in the 3300 XL 8 mm ordering information.
      • What is the published linear range for the matched 330101-00-20-50-02-05 system?
        The matched 3300 XL 8 mm transducer system has a 2.0 mm (80 mil) linear range.
      • What initial gap is recommended when setting up 330101-00-20-50-02-05?
        The datasheet recommends an approximately 1.27 mm (50 mil) gap, corresponding to about -9 Vdc, for the matched system.
      • How tightly may the ClickLoc connector of 330101-00-20-50-02-05 be torqued?
        The published maximum connector torque is 0.565 N m (5 in-lb).
