      XBTGT2220

      Touchscreen Panel
      In Stock
      Ships by Wednesday, November 11
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      Schneider Electric XBTGT2220 is a 5.7-inch Magelis touchscreen panel with a 320 x 240 QVGA display and 24 V DC supply.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for XBTGT2220
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for XBTGT2220

      • Manufacturer:
        Schneider Electric
      • Product Category:
        PLC Systems
      • Spare Part Number:
        XBTGT2220
      • Estimated shipping dimensions:
        16.7x6x13.5cm
      • Weight:
        0.84 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        France
      • Display size:
        5.7 inch
      • Resolution:
        320 x 240 pixels
      • Display format:
        QVGA
      • Supply:
        24 V DC
      • Device class:
        Touchscreen operator panel
      • Named replacement:
        HMIGTO2310
      • Conversion software:
        Vijeo Designer 6.1 or later
      • Replacement COM1:
        RS-232 only
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Schneider Electric XBTGT2220 combines a compact 5.7-inch touch display with the runtime project and communications assigned to its machine.
      • 5.7-inch touchscreen
      • 320 x 240 QVGA display
      • 24 V DC supply
      • HMIGTO2310 migration path

      The HMI renders pages and exchanges data according to its Vijeo Designer application. Screen variables, PLC driver, COM-port use, access levels and alarm behavior must remain aligned with the installed control project.

      Important Notice: HMIGTO2310 is the named hardware replacement, but COM1 on the replacement is RS-232 only. Review the original port usage, convert the project in Vijeo Designer 6.1 or later and retest communications.

      Schneider Electric XBTGT2220 Manuals & Downloads
      Schneider Electric XBTGT2220 Technical Reference (PDF)Schneider Electric XBTGT2220 Official Manual Excerpt (PDF)

      The technical reference is specific to XBTGT2220. The official Schneider Electric hardware guide directly lists XBTGT2220 and covers installation, interfaces and maintenance for the Magelis XBT GT family.

      Machine visualization
      Shows process values and status from the configured controller.
      Touch operation
      Provides project-defined navigation and operator command entry.
      Alarm interaction
      Displays and acknowledges the alarm functions built into the HMI project.
      Controlled HMI migration
      Moves the validated application to HMIGTO2310 after port and project review.
      Schneider Electric XBTGT2220 installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Verify XBTGT2220 on the terminal nameplate.
      2
      Secure the machine before removing operator-interface power or cables.
      3
      Archive the HMI project, recipes and any retained data required by procedure.
      4
      Record the PLC driver, node addresses and exact COM-port assignments.
      5
      Confirm the 24 V DC circuit and protective grounding arrangement.
      6
      Inspect cutout, sealing surface, mounting hardware and connector clearance.
      7
      Convert and validate the project before loading a replacement HMI.
      8
      Prove screens, alarms, permissions, touch targets and all PLC communications.

      Technical notes

      For XBTGT2220, retain the exact manufacturer identifier with the installed drawing, software or wiring baseline. Return the equipment to service only after the relevant diagnostics and model-specific field response have been recorded.

      FAQ View All FAQ

      • What display does Schneider Electric XBTGT2220 use?
        It has a 5.7-inch touchscreen with 320 x 240 QVGA resolution.
      • What supply is specified for Schneider Electric XBTGT2220?
        The exact product record specifies 24 V DC.
      • Which hardware replaces Schneider Electric XBTGT2220?
        Schneider Electric identifies HMIGTO2310 as the replacement panel.
      • Which software version supports Schneider Electric XBTGT2220 migration?
        The replacement FAQ specifies Vijeo Designer version 6.1 or later.
      • What COM-port difference matters when replacing Schneider Electric XBTGT2220?
        The HMIGTO2310 COM1 port is RS-232 only, so the original interface use must be checked.
      • What should be archived before servicing Schneider Electric XBTGT2220?
        Retain the project, recipes, communications, alarm definitions and required operating data.
      • What mounting checks apply to Schneider Electric XBTGT2220?
        Inspect the cutout, gasket surface, fasteners, enclosure condition and rear connector clearance.
      • How is Schneider Electric XBTGT2220 commissioned?
        Test every screen, touch target, alarm, user level and PLC data path under the approved procedure.
