Technical specifications for 140ACI03000C
-
Manufacturer:Schneider Electric
-
Product Category:PLC Systems
-
Spare Part Number:140ACI03000C
-
Estimated shipping dimensions:4x10.5x25cm
-
Weight:0.46 kg
-
Tariff Code:8537101190
-
Counliy of origin:France
-
Product range:Modicon Quantum automation platform
-
Product type:Analogue input module
-
Analogue inputs:8 differential channels
-
Input ranges:1–5 V; 4–20 mA
-
Resolution:12 bits
-
Addressing:9 input words
-
Input impedance:250 ohm current; greater than 20 megohm voltage
-
Absolute maximum input:50 V DC; 25 mA
-
Update time:5 ms
-
Channel-to-bus isolation:1000 V DC; 3000 V DC for 60 s
-
Channel-to-channel isolation:30 V DC
-
Filter:Single-pole low-pass, -3 dB at 15 Hz ±20%
-
Bus current:240 mA
-
Power dissipation:2 W
-
Operating temperature:0–60 °C
Information
Overview
Manuals
Common Applications
Product Precautions
Schneider Electric 140ACI03000C digitizes eight differential voltage or current channels for the Quantum rack with 12-bit resolution and five-millisecond updates.
- 8 differential analogue inputs
- 1–5 V and 4–20 mA ranges
- 12-bit conversion
- 5 ms update time
Use Schneider Electric 140ACI03000C only with the documented rack, field interface and approved commissioning record for the installed application.
Important Notice: Confirm the complete 140ACI03000C identifier, companion hardware and wiring condition; do not substitute a nearby code without an engineering review.
Schneider Electric 140ACI03000C Manuals & Downloads
Schneider Electric 140ACI03000C Official Manual Excerpt (PDF)Schneider Electric 140ACI03000C Installation & Commissioning Guide (PDF)
The Official Manual Excerpt consolidates selected Schneider Electric manual pages; the Installation & Commissioning Guide organizes identity control, isolation, interface checks, functional testing and acceptance records.
Process transmitter inputs
Reads documented 4–20 mA transmitter loops on eight channels.
Voltage signal acquisition
Measures 1–5 V field signals with differential inputs.
Quantum I/O renewal
Restores the same nine-word input mapping and channel assignments.
Loop diagnostics
Uses channel indication and broken-wire detection for configured current loops.
Apply these controls specifically to Schneider Electric 140ACI03000C before isolation, replacement, reconnection and final release.
1
Record all eight channel assignments, ranges and loop-power arrangements before disconnection.
2
Keep channel-to-channel working voltage within the documented 30 V DC boundary.
3
Do not apply more than the specified 50 V DC or 25 mA absolute input limits.
4
Separate and preserve current-loop and voltage-input terminal assignments.
5
Restore shielding and commons without creating unintended ground paths.
6
Verify the nine input words map to the original controller addresses.
7
Test each channel with a traceable current or voltage source at more than one point.
8
Confirm module, external-fault and channel LEDs before process release.
Alternative Names
140ACI03000C
Technical notes
Record the complete model identity, installed system position, companion hardware, field wiring and configuration before service. Use the exact-model limits and acceptance checks shown in the manuals for restoration.
FAQ View All FAQ
-
How many analogue inputs does Schneider Electric 140ACI03000C provide?It provides eight differential analogue input channels.
-
Which signal ranges are supported by Schneider Electric 140ACI03000C?The exact model supports 1–5 V and 4–20 mA input ranges.
-
How many input words does Schneider Electric 140ACI03000C use?The Quantum address map requires nine input words.
-
What is the update time of Schneider Electric 140ACI03000C?The published module update time is 5 ms.
-
What resolution does Schneider Electric 140ACI03000C provide?The analogue conversion resolution is 12 bits.
-
What channel-to-channel limit applies to Schneider Electric 140ACI03000C?The specified channel-to-channel isolation or working boundary is 30 V DC.
-
How should Schneider Electric 140ACI03000C current channels be tested?Inject known 4–20 mA values, compare raw and scaled controller readings, and verify channel diagnostics.
-
What must be restored after replacing Schneider Electric 140ACI03000C?Restore the exact range, terminal, shield, loop-power and nine-word controller mapping for every channel.
