140DDO35300C

Name: 140DDO35300C
Brand: Schneider Electric
SKU: 140DDO35300C

Discrete Output Module

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

140DDO35300C is a coated 32-channel, 24 V DC positive-logic Quantum source-output module arranged as four groups of eight.

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for 140DDO35300C

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 140DDO35300C

Manufacturer:

Schneider Electric
Product Category:

PLC Systems
Spare Part Number:

140DDO35300C
Estimated shipping dimensions:

4x10.6x24.8cm
Weight:

0.3 kg
Tariff Code:

8537101190
Counliy of origin:

France
Discrete outputs:

32
Channel groups:

4 groups of 8
Output logic:

Positive logic; source
Nominal voltage:

24 V DC
Voltage limits:

19.2 to 30 V DC
Addressing:

2 output words
Maximum load:

0.5 A per point; 4 A per group; 16 A per module
Response time:

1 ms or less
Group protection:

Internal 5 A fuse per group
Fault indication:

Loss of field power and blown fuse
Bus current:

330 mA
Environmental execution:

Conformal coated C suffix

View as PDF Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

Schneider Electric 140DDO35300C switches four isolated groups of solid-state field outputs from two Quantum output words.

Preserve all four group supplies and commons.
Respect point, group and module current limits.
Record the two output-word mappings.
Keep the coated C suffix in the exact reference.

The module sources 24 V DC to 32 loads through four protected groups. Command bits, group supply, current loading, fusing and inductive suppression must be reviewed together.

Important Notice: Do not exceed 0.5 A per point, 4 A per group or 16 A per module; preserve the 140DDO35300C group fusing and coated suffix.

Schneider Electric 140DDO35300C Manuals & Downloads

Schneider Electric 140DDO35300C Technical Reference (PDF)Schneider Electric 140DDO35300C Official Manual Excerpt (PDF)

The technical reference presents exact-model engineering data and maintenance boundaries. The official excerpt contains selected unchanged Schneider Electric source pages for this exact model or its documented product family.

Grouped 24 V DC outputs

Controls 32 documented source-load circuits.

Relay and solenoid command

Operates loads within point and group limits.

Two-word PLC mapping

Transfers 32 commands from the Quantum application.

Coated output renewal

Restores exact group wiring and environmental execution.

Schneider Electric 140DDO35300C installation checks: verify exact identity, retain configuration evidence and record the complete functional acceptance.

Verify the complete Schneider Electric 140DDO35300C marking before any selection or field work.

Record the installed position, connectors, conductors and configuration assigned to 140DDO35300C.

Place the connected equipment in its approved safe state and isolate all relevant energy sources.

Protect the discrete output module and its mating interfaces from contamination, static discharge and mechanical damage.

Label output bits, group supplies, commons and fuses before removal.

De-energize and suppress inductive loads according to the design.

Confirm every group remains below 4 A and the module below 16 A.

Energize in stages and prove all 32 outputs safely.

Technical notes

Do not exceed 0.5 A per point, 4 A per group or 16 A per module; preserve the 140DDO35300C group fusing and coated suffix.
