      T8850C

      conformal-coated 40-channel analog or digital output field termination assembly
      In Stock
      Ships by Sunday, November 8
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      ICS Triplex T8850C Trusted Conformal-Coated 40-Channel Analog or Digital Output FTA

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for T8850C
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for T8850C

      • Manufacturer:
        ICS Triplex
      • Product Category:
        DCS Systems
      • Spare Part Number:
        T8850C
      • Estimated shipping dimensions:
        30x12.5x6.3cm
      • Weight:
        0.6 kg
      • Tariff Code:
        8537101101
      • Counliy of origin:
        USA
      • Product Type:
        Trusted Conformal-Coated 40-Channel Analog or Digital Output FTA
      • System Family:
        Trusted 8000
      • Channel / Interface Summary:
        40 outputs in five groups of eight; conformal-coated C variant
      • Field supply:
        Up to 60 Vdc via approved T8290 arrangement
      • Channels:
        40 in five groups of eight
      • Maximum channel current:
        2 A
      • Maximum assembly current:
        40 A
      • Variant identification:
        C suffix denotes conformal coating
      • Official source:
        Rockwell Automation PD-T8850 Trusted 40 Channel Analog or Digital Output FTA
      • Signal / Data Handled:
        forty grouped analog or digital output paths using the engineered 18–60 Vdc field-supply arrangement
      • Compatible Components:
        Approved Trusted output module, matching SmartSlot/field cables, T8290 field-supply arrangement and coated-system environmental plan
      • Lifecycle Reference:
        The official FTA certificate permits a C suffix for conformal coating; confirm current availability with Rockwell Automation.
      • Primary Application:
        Coated safety output cabinets
      • Secondary Application:
        Humid-process-area panels
      • Verification Note:
        Confirm the exact T8850C physical nameplate and controlled project record.
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      The T8850C is an ICS Triplex Trusted Conformal-Coated 40-Channel Analog or Digital Output FTA for Trusted 8000 systems.
      • 40 outputs in five groups of eight; conformal-coated C variant
      • Designed for the Trusted 8000 architecture
      • provides the T8850 output termination function with a conformal-coated circuit-board variant identified by the official C suffix
      • Model-specific compatible hardware: Approved Trusted output module, matching SmartSlot/field cables, T8290 field-supply arrangement and coated-system environmental plan

      It provides the T8850 output termination function with a conformal-coated circuit-board variant identified by the official C suffix. It handles forty grouped analog or digital output paths using the engineered 18–60 Vdc field-supply arrangement and works with Approved Trusted output module, matching SmartSlot/field cables, T8290 field-supply arrangement and coated-system environmental plan. For dependable operation, follow the official model-specific system matching, wiring, environmental and commissioning instructions.

      Important Notice: Confirm the exact T8850C physical nameplate, hardware revision and controlled project record before installation or replacement.

      Apter Power T8850C Manuals and Guides

      Important Notice: These are two separate Apter Power documents with different layouts and model-specific content, prepared from the manufacturer-published source identified in each document. Confirm the physical nameplate, current Rockwell Automation documentation, and host-system requirements before installation or replacement.

      Coated safety output cabinets
      T8850C provides the T8850 output termination function with a conformal-coated circuit-board variant identified by the official C suffix.
      Humid-process-area panels
      T8850C forty grouped analog or digital output paths using the engineered 18–60 Vdc field-supply arrangement.
      Shutdown final-element groups
      T8850C provides the T8850 output termination function with a conformal-coated circuit-board variant identified by the official C suffix.
      Analog actuator interfacing
      T8850C forty grouped analog or digital output paths using the engineered 18–60 Vdc field-supply arrangement.
      Legacy Trusted coated assemblies
      T8850C provides the T8850 output termination function with a conformal-coated circuit-board variant identified by the official C suffix.
      Read Rockwell Automation PD-T8850 Trusted 40 Channel Analog or Digital Output FTA and the applicable system installation instructions before use. Verify the exact model, revision, slot or base, termination hardware and field wiring.
      1
      Verify the T8850C nameplate; the coating suffix does not change the published electrical ratings.
      2
      Preserve coating integrity and use ESD-safe handling during inspection or replacement.
      3
      Confirm output module, cables, T8290 field power and group-loading design.
      4
      Do not infer additional environmental approvals from coating alone; follow the site certificate set.
      5
      Test all used channels and diagnostics, then retain a coating-inspection record before release.

      Alternative Names

      T8850C ICS Triplex ICS Triplex T8850C Trusted 8000 T8850C

      Technical notes

      Official source: Rockwell Automation PD-T8850 Trusted 40 Channel Analog or Digital Output FTA. Confirm the exact physical nameplate and current Rockwell Automation record before replacement.

      FAQ View All FAQ

      • What is the ICS Triplex T8850C?
        It is a Trusted Conformal-Coated 40-Channel Analog or Digital Output FTA for Trusted 8000 control and safety architectures.
      • What does T8850C do?
        provides the T8850 output termination function with a conformal-coated circuit-board variant identified by the official C suffix.
      • What signals or data does it handle?
        forty grouped analog or digital output paths using the engineered 18–60 Vdc field-supply arrangement.
      • Which components are compatible?
        Approved Trusted output module, matching SmartSlot/field cables, T8290 field-supply arrangement and coated-system environmental plan.
      • Where is this model applied?
        Coated safety output cabinets, Humid-process-area panels, Shutdown final-element groups, Analog actuator interfacing, Legacy Trusted coated assemblies.
      • What should be checked before replacement?
        Confirm the complete model, physical nameplate, hardware revision, slot or base, termination hardware, field wiring, configuration and current official documentation.
