Technical specifications for C7076A1015
-
Manufacturer:Honeywell
-
Product Category:DCS Systems
-
Spare Part Number:C7076A1015
-
Estimated shipping dimensions:12x26x10cm
-
Weight:3.08 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Power Supply Voltage:24 V DC nominal
-
Power Supply Range:20–30 V DC
-
Power Consumption:1.5 W typical
-
Current Consumption:60 mA nominal
-
Detection Range:Up to 20 m
-
Field of View:90° cone
Information
Overview
Manuals
Common Applications
Product Precautions
Honeywell C7076A1015 is a self-checking ultraviolet flame detector for burner flame-safeguard systems. It senses burner UV radiation and supplies the signal to a compatible flame amplifier.
- Detects ultraviolet radiation from a burner flame
- Uses a self-checking shutter for flame-safeguard supervision
- Feeds the compatible flame amplifier
- Supports adjustable detector sensitivity
C7076A1015 installs with R7476A1007 or R7886A1001 amplifier, 7800 Series flame safeguard, One-inch NPT sight pipe, 100 Vac detector supply in an engineered Honeywell burner flame safeguard configuration.
The commissioning workflow covers installed-hardware matching, controlled start-up and functional verification for this ultraviolet flame detector.
Important Notice: Confirm the complete C7076A1015 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.
Apter Power C7076A1015 Manuals and Guides
Apter Power C7076A1015 Product Technical Reference PDFHoneywell C7076A1015 Official Manual PDF
The first document is an Apter Power model-specific technical reference. The second supports model-specific installation, configuration and engineering verification.
Industrial burner flame provingDetects ultraviolet radiation from a burner flame
Boiler combustion supervisionUses a self-checking shutter for flame-safeguard supervision
Furnace burner managementFeeds the compatible flame amplifier
Process-heater flame detectionSupports adjustable detector sensitivity
Read the applicable Honeywell installation instructions before work. Verify C7076A1015 and the installed Honeywell burner flame safeguard configuration.
1Verify the complete C7076A1015 marking and its assigned Honeywell burner flame safeguard position before work.
2Isolate the energy associated with R7476A1007 or R7886A1001 amplifier before disconnecting C7076A1015.
3Protect the C7076A1015 connectors and electronic assembly using approved ESD controls.
4Record the as-found 7800 Series flame safeguard connections and configured assignment before replacement.
5Confirm One-inch NPT sight pipe matches the approved installation record for C7076A1015.
6Restore C7076A1015 under controlled conditions and review its model-specific diagnostics.
7Complete a documented functional test for industrial burner flame proving before release.
FAQ View All FAQ
-
What is C7076A1015 and what function does it perform in a burner flame-safeguard system?Honeywell C7076A1015 is a self-checking ultraviolet flame detector. It senses ultraviolet radiation from the burner flame and supplies the flame signal to a compatible Honeywell flame amplifier.
-
Which Honeywell flame amplifiers are specified for C7076A1015?C7076A1015 is specified for use with the Honeywell R7476A1007 or R7886A1001 flame amplifier. Confirm the installed amplifier and safeguard configuration before replacement.
-
What power supply and frequency are required for C7076A1015?The C7076A1015 detector supply is 100 Vac at 50/60 Hz. Verify the measured supply and the installed safeguard wiring before energizing the detector.
-
What sight-pipe connection is used when mounting C7076A1015?C7076A1015 uses a 1-inch NPT process connection. The sight pipe must provide the detector with the burner-viewing path defined for the installation.
-
What ambient-temperature range applies to C7076A1015?The stated ambient-temperature range for C7076A1015 is -40 to 160 °F. Keep the detector installation within this range.
-
How should the self-checking shutter of C7076A1015 be verified during commissioning?Commission C7076A1015 with its compatible amplifier and flame-safeguard controller, then verify shutter operation and flame-signal response using the controlled test procedure for the installed system.
-
What installation and wiring checks are important for C7076A1015?Confirm the detector has an unobstructed burner view, preserve the documented sight-pipe arrangement, keep detector wiring separated from ignition conductors, and check the installed grounding and terminations.
-
What information should be recorded when replacing C7076A1015?Record the full C7076A1015 identity, companion amplifier, sight-pipe arrangement, terminal and cable identification, as-left connections, flame-signal result, shutter check and final safeguard functional test.
