330500-00-20

Velomitor piezo-velocity sensor
In Stock
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

Bently Nevada 330500-00-20 is a solid-state piezo-velocity sensor for absolute bearing-housing, casing or structural vibration. Its selected mounting and configuration suffix must agree with the delivered marking.
  • Manufacturer part number
    330500-00-20
  • Shipping
    Swift global dispatch
  • Condition
    New, original product
  • Shipping size (est.)
    7cm x 2.5cm x 2.5cm
  • Country of Origin
    USA
Get a quick price for 330500-00-20
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 0

    Review your reference

    Send the full marking, quantity and label photos. We review the item and any version details that need clarification.
  • 1

    Confirm the offer

    Check the quoted reference, condition, included items and expected dispatch date before approving your order.
  • 2

    Arrange dispatch

    Confirm delivery details and receive the tracking number when it becomes available.
  • Match the complete marking

    Include 330500-00-20 and every revision or approval marking visible on the item. Keep the exact reference on your enquiry and quotation.
  • Check the offered item before ordering

    Request available label and interface photos. Have your maintenance team compare the offered 330500-00-20 reference with the installed equipment and applicable Bently Nevada documentation.

Technical specifications for 330500-00-20

  • Manufacturer:
    Bently Nevada
  • Product Category:
    Machinery Monitoring Systems
  • Spare Part Number:
    330500-00-20
  • Weight:
    0.15 kg
  • Tariff Code:
    8537101190
  • Measurement:
    Absolute bearing-housing, casing or structural vibration
  • Sensitivity:
    3.94 mV/mm/s (100 mV/in/s) +/-5%
  • Frequency response:
    4.5 Hz to 5 kHz, +/-3 dB
  • Precision frequency band:
    6 Hz to 2.5 kHz, +/-0.9 dB
  • Velocity range:
    1270 mm/s (50 in/s) peak
  • Amplitude linearity:
    +/-2% to 152 mm/s (6 in/s) peak
  • Mounted resonant frequency:
    >12 kHz
  • Output bias voltage:
    -12 +/-3 V DC
  • Dynamic output impedance:
    <2400 ohm
  • Broadband noise floor:
    0.004 mm/s rms nominal
  • Maximum signal cable length:
    305 m under stated cable conditions
  • Operating temperature:
    -55 to +121 deg C
  • Case material:
    316L stainless steel
  • Connector:
    2-pin MIL-C-5015, hermetically sealed
  • Mounting torque:
    32 to 46 kg cm maximum
  • Sensor diameter:
    25.3 mm
  • Sensor height:
    63.2 mm
  • Typical sensor mass:
    142 g
  • Mounting adapter selection:
    No mounting-thread adapter
  • Approval/configuration marking:
    Legacy suffix 20 retained from delivered marking

Information

Overview Downloads Applications / Compatibility Product Precautions
  • 330500-00-20 combines a piezoelectric sensing element with embedded integration electronics to produce a velocity-proportional signal from absolute machine-casing vibration. It is applied on rigid bearing housings, casings or structural points connected to a compatible current-limited vibration monitor input.
Measurement role: Absolute vibration from a piezoelectric element with embedded velocity integration.
Selected mounting: No mounting-thread adapter; mounting surface and torque govern high-frequency coupling.
Electrical output: 3.94 mV/mm/s sensitivity with -12 +/-3 V DC output bias.
330500-00-20 integrates a piezoelectric acceleration signal inside a solid-state 316L stainless-steel sensor to provide velocity-proportional output for absolute machine-housing vibration.

The selected no mounting-thread adapter must be seated on a rigid prepared surface. Preserve connector polarity, cable support and the monitor current-limiting arrangement, and keep mounting torque within 32 to 46 kg cm.

Published sensitivity and frequency response assume the stated loading and mounting conditions. Final acceptance should compare the installed velocity response with the established machine baseline across a controlled operating state.
Controller platform reference: 330500 Velomitor piezo-velocity sensor family. Match the installed chain and machine record before release.
Prepare Bently Nevada 330500-00-20 using the approved machine documentation and site procedure.
Confirm the complete marking

Match every field of 330500-00-20 with the installed spare-parts record before removal or installation.

Protect the sensing face

Keep the probe tip, connector and cable free from impact, moisture, metal chips and unsupported loading.

Preserve the mechanical datum

Record reach, thread engagement, lock position and target relationship before disturbing the installed component.

Control the cable route

Maintain the approved bend radius, separation and strain relief; do not twist, kink or crush the coaxial path.

Restore the operating point

Use the approved stopped-machine procedure to restore gap or bias and verify expected target travel.

Prove the complete channel

Verify the as-left electrical reading, monitor indication and operating response before return to service.

Alternative Names

330500 00 20 Bently Nevada 330500-00-20

Technical notes

Installation relationship: Use the selected no mounting-thread adapter on a rigid bearing-housing or casing surface; flexible brackets can attenuate or distort the response.

Electrical boundary: The sensor incorporates embedded electronics and requires the documented current-limited monitor input, cable loading and polarity.

Technical reference: Bently Nevada 330500 Velomitor Piezo-velocity Sensor Datasheet, 141632 Rev. V.

FAQ View All FAQ

  • Where should 330500-00-20 be mounted?
    Use a rigid, prepared bearing-housing, casing or structural location that transfers the vibration of interest; avoid thin covers, flexible brackets and painted or uneven surfaces.
  • How should the mounting interface of 330500-00-20 be prepared?
    Confirm the selected no mounting-thread adapter, clean and flatten the mounting surface, apply the approved installation method, and keep torque within 32 to 46 kg cm.
  • What electrical checks apply to 330500-00-20?
    Confirm the current-limited input and polarity, record the unloaded bias, inspect the 2-pin MIL-C-5015 connector, and keep field cable loading within the documented channel design.
  • How should the response of 330500-00-20 be accepted?
    Compare the local velocity reading and monitor indication at a controlled operating state with the approved machine baseline; investigate resonance, loose mounting or cable motion before release.
  • What evidence should be captured before removing 330500-00-20?
    Photograph the complete 330500-00-20 marking, installed datum, connector, cable route and companion electronics. Record the stopped-machine baseline for the Velomitor piezo-velocity sensor.
  • How should connector integrity be checked on 330500-00-20?
    Isolate the channel, inspect the coaxial contacts for moisture and damage, verify continuity only with an approved method, and provide strain relief so the connector carries no cable load.
  • What commissioning record is required for 330500-00-20?
    Retain the exact markings, mechanical datum, companion-component identities, as-left gap or bias, monitor indication and the accepted operating response.
  • When should 330500-00-20 be withheld from service?
    Do not release the channel if the complete identity, mechanical fit, cable construction, connector, approval marking or measured response differs from the approved installed record.
