      330105-02-12-10-02-CN

      3300 XL 8 mm Reverse Mount Probes
      In Stock

      Product Describe：

      3300 XL 8 mm
      Reverse Mount Probes
      3/8-24 UNF threads
      02 = 20 mm
      12 = 120 mm
      1.0 meter (3.3 feet)
      Miniature ClickLoc
      Coaxial connector

      Ask our team:

      Get a quick price for： 330105-02-12-10-02-CN
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information FAQ

      Technical specifications for 330105-02-12-10-02-CN

      Technical specifications for 330105-02-12-10-02-CN

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330105-02-12-10-02-CN
      • Estimated shipping dimensions:
        16cm*16cm*12cm
      • Weight:
        0.3 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Operating Voltage:
        DC 24V
      • Detection Distance:
        8mm
      • Signal Output:
        TTL/PNP
      • Detection Angle:
        360°
      • Enclosure Type:
        IP67
      • Humidity Range:
        0% to 95% non-condensing
      • Environmental Temperature Range:
        -40°C to +85°C
      Ask for Quote

      Information

      Information

      Overview Manuals Need More Info
      • 330105-02-12-10-02-CN 3300 XL 8 mm Reverse Mount Probes
      • A high-performance reverse mount proximity probe designed
      • It delivers accurate non-contact measurement of shaft vibration and position for reliable machinery protection.
      The BENTLY NEVADA 330105-02-12-10-02-CN is a 3300 XL 8 mm Reverse Mount Proximity Probe designed for vibration and displacement monitoring in industrial machinery. It features a 3/8-24UNF UNF thread, a 1.0-meter total length, and a Miniature ClickLoc coaxial connector. "CN" indicates country-specific approvals for China.

      This reverse mount probe features an 8 mm tip, delivering stable linear performance and high sensitivity for detecting small displacements. Its construction ensures consistent operation under demanding industrial conditions, including high temperatures and vibration environments, making it ideal for turbines, compressors, pumps, and other critical rotating equipment.

      The modular design of the 3300 XL reverse mount probe allows flexible installation and easy integration with existing monitoring systems. Fully compatible with standard 3300 XL system components, it simplifies maintenance and upgrades while ensuring long-term reliability and accurate performance for predictive maintenance and machinery protection applications.

      Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      BENTLY NEVADA 330105-02-12-10-02-CN 3300 XL 8 mm Reverse Mount Probes Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
      We know that questions arise, and that sometimes you need more details or a closer look to make the right decision. That’s why we make it easy for you to reach out directly—so you’re never left wondering.

      With our team, you’re just a message away from clarity and confidence. Whether you have a specific question, need a particular image, or want more details, the request form puts you in control. Let us know what you need, and we’ll bring the answers straight to you—no guesswork required!

      FAQS

      • What does the 330105-02-12-10-02-CN "Reverse Mount" mean?
        The probe is installed through the machine case, with the probe tip inside and the connector outside.
      • What is the 330105-02-12-10-02-CN typical lead time?
        Generally 8–10 weeks, but can vary.
      • Does the 330105-02-12-10-02-CN require a special cable?
        It uses a connector that requires specific mating, generally part of the 3300 XL system.
      • How does the 330105-02-12-10-02-CN work?
        It uses eddy current technology to measure both static and dynamic gaps between the probe and a conductive shaft.
      • What is the function of the 330105-02-12-10-02-CN 3300 XL 8 mm Reverse Mount Probe?
        It provides non-contact measurement of shaft vibration and position for machinery monitoring and protection.
      • What is the 330105-02-12-10-02-CN probe tip diameter?
        The probe features an 8 mm tip for accurate and stable measurements.
