The 330104-00-13-10-01-CN is an industrial-grade, high-precision 3300 XL series 8mm eddy current proximity transducer probe manufactured by Bently Nevada (a Baker Hughes business), a globally renowned machinery condition monitoring brand.
One 3300 XL 8 mm probe
One 3300 XL extension cable
One 3300 XL Proximitor Sensor
The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system also fully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability.
All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components. Each 3300 XL 8 mm Transducer System component is backward compatible and interchangeable with other non XL 3300 series 5 mm and 8 mm transducer system components. This compatibility includes the 3300 5 mm probe, for applications in which an 8 mm probe is too large for the available mounting space.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 330104-00-13-10-01-CN Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Thermal Power Generation
Installed on the main bearings of large steam turbines and generators to dynamically monitor shaft radial vibration and axial thermal growth displacement, preventing rubs between rotating and stationary components at high speeds.
Hydropower Generation
Used to measure the runout (radial vibration) and shaft speed of hydro-generator units, tracking the dynamic stability of the main shaft under water flow impacts.
Nuclear Power
Provides 24/7 bearing vibration monitoring for main feedwater pumps and high-pressure steam turbines outside the nuclear island, ensuring the absolute safety of critical rotating machinery.
Wind Power Generation
Positioned on the main shaft, gearbox inputs, and generator bearings of high-power wind turbines to monitor axial loads and movement under low-frequency, high-torque conditions.
Oil & Gas
Applied to gas pipeline compressors and crude oil export pumps along long-distance pipelines, providing explosion-proof monitoring of shaft clearances and severe vibrations.
When using the 330104-00-13-10-01-CN probe you must first strictly control the installation gap voltage and perform mechanical zero alignment using a calibrated target disc. Secondly during wiring you need to ensure the total extension cable length strictly matches the proximitor sensor, and armored metal conduits must be used throughout to prevent mechanical wear and electromagnetic interference. Finally you must regularly check the explosion-proof seals, oil contamination, and carbon buildup on the probe tip to avoid measurement signal drift caused by medium contamination or insulation degradation.
The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface (calibrated to AISI 4140 steel as default). It is engineered to measure both static (position/gap) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements on critical rotating machinery. This specific configuration (330104-00-13-10-01-CN) features an unthreaded design (0 mm unthreaded length) with a 130 mm overall case length made of M10×1 metric threaded stainless steel. To withstand harsh plant conditions involving metal debris or mechanical crushing, the high-frequency cable is fully protected by stainless steel armor. The low-loss cable has a total length of 1.0 meter (3.3 feet) and terminates in a miniature ClickLoc coaxial connector equipped with a factory-supplied connector protector. Crucially, the -CN suffix indicates that this component holds country-specific hazardous area approvals from NEPSI for intrinsic safety or explosion-proof compliance in China, ensuring secure deployment in hazardous environments. It complies fully with the API 670 Standard and supports complete calibration-free component interchangeability.
It is an industrial-grade explosion-proof non-contact eddy current proximity transducer probe primarily used for high-precision displacement and vibration measurement of critical rotating machinery shafts.
How to correctly install and use the 330104-00-13-10-01-CN probe in an industrial field?
Fix it onto the bearing housing near the shaft via M10x1 threads and use its integrated 1.0-meter cable to link into a 1.0-meter system Proximitor via the coaxial connector.
What are the recommended and maximum mounting torques when installing 330104-00-13-10-01-CN?
To protect the stainless steel case from distortion, a mounting torque of 11.2 N·m (100 in·lbf) is recommended, and it must never exceed 22.6 N·m.
If a 330104-00-13-10-01-CN component is directly replaced at a factory site, does the system require bench recalibration?
Absolutely not, as the entire 3300 XL series features excellent calibration-free interchangeability, allowing an identical new probe to replace an old one without losing original system accuracy.
What is the practical advantage of the stainless steel armor on the case of 330104-00-13-10-01-CN?
The stainless steel armor effectively protects the internal high-frequency coaxial cable from mechanical wear, cutting debris, or external crushing, greatly extending wiring longevity in harsh environments.
