      Bently Nevada 21000-16-10-15-144-03-02
      Bently Nevada 21000-16-10-15-144-03-02
      Bently Nevada 21000-16-10-15-144-03-02
      Bently Nevada 21000-16-10-15-144-03-02
      Bently Nevada 21000-16-10-15-144-03-02
      Bently Nevada 21000-16-10-15-144-03-02
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      21000-16-10-15-144-03-02

      21000 Aluminum Proximity Probe Housing Assembly
      In Stock
      Ships by Tuesday, September 22
      Fast Shipping Available

      Product Describe：

      Bently Nevada 21000-16-10-15-144-03-02 is a 21000 aluminum external proximity-probe housing configured with a 3300 XL 8 mm probe, 1.0 m probe cable, 1.5 in standoff adapter and 14.4 in penetration option. It supports protected, adjustable mounting of the probe at a rotating-machine case.

      Ask our team:

      Get a quick price for： 21000-16-10-15-144-03-02
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 21000-16-10-15-144-03-02

      Technical specifications for 21000-16-10-15-144-03-02

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        21000-16-10-15-144-03-02
      • Estimated shipping dimensions:
        60x8.5x8.5cm
      • Weight:
        1.44 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Housing series:
        21000
      • Housing body:
        Aluminum
      • Probe sleeve:
        304 stainless steel
      • Installed probe option:
        3300 XL 8 mm probe
      • Probe cable length:
        1.0 m
      • Standoff adapter:
        1.5 in
      • Probe penetration option:
        14.4 in
      • Fittings option:
        One 3/4-14 NPT plug; 3/4-14 to 1/2-14 NPT reducer; cable seal grip
      • Mounting thread:
        3/4-14 NPT
      • Adjustment range:
        ±0.5 in
      • Probe operating and storage temperature:
        -51 to +177 °C
      • Enclosure:
        CSA Type 4
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      21000-16-10-15-144-03-02 encloses and positions a 3300 XL 8 mm proximity probe for deep machine-case penetration while providing conduit and cable-sealing provisions.
      • Provides an external protective enclosure for the proximity probe
      • Allows controlled adjustment of the installed probe position
      • Routes the probe lead through a sealed conduit interface
      • Supports API 670-style externally mounted probe arrangements

      The assembly mounts externally to the machine case through the selected 3/4-14 NPT thread. Its aluminum body, stainless-steel sleeve, standoff adapter, adjustable penetration and conduit fittings protect the probe installation; commissioning includes sleeve support, conduit sealing, lead routing, static gap, target clearance and monitor response checks.

      Important Notice: Confirm 21000-16-10-15-144-03-02, 21000 aluminum housing, 3300 XL 8 mm probe option, 1.0 m cable, 1.5 in standoff, 14.4 in penetration, 3/4-14 NPT mounting thread, fitting set, sleeve support, O-rings, conduit sealing, target clearance, grounding, monitor configuration, static gap and controlled response-test results before commissioning.

      Apter Power 21000-16-10-15-144-03-02 Manuals and Guides

      The first document is the model-specific technical and system reference. The second is a distinct field workbook for installation, wiring, commissioning and acceptance records.

      Bearing-case proximity probe mounting
      Supports deep machine-case penetration for relative shaft measurement.
      External radial-vibration sensing
      Houses the probe and protects its lead at a documented radial location.
      Axial-position probe access
      Provides an adjustable external mounting path where the approved machine design requires it.
      Probe replacement without case entry
      Allows the sleeve and probe arrangement to be serviced from outside the machine case.
      Read the applicable Bently Nevada installation instructions before work. Verify 21000-16-10-15-144-03-02, the installed host system and all configured field interfaces before isolation, wiring or commissioning.
      1
      Confirm the full 21000-16-10-15-144-03-02 marking and the 144 penetration code.
      2
      Place the monitored machine and associated protection channel in the approved maintenance state.
      3
      Isolate connected circuits and use ESD controls while handling the probe lead and connector.
      4
      Inspect the aluminum body, dome cover, O-rings, stainless-steel sleeve and thread seal.
      5
      Verify the 3/4-14 NPT mounting thread, standoff adapter and conduit fitting arrangement.
      6
      Support long sleeves as required and keep the probe lead longer than the installed sleeve.
      7
      Set the 3300 XL 8 mm probe gap while maintaining shaft and target clearances.
      8
      Seal the conduit, restore the signal loop and prove polarity, response and alarm action before release.

      Technical notes

      Technical notes

      Mount 21000-16-10-15-144-03-02 through the documented 3/4-14 NPT machine-case connection and preserve the 1.5 in standoff and 14.4 in probe-penetration setting. Support the sleeve when required, route and seal the 1.0 m lead, set the 3300 XL 8 mm probe gap and confirm housing, conduit and signal-loop integrity before service.

      FAQS

      • What exact function does 21000-16-10-15-144-03-02 perform as a 21000 Aluminum Proximity Probe Housing Assembly?
        It externally houses and positions the selected 3300 XL 8 mm probe while routing its lead through the conduit fittings.
      • Which host system must be confirmed before installing 21000-16-10-15-144-03-02?
        Confirm the documented Bently Nevada 21000 / 24701 Proximity Probe Housing Assemblies host and the complete 21000-16-10-15-144-03-02 marking before work.
      • Which connection checks are required for 21000-16-10-15-144-03-02?
        Inspect the mounting thread, sleeve, standoff, O-rings, dome cover, fittings and lead route.
      • How should the installed configuration for 21000-16-10-15-144-03-02 be preserved?
        Retain the documented standoff, penetration, fittings and matched proximity-transducer loop.
      • Which diagnostic evidence should be reviewed for 21000-16-10-15-144-03-02?
        Review static gap, signal polarity, baseline, conduit sealing and monitor-channel diagnostics.
      • What must be recorded before replacing 21000-16-10-15-144-03-02?
        Record the complete order code, 144 penetration option, installed thread, sleeve support and signal-loop components.
      • How should 21000-16-10-15-144-03-02 be commissioned after installation?
        Seal the conduit, establish the linear-region gap and prove monitor response and alarm action under control.
      • Which model-specific limitation applies to 21000-16-10-15-144-03-02?
        The sleeve must be supported when the installed C plus D length exceeds the manufacturer threshold, and the probe lead must remain longer than the sleeve.
