      3CP360.60-1

      System 2005 CPU
      In Stock
      Ships by Tuesday, September 22
      Fast Shipping Available

      Product Describe：

      B&R 3CP360.60-1 is a System 2005 CPU built around a Pentium 266 processor with DRAM, SRAM and removable CompactFlash application memory. Its integrated RS232, Ethernet and USB ports coordinate controller logic, communication and supported aPCI expansion.

      Ask our team:

      Get a quick price for： 3CP360.60-1
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Revisions Alternative names Technical notes FAQ

      Technical specifications for 3CP360.60-1

      Technical specifications for 3CP360.60-1

      • Manufacturer:
        B&R
      • Product Category:
        PLC Systems
      • Spare Part Number:
        3CP360.60-1
      • Estimated shipping dimensions:
        17.8×7.6 ×11.3 cm
      • Weight:
        0.6 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        Austria
      • Processor:
        Pentium 266
      • DRAM:
        32 MB
      • SRAM:
        496 kB user RAM; 512 kB stated product memory
      • Remanent variables:
        256 kB
      • Application memory:
        1 removable CompactFlash slot
      • Interface IF1:
        RS232, 9-pin male DSUB, max. 115.2 kbit/s
      • Interface IF2:
        10/100 Mbit/s Ethernet, shielded RJ45
      • Interface IF3:
        USB 1.1 Type A
      • aPCI slots:
        1 for IF7xx interface modules
      • Shortest task class:
        400 us
      • Total power:
        14 W without memory card or interface module
      • Protection rating:
        IP20
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      B&R 3CP360.60-1 is a System 2005 CPU built around a Pentium 266 processor with DRAM, SRAM and removable CompactFlash application memory. Its integrated RS232, Ethernet and USB ports coordinate controller logic, communication and supported aPCI expansion.
      • Executes System 2005 control tasks while an integrated I/O processor handles background data
      • Stores the application on removable CompactFlash media
      • Combines serial, Ethernet and USB service interfaces on the CPU
      • Accepts one IF7xx aPCI communication or interface module

      Back up the application, CompactFlash contents, interface settings and retained variables before replacing B&R 3CP360.60-1. Refit the CPU in base-unit slots 3 and 4, restore the approved aPCI module and prove Ethernet, serial, USB and I/O operation.

      Important Notice: Confirm B&R 3CP360.60-1, terminal hardware, field wiring, installed accessories and current B&R documentation before commissioning.

      Apter Power B&R 3CP360.60-1 Manuals and Guides
      Apter Power B&R 3CP360.60-1 Product and System Technical Reference PDFB&R 3CP360.60-1 Official Datasheet V1.0 PDF

      Important Notice: The first document is an Apter Power model-specific technical reference; the second is the B&R official data sheet identified in the manufacturer source record.

      System 2005 machine controller
      B&R 3CP360.60-1 executes deterministic application logic and coordinates installed I/O.
      Ethernet-connected production cell
      The shielded 10/100BASE-T port exchanges supervisory and controller data over the documented segment.
      Serial equipment integration
      The RS232 DSUB interface connects approved serial devices at rates up to 115.2 kbit/s.
      aPCI interface expansion
      One IF7xx slot adds the project-specific fieldbus or communication interface retained by the system record.
      Read the applicable B&R instructions before work. Verify B&R 3CP360.60-1 and the installed System 2005 configuration.
      1
      Record the B&R 3CP360.60-1 hardware revision, firmware and base-unit slot assignment.
      2
      Back up the CompactFlash application before removing power or the CPU.
      3
      Preserve the aPCI interface model, settings and cable assignments installed in the single expansion slot.
      4
      Place the controlled process in its approved safe state before stopping System 2005 execution.
      5
      Check the lithium backup-battery status before relying on retained SRAM data.
      6
      Label the RS232, Ethernet and USB connections and preserve network parameters.
      7
      Allow for the documented 14 W CPU load plus the separate memory and interface-module demand.
      8
      After restoration, prove the application checksum, retained data, I/O scan and every active communication link.

      Revisions

      Revisions

      Revision Part #

      Also known as

      Datasheet 3CP360.60-1
      B&R version 1.0, 2004-06-08
      Get Parts Quote

      Alternative Names

      Alternative Names

      B&R 3CP360.60-1

      Technical notes

      Technical notes

      Back up the application, CompactFlash contents, interface settings and retained variables before replacing B&R 3CP360.60-1. Refit the CPU in base-unit slots 3 and 4, restore the approved aPCI module and prove Ethernet, serial, USB and I/O operation.

      FAQS

      • What memory must be backed up before exchanging B&R 3CP360.60-1?
        The application resides on removable CompactFlash, while user and remanent data use SRAM; preserve both the CompactFlash image and retained values.
      • Which communication ports are built into B&R 3CP360.60-1?
        The CPU provides RS232 on a 9-pin male DSUB, switched 10/100 Mbit/s Ethernet on RJ45 and one USB 1.1 Type-A port.
      • How is an additional fieldbus interface added to B&R 3CP360.60-1?
        Use the single insertion slot intended for IF7xx aPCI interface modules and restore the exact documented module and configuration.
      • Where is B&R 3CP360.60-1 installed in a System 2005 base unit?
        The official data sheet assigns the double-width CPU to base-unit slots 3 and 4 and does not permit it in an expansion unit.
      • What task timing is documented for B&R 3CP360.60-1?
        The shortest task class cycle time is 400 microseconds, with a typical instruction cycle time of 0.02 microseconds.
      • Why should the backup battery be checked on B&R 3CP360.60-1?
        Battery monitoring protects retained SRAM and the nonvolatile real-time clock; B&R states a lithium-battery life of at least three years.
      • Which interfaces of B&R 3CP360.60-1 are electrically isolated?
        The data sheet shows IF2 Ethernet isolated from the PLC and from IF1 and IF3, while the RS232 and USB paths are not isolated from the PLC.
      • What proves successful B&R 3CP360.60-1 recommissioning?
        Verify boot from the approved CompactFlash, compare the application checksum, confirm retained variables and exercise Ethernet, RS232, USB, aPCI and controlled I/O functions.
