The 2711P-T7C22D9P from Allen-Bradley is a touch-operated human-machine interface (HMI) terminal. Featuring a high-definition TFT color display, it supports 640 x 480 VGA resolution and 18-bit color graphics, delivering clear, vibrant, and highly detailed visual interfaces for operators.
18-bit color depth and VGA resolution accurately display complex process charts and alarms
Built-in USB ports enable external storage and peripherals for fast data transfers
Direct Logix tag parsing eliminates tedious intermediate variable configuration
The 2711P-T7C22D9P terminal operates on 24V DC power and is tailored for seamless integration into standard industrial control cabinets. Built-in dual Ethernet ports support star, linear, and Device Level Ring (DLR) network topologies, which maintains uninterrupted data communication even in the event of a single point of network failure. Alongside these network interfaces, the chassis includes USB ports that allow users to connect external storage drives, keyboards, or mice, streamlining field maintenance and rapid data imports or exports.
For visual interaction, this model incorporates a full-color TFT LCD panel with a 640 x 480 VGA pixel grid. Utilizing 18-bit color depth processing, it provides faithful reproduction of intricate process flow diagrams, trend charts, and alarm indicators. Operators can input process variables, trigger control commands, and switch monitoring screens by tapping the screen surface directly, removing the physical limitations of traditional pushbuttons.
The hardware embeds the FactoryTalk View Machine Edition (ME) runtime environment, which directly reads and parses tag data from Logix controllers to eliminate intermediate variable configuration steps. Through this tight binding, workshop operators can view live equipment operating states, recipe data, and historical alarm logs, enabling accurate production decisions within complex factory environments.
