What is the 2711P-K12C4A8 product?

The 2711P-K12C4A8 is an industrial Human-Machine Interface (HMI) terminal from the PanelView Plus 6 1250 series by Allen-Bradley (Rockwell Automation).

What is the screen size and display type of the 2711P-K12C4A8?

It features a 12.1-inch TFT color LCD display with an 800 x 600 SVGA resolution and supports 18-bit color graphics.

Which operator input method does the 2711P-K12C4A8 use?

This model uses a pure keypad input method, featuring a stainless-steel membrane for protection along with navigation, numeric, and function keys; it does not support touch operation.

What operating system is built into the 2711P-K12C4A8?

It runs on the embedded Windows CE 6.0 operating system (standard version without extended features).

What is the memory configuration of the 2711P-K12C4A8?

It is equipped with 512 MB RAM and 512 MB of Flash memory for system storage and HMI runtime projects.

2711P-K12C4A8

Name: 2711P-K12C4A8
Brand: Allen-Bradley
SKU: 2711P-K12C4A8

PanelView Plus Terminal

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

PanelView Plus Terminal
Color active-matrix TFT
End of life
F1 to F20, K1 to K20; 0…9
Special Characters
Backspace, Enter, Left
and Right Tab, keys
Shift keys

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for 2711P-K12C4A8

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 2711P-K12C4A8

Manufacturer:

Allen-Bradley
Product Category:

PLC Systems
Spare Part Number:

2711P-K12C4A8
Estimated shipping dimensions:

46.8x8.5x33cm
Weight:

4.28 kg
Tariff Code:

8537101190
Counliy of origin:

USA
Display Size:

12.1 in
Input Type:

Keypad
Display Type:

Color
Communication:

Ethernet, RS-232 & (2) USB
Power:

AC
Operating System:

Windows CE 6.0
Input Power:

100-240 VAC
Memory:

512 MB RAM

Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

The 2711P-K12C4A8 is a PanelView Plus 6 industrial-grade human-machine interface manufactured by Rockwell Automation. It features a 12.1-inch color display, a keypad input panel, an AC power supply, and an Ethernet communication interface, providing robust capabilities for graphical monitoring and system control in harsh industrial environments.

Includes an SD card slot
Utilizes a proprietary electromagnetic and physical isolation mechanism
1 x Ethernet, 1 x RS-232 serial, and 2 x USB ports for external peripherals

Featuring a modular architecture, it offers flexible configuration with independent logic, communication, and display components.The terminal is equipped with a 12.1-inch active-matrix color display (18-bit graphics, 800 x 600 resolution) with a protective, stainless-steel membrane keypad that includes function, numeric, and navigation keys. Engineered with 512 MB of RAM and 512 MB of nonvolatile storage, this 10-lb unit measures 20 x 14 x 8 inches and operates on a universal 100–240V AC power supply (50–60 Hz).Compared to older models, the 2711P-K12C4A8 delivers significant upgrades in processing speed, data transition rates, memory capacity, and screen brightness. Leveraging the open EtherNet/IP standard, the terminal facilitates real-time I/O messaging, general data exchange, application transfers, and printing. Users can directly view and adjust network communication settings via the onboard EtherNet/IP configuration screen.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.

Allen Bradley 2711P-K12C4A8 PanelView Plus Terminal Manuals, Datasheets, Drivers, Link

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.

Automotive

Used in body assembly lines, stamping shops, and paint robot cells to monitor welding parameters, conveyor speeds, and equipment fault alarms in real time.

Pharmaceuticals

Deployed in vaccine production, pill packaging, and cleanroom control systems, leveraging data logging and timestamping to comply with FDA 21 CFR Part 11 audit trail regulations.

Oil and Gas

Installed on drilling consoles, pipeline pumping stations, or gas metering skids to monitor pressure, tank levels, valve positions, and safety interlock systems.

Pulp and Paper

Used to oversee large paper machines, bleaching lines, and winders, managing synchronous speeds of multi-segment drives and paper tension control.

Steel and Metallurgy

Used in blast furnace charging, high-speed rolling mill control, and induction hardening equipment, displaying thermal distribution layouts and receiving molten steel temperature alarms.

When operating the 2711P-K12C4A8, ensure the power supply stays within the rated 100-240V AC range to prevent voltage spikes. Avoid striking the stainless-steel membrane keypad forcefully or scratching the screen with sharp tools. Routinely back up your FactoryTalk View ME projects to the internal memory or an SD card, and check or replace the real-time clock battery after 4 years of run time. Lastly, maintain proper ventilation to prevent overheating, and ensure correct wiring for Ethernet or serial ports to block industrial electromagnetic interference (EMI).

Revisions

Revision Part #

Also known as

2711P-K12C4A8 Ser A

2711P-K12C4A8/A, Series A, Rev A

Get Parts Quote

2711P-K12C4A8 SerX

2711P-K12C4A8/X, Series X, Rev X

Get Parts Quote

Alternative Names

2711P-K12C4AB 2711PK12C4AB 271IPK12C4A8 27IIP-KI2CAAB 2711P-K12CAA8 2711PK12CAA8 27I1P-K12C4A8 27IIPKI2C4A8 2711P-KI2C4A8 2711PKI2C4A8 27I1PK12C4A8 27IIPKI2CAAB 2711PK12C4A8 271IP-K12C4A8 27IIP-KI2C4A8

FAQ View All FAQ

What is the 2711P-K12C4A8 product?

The 2711P-K12C4A8 is an industrial Human-Machine Interface (HMI) terminal from the PanelView Plus 6 1250 series by Allen-Bradley (Rockwell Automation).
What is the screen size and display type of the 2711P-K12C4A8?

It features a 12.1-inch TFT color LCD display with an 800 x 600 SVGA resolution and supports 18-bit color graphics.
Which operator input method does the 2711P-K12C4A8 use?

This model uses a pure keypad input method, featuring a stainless-steel membrane for protection along with navigation, numeric, and function keys; it does not support touch operation.

What operating system is built into the 2711P-K12C4A8?

It runs on the embedded Windows CE 6.0 operating system (standard version without extended features).
What is the memory configuration of the 2711P-K12C4A8?

It is equipped with 512 MB RAM and 512 MB of Flash memory for system storage and HMI runtime projects.
