1757-FFLD2

FIELDBUS LINKING DEVICE
In Stock
Allen-Bradley 1757-FFLD2
Allen-Bradley 1757-FFLD2
Allen-Bradley 1757-FFLD2
Allen-Bradley 1757-FFLD2
Allen-Bradley 1757-FFLD2
Allen-Bradley 1757-FFLD2
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

DISCONTINUED BY MANUFACTURER
FIELDBUS LINKING DEVICE
300 MA
24 VDC
1.5 A
Get a quick price for 1757-FFLD2
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 1

    Requirement review

    We review the part number, quantity and delivery requirements and ask for any missing details.
  • 2

    Quotation and availability

    We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
  • 3

    Order confirmation and dispatch

    Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 1757-FFLD2

  • Manufacturer:
    Allen-Bradley
  • Product Category:
    PLC Systems
  • Spare Part Number:
    1757-FFLD2/A
  • Estimated shipping dimensions:
    19.1x12.7x8.9cm
  • Weight:
    0.8 kg
  • Tariff Code:
    8537101190
  • Counliy of origin:
    USA
  • Category:
    PLCs/Machine Control
  • Subcategory:
    PLC Module/Rack
  • Interfaces:
    1 x Etherent, 2 x H1
  • H1 networks per linking device:
    2
  • Maximum fieldbus devices per H1 network:
    16
  • Power requirement:
    300 milliamps at 24 Volts DC
  • In-circuit battery:
    5000 charge / discharge cycles

Information

Overview Manuals Common Applications Installation
The 1757-FFLD2 is designed to facilitate robust industrial communication and control. It operates on an input voltage range of 18 to 36 VDC, with a nominal input of 24 VDC. This device consumes a maximum of 36 watts of power while handling an input current of up to 1.5 amperes.Equipped with dual Ethernet ports, it operates at speeds of 10/100 Mbps and supports crucial protocols like EtherNet/IP and High-Speed Ethernet (HSE). Provisions for fieldbus connectivity are managed through two H1 ports, allowing for a communication speed of 31.25 kbps.
    • Dual H1 Ports
    • 18...32V DC Input
    • 0...60 °C Operating
The module ensures a high level of isolation with an Ethernet to H1 isolation voltage rated at 500 V RMS. It is built to withstand surges with a tolerance of ±2 kV across the H1 ports, contributing to its overall reliability in industrial settings.Furthermore, it demonstrates solid immunity against electrostatic discharge (ESD), rated at 8 kV for air discharge and 6 kV for direct contact discharge. The enclosure is rated IP20, making it suitable for environments where dust and solid objects are minimal.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Allen-Bradley 1757-FFLD2 FIELDBUS LINKING DEVICE Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
  Oil & Gas
The linking device connects EtherNet/IP networks to field devices in hazardous locations. It facilitates real-time data exchange for wellhead monitoring and custody transfer meters in upstream and midstream operations.

 Chemical Processing
Enables integration of temperature and pressure transmitters across dual H1 segments with an operating range of 0…60 °C. It supports distributed control of reactors and storage tanks through seamless bridge communication.

 Power Generation
Provides 18…32V dc power flexibility for monitoring cooling systems and steam turbines. The device ensures high-speed data throughput for diagnostic information in both fossil fuel and renewable energy facilities.

 Water Treatment
Managed within an open-style enclosure for pump station control and wastewater filtration systems. It utilizes 31.25 Kbps Foundation Fieldbus H1 ports to maintain connectivity with remote flow meters and valves.

  Pharmaceutical Manufacturing
Supports 5…95% noncondensing relative humidity for cleanroom process automation and batch control. The hardware facilitates precise instrumentation integration to meet stringent regulatory tracking and data logging requirements.

 Mining & Metals
Designed to withstand 2 g operational vibration at 10…500 Hz for heavy-duty ore processing and smelting operations. It links Ethernet-based plant architectures to specialized Fieldbus sensors in high-interference environments.
The 1757-FFLD2 is designed for installation as an open-style device, necessitating its placement within a protective enclosure that meets specific environmental ratings to shield it from debris and ensure safety. To maintain operational integrity, the module requires a dedicated connection to a clean earth ground via the grounding screw, typically utilizing a 14 AWG copper wire to mitigate electromagnetic interference and ensure proper electrostatic discharge (ESD) immunity.

The  current consumption of 500 mA at 24V dc, and it is essential that the power supply source remains within the 18...32V dc range to prevent thermal stress or hardware instability. During the configuration of Foundation Fieldbus H1 segments, attention must be paid to the total cable length and the correct placement of two terminators per segment, as the linking device provides the dual H1 communication ports but does not supply the internal bus power.

FAQ View All FAQ

  • What is the input voltage range and current consumption for the 1757-FFLD2?
    The 1757-FFLD2 requires an input voltage of 18…32V dc and has a current consumption of 500 mA @ 24V dc.
  • What are the operating and storage temperature limits for the 1757-FFLD2?
    The operating temperature is 0…60 °C (32…140 °F), while the nonoperating temperature for storage is -40…85 °C (-40…185 °F).
  • What is the relative humidity range and vibration tolerance for the 1757-FFLD2?
    The allowable relative humidity is 5…95% noncondensing, and the operational vibration is 2 g @ 10…500 Hz.
  • What are the communication interfaces available on the 1757-FFLD2?
    The 1757-FFLD2 features one EtherNet/IP port and two Foundation Fieldbus H1 ports for connecting field devices.
  • What is the enclosure type rating for the 1757-FFLD2 according to the technical data?
    The 1757-FFLD2 is an open-style device, and its enclosure type rating is None (open-style).
