Technical specifications for TCSEGDB23F24FA
-
Manufacturer:Schneider Electric
-
Product Category:PLC Systems
-
Spare Part Number:TCSEGDB23F24FA
-
Estimated shipping dimensions:3.7x14.5x15cm
-
Weight:0.54 kg
-
Tariff Code:8537101190
-
Counliy of origin:France
-
Gateway function:Ethernet Modbus TCP to Modbus Plus
-
Compatible controllers:Modicon M340 and M580
-
Modbus Plus rate:1 Mbit/s
-
Ethernet rate:10/100 Mbit/s
-
Server devices:Up to 128
-
Ethernet interfaces:2 RJ45 ports
-
Modbus Plus interfaces:2 SUB-D 9 ports
-
Network services:Messaging, FDR, SNMP, Global Data and Peer Cop
-
External supply:24 V DC
-
Current consumption:300 mA
-
Operating temperature:0 to 60 degrees C
-
Operating altitude:Up to 2000 m
Information
Overview
Manuals
Common Applications
Product Precautions
Schneider Electric TCSEGDB23F24FA provides protocol, configuration and diagnostic services between X80 Ethernet and Modbus Plus devices.
- Preserve both Ethernet and both Modbus Plus connections.
- Retain IP addressing, Modbus Plus nodes and scanner mapping.
- Back up proxy configuration and FDR-related settings.
- Confirm the 24 V DC external supply before commissioning.
The proxy translates between Modbus TCP services and the existing Modbus Plus network. Its operation depends on the configured Ethernet identity, Modbus Plus topology, mapped devices and controller application.
Important Notice: Do not treat TCSEGDB23F24FA as a transparent cable adapter; its IP settings, Modbus Plus node map, configuration services and controller project must agree.
Schneider Electric TCSEGDB23F24FA Manuals & Downloads
Schneider Electric TCSEGDB23F24FA Technical Reference (PDF)Schneider Electric TCSEGDB23F24FA Official Manual Excerpt (PDF)The technical reference presents exact-model engineering data and maintenance boundaries. The official excerpt contains selected unchanged Schneider Electric source pages for this exact model or its documented product family.
M340 migration bridge
Connects an M340 application to existing Modbus Plus devices.
M580 legacy integration
Maintains access to a documented Modbus Plus segment.
Network diagnostics
Provides configured status and SNMP services.
Proxy replacement
Restores the exact mapping and four physical network interfaces.
Schneider Electric TCSEGDB23F24FA installation checks: verify exact identity, retain configuration evidence and record the complete functional acceptance.
1
Verify the complete Schneider Electric TCSEGDB23F24FA marking before any selection or field work.
2
Record the installed position, connectors, conductors and configuration assigned to TCSEGDB23F24FA.
3
Place the connected equipment in its approved safe state and isolate all relevant energy sources.
4
Protect the network proxy and its mating interfaces from contamination, static discharge and mechanical damage.
5
Export the proxy configuration and device map before removal.
6
Label both Ethernet and both SUB-D Modbus Plus connections.
7
Verify the external 24 V DC supply and grounding.
8
Test each mapped server and controller data path before release.
Technical notes
Do not treat TCSEGDB23F24FA as a transparent cable adapter; its IP settings, Modbus Plus node map, configuration services and controller project must agree.
FAQ View All FAQ
-
What device identity or role does Schneider Electric TCSEGDB23F24FA publish?Use Ethernet Modbus TCP to Modbus Plus as the TCSEGDB23F24FA gateway function reference and resolve any field discrepancy before release.
-
Which compatible controllers is associated with Schneider Electric TCSEGDB23F24FA?The manufacturer record for TCSEGDB23F24FA specifies Modicon M340 and M580. Preserve it through selection, installation and acceptance.
-
What modbus plus rate rating is specified for Schneider Electric TCSEGDB23F24FA?Schneider Electric identifies the modbus plus rate as 1 Mbit/s; keep that exact entry in the TCSEGDB23F24FA record.
-
What ethernet rate rating is specified for Schneider Electric TCSEGDB23F24FA?The published TCSEGDB23F24FA value is 10/100 Mbit/s. The installed configuration must remain within that boundary.
-
How many server devices are documented for Schneider Electric TCSEGDB23F24FA?For TCSEGDB23F24FA, the manufacturer states Up to 128. Do not replace it with a nearby suffix value.
-
Which ethernet interfaces configuration belongs to Schneider Electric TCSEGDB23F24FA?Record 2 RJ45 ports for TCSEGDB23F24FA and verify the field arrangement against the controlled drawing or project.
-
Which modbus plus interfaces configuration belongs to Schneider Electric TCSEGDB23F24FA?The exact-model source gives 2 SUB-D 9 ports. Use it together with the actual TCSEGDB23F24FA nameplate and installation record.
-
What manufacturer value is recorded for TCSEGDB23F24FA network services?TCSEGDB23F24FA is documented with Messaging, FDR, SNMP, Global Data and Peer Cop; this value belongs to the verified product configuration.
