      MU-TSIM12

      Serial Interface Field Termination Assembly
      In Stock
      Ships by Tuesday, September 22
      Fast Shipping Available

      Product Describe：

      Honeywell MU-TSIM12 is a Modbus serial-interface FTA that connects EIA-232 or EIA-485 devices to the TPS serial interface processor.

      Ask our team:

      Get a quick price for： MU-TSIM12
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for MU-TSIM12

      Technical specifications for MU-TSIM12

      • Manufacturer:
        Honeywell
      • Product Category:
        DCS System
      • Spare Part Number:
        51303932-401
      • Estimated shipping dimensions:
        15.2x12x8cm
      • Weight:
        0.3 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Electrical interfaces:
        EIA-232; EIA-485
      • Protocol:
        Modbus RTU
      • FTAs per interface:
        2
      • Devices per FTA:
        15 maximum
      • Points per channel:
        16
      • Baud rates:
        1200; 2400; 4800; 9600; 19200 bit/s
      • Parity:
        None; odd; even
      • Stop bits:
        1
      • EIA-232 distance:
        15 m maximum
      • EIA-485 distance:
        1.2 km maximum
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Honeywell MU-TSIM12 is a Modbus serial-interface FTA that connects EIA-232 or EIA-485 devices to the TPS serial interface processor.
      • Terminates serial field links
      • Supports EIA-232 point-to-point wiring
      • Supports EIA-485 multidrop wiring
      • Maps Modbus RTU data to TPS channels

      MU-TSIM12 operates with TPS serial-interface processor, Serial-interface power adapter, Shielded serial cable, Modbus RTU slave devices.

      Its engineered use includes PLC-to-TPS data exchange, Variable-speed drive integration, Analyzer serial communications, Packaged skid Modbus links.

      Important Notice: Confirm the complete MU-TSIM12 marking, installed-system configuration, field connections and controlled functional test before commissioning or replacement.

      Apter Power MU-TSIM12 Manuals and Guides
      Apter Power MU-TSIM12 Product Technical Reference PDFApter Power MU-TSIM12 Installation and Verification PDF
      The first document is an Apter Power model-specific technical reference. The second supports installation, configuration and engineering verification for MU-TSIM12.
      PLC-to-TPS data exchangeTerminates serial field links
      Variable-speed drive integrationSupports EIA-232 point-to-point wiring
      Analyzer serial communicationsSupports EIA-485 multidrop wiring
      Packaged skid Modbus linksMaps Modbus RTU data to TPS channels
      Read the applicable Honeywell instructions before work. Verify MU-TSIM12 and the installed TPS Process Manager I/O configuration.
      1Verify the complete MU-TSIM12 marking and its assigned TPS Process Manager I/O position before work.
      2Isolate the applicable power and field energy before disconnecting MU-TSIM12.
      3Protect MU-TSIM12 connectors and electronic assemblies with approved ESD controls.
      4Record the installed wiring, channel assignment and configuration before replacement.
      5Match TPS serial-interface processor and Serial-interface power adapter to the documented system arrangement.
      6Commission MU-TSIM12 with controlled status, signal and diagnostic checks.
      7Retain the final plc-to-tps data exchange functional-test result in the maintenance record.

      Technical notes

      Technical notes

      Set baud rate, parity, device address and EIA-485 termination consistently before enabling Modbus write functions.

      FAQS

      • Does MU-TSIM12 match TPS serial-interface processor in a PLC-to-TPS data exchange installation?
        Verify the complete MU-TSIM12 marking, the documented TPS Process Manager I/O position and the installed TPS serial-interface processor before fitting the assembly.
      • How should MU-TSIM12 be wired when it must terminates serial field links?
        Isolate the circuit, identify every terminal and reproduce the approved polarity, shield and channel assignment for MU-TSIM12; then continuity-test the affected path.
      • Which TPS Process Manager I/O records should be captured before removing MU-TSIM12?
        Record the as-found wiring, installed position, active configuration and diagnostic state associated with MU-TSIM12 before disconnection.
      • What controlled test confirms that MU-TSIM12 can supports eia-232 point-to-point wiring?
        Apply the approved field or simulated stimulus, observe the TPS Process Manager I/O indication and confirm the intended response without bypassing the normal interlocks.
      • Which Serial-interface power adapter condition should be checked when MU-TSIM12 reports an abnormal state?
        Check the Serial-interface power adapter supply, seating and connection first, then compare channel diagnostics with the recorded MU-TSIM12 baseline.
      • Can MU-TSIM12 be moved directly into Variable-speed drive integration without validating Modbus RTU slave devices?
        No. Confirm the Modbus RTU slave devices, revision, connection scheme and TPS Process Manager I/O configuration before transferring MU-TSIM12 to that duty.
      • What maintenance evidence is required after MU-TSIM12 is used for Analyzer serial communications?
        Retain the nameplate record, corrective action, final diagnostics and a controlled analyzer serial communications functional-test result for MU-TSIM12.
      • How should MU-TSIM12 be returned to service in Packaged skid Modbus links?
        Restore power under control, verify supports eia-485 multidrop wiring, exercise the intended signal path and release MU-TSIM12 only after the TPS Process Manager I/O remains in its approved operating state.
