Get a quick price for F3 AIO 8/4 01
For more information on how your data is processed and stored by Apterpower please read our privacy policy
Technical specifications for F3 AIO 8/4 01
-
Manufacturer:HIMA
-
Product Category:DCS Systems
-
Spare Part Number:F3 AIO 8/4 01
-
Estimated shipping dimensions:2x19x12.8cm
-
Weight:0.15 kg
-
Tariff Code:8537101190
-
Counliy of origin:Germany
-
Product family:HIMatrix F
-
Device form:Remote analog I/O
-
Analog inputs:8
-
Analog outputs:4
-
Analog output classification:Non-safety-related
-
Ethernet switch ports:2
-
Line monitoring:Not listed
-
Sensor supply:NAMUR proximity-switch supply
-
Field supply:24 V support
-
System engineering:SILworX
-
Safety networking:SafeEthernet portfolio
Information
Overview
Manuals
Common Applications
Product Precautions
The F3 AIO 8/4 01 brings mixed analog acquisition and output functions to a distributed HIMatrix station while keeping the four outputs outside the safety-related classification.
- Confirm the eight analog input ranges and channel assignments from the approved project.
- Treat all four analog outputs as non-safety-related outputs.
- Record the two Ethernet switch-port connections before removal.
- Verify NAMUR or 24 V field-supply use channel by channel.
Analog ranges, scaling, diagnostics, sensor supply and output use are determined by the validated project. The four analog outputs must not be represented as safety-related outputs.
Important Notice: The four analog outputs are non-safety-related; do not assign them a safety function that the manufacturer portfolio does not claim.
HIMA F3 AIO 8/4 01 Manuals & Downloads
HIMA F3 AIO 8/4 01 Technical Reference (PDF)HIMA F3 AIO 8/4 01 Installation & Commissioning Guide (PDF)The technical reference consolidates exact product data and evidence boundaries. The installation guide organizes controlled replacement, wiring or network checks, commissioning and acceptance.
Analog measurement
Acquire eight approved process or machinery signals at a remote station.
NAMUR sensor interface
Support documented NAMUR proximity-switch circuits.
Mixed analog station
Combine input acquisition with four non-safety analog outputs.
Distributed diagnostics
Retain scaling and diagnostic records in the HIMatrix project.
HIMA F3 AIO 8/4 01 installation checks: preserve the exact model identity, documented system arrangement and controlled acceptance evidence.
1
Verify the complete manufacturer and model marking against the approved bill of materials.
2
Record the installed position, terminal arrangement, network assignment and visible diagnostics before removal.
3
De-energize the affected circuit and apply the site isolation and electrostatic-control procedure.
4
Compare every conductor, connector and address with the controlled drawing before transfer.
5
Inspect mating parts, grounding, shielding and enclosure condition before installing the replacement.
6
Restore only the validated project and the documented channel or communication settings.
7
Review startup diagnostics before any live functional test is attempted.
8
Prove the intended response and retain the witnessed acceptance record before release.
Technical notes
Verify input ranges, scaling, sensor supply and the non-safety status of every analog output against the validated project.
FAQ View All FAQ
-
What is HIMA F3 AIO 8/4 01?HIMA F3 AIO 8/4 01 is a HIMatrix remote analog I/O module with eight analog inputs and four analog outputs.
-
How many analog inputs does HIMA F3 AIO 8/4 01 provide?The exact model provides eight analog input channels.
-
How are the outputs of HIMA F3 AIO 8/4 01 classified?Its four analog outputs are documented as non-safety-related.
-
Which sensor supply is documented for HIMA F3 AIO 8/4 01?HIMA documents supply support for NAMUR proximity switches and 24 V field devices.
-
How many Ethernet switch ports does HIMA F3 AIO 8/4 01 have?The manufacturer portfolio lists two Ethernet switch ports.
-
Is line monitoring listed for HIMA F3 AIO 8/4 01?Line monitoring is not listed for this exact analog execution in the cited manufacturer table.
-
What analog settings must be preserved for HIMA F3 AIO 8/4 01?Preserve channel ranges, scaling, sensor-supply choices, output assignments and both Ethernet addresses from the validated project.
-
What completes commissioning of HIMA F3 AIO 8/4 01?Review diagnostics and prove each required analog input and output response with calibrated test equipment.
