What mounting geometry defines Emerson PR6423/00R-111 CON041?

The R code identifies a reverse-mount sensor execution.

Does Emerson PR6423/00R-111 CON041 include an adaptor plug?

No. The order code specifies the no-adaptor configuration.

What cable length is supplied with Emerson PR6423/00R-111 CON041?

The sensor has a five-metre cable.

How does the cable terminate on Emerson PR6423/00R-111 CON041?

The exact execution has open cable ends for terminal connection.

Why must forward-mount geometry not be used for Emerson PR6423/00R-111 CON041?

Reverse mounting changes the mechanical reference and adjustment geometry.

Which converter form is paired with Emerson PR6423/00R-111 CON041?

CON041 is the DIN-rail signal converter in the documented channel.

What must be labelled before disconnecting Emerson PR6423/00R-111 CON041?

Label every cable core, shield and CON041 terminal together with the reverse-mount orientation.

How is Emerson PR6423/00R-111 CON041 functionally accepted?

Verify the static gap, output polarity, target-movement response, dynamic signal and monitor alarms.

PR6423/00R-111 CON041

Name: PR6423/00R-111 CON041
Brand: Emerson
SKU: PR6423/00R-111 CON041

Reverse-Mount 8 mm Eddy Current Sensor and DIN-Rail Converter Set

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

Reverse-mount M10 unarmored 8 mm probe without adaptor plug, using a five-metre open-ended cable and CON041 DIN-rail converter.

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for PR6423/00R-111 CON041

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for PR6423/00R-111 CON041

Manufacturer:

Emerson
Product Category:

Machinery Monitoring Systems
Spare Part Number:

PR6423/00R-111 CON041
Estimated shipping dimensions:

16x16x2cm
Weight:

0.22 kg
Tariff Code:

8537101190
Counliy of origin:

USA
Converter:

CON041
Probe class:

8 mm
Mounting form:

Reverse mount
Thread:

M10 x 1
Armor:

None
Adaptor plug:

Not supplied
Cable length:

5 m
Cable end:

Open
Converter mounting:

DIN rail

View as PDF Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

Emerson EPRO PR6423/00R-111 CON041 is a reverse-mounted proximity sensor execution wired directly to a DIN-rail converter.

Reverse-mount probe geometry
M10 x 1 unarmored body
5 m open-ended cable
CON041 DIN-rail converter

Reverse mounting changes the mechanical installation and requires the open-ended no-adaptor cable path documented by the order code. The converter remains part of the calibrated non-contact measurement chain.

Important Notice: PR6423/00R-111 is a reverse-mount execution; do not apply forward-mount sleeve geometry or a Lemo-ended wiring arrangement.

Emerson PR6423/00R-111 CON041 Manuals & Downloads

Emerson PR6423/00R-111 CON041 Technical Reference (PDF)Emerson PR6423/00R-111 CON041 Manufacturer Manual Excerpt (PDF)

The technical reference organizes exact characteristics and engineering boundaries. The manufacturer excerpt supplies the original product evidence used for exact-model review.

Reverse-access bearing locations

Installs the sensing tip from the documented opposite mounting direction.

DIN-rail monitoring cabinets

Terminates the open cable at a nearby CON041 converter.

Radial vibration channels

Measures shaft motion when reverse geometry suits the housing.

Special outage replacements

Restores an exact reverse-mount probe without redesigning the bracket.

Emerson PR6423/00R-111 CON041 installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.

Confirm PR6423/00R-111 CON041 and the reverse-mount drawing.

Record probe orientation, gap, cable cores and converter terminals.

Stop the machine and isolate the channel before loosening the probe.

Protect the sensing tip and identify every open-ended conductor.

Inspect reverse-mount threads, locking hardware and target clearance.

Terminate the five-metre cable only on the documented CON041 points.

Set the static gap while observing the converter output.

Prove displacement direction, dynamic response and alarms before release.

Technical notes

For PR6423/00R-111 CON041, retain the exact manufacturer identity, installed connection record and witnessed model-specific acceptance result.

FAQ View All FAQ

What mounting geometry defines Emerson PR6423/00R-111 CON041?

The R code identifies a reverse-mount sensor execution.
Does Emerson PR6423/00R-111 CON041 include an adaptor plug?

No. The order code specifies the no-adaptor configuration.
What cable length is supplied with Emerson PR6423/00R-111 CON041?

The sensor has a five-metre cable.
How does the cable terminate on Emerson PR6423/00R-111 CON041?

The exact execution has open cable ends for terminal connection.

Why must forward-mount geometry not be used for Emerson PR6423/00R-111 CON041?

Reverse mounting changes the mechanical reference and adjustment geometry.
Which converter form is paired with Emerson PR6423/00R-111 CON041?

CON041 is the DIN-rail signal converter in the documented channel.
What must be labelled before disconnecting Emerson PR6423/00R-111 CON041?

Label every cable core, shield and CON041 terminal together with the reverse-mount orientation.
How is Emerson PR6423/00R-111 CON041 functionally accepted?

Verify the static gap, output polarity, target-movement response, dynamic signal and monitor alarms.
