Technical specifications for 3500/05-01-01-00-00-00
-
Manufacturer:Bently Nevada
-
Product Category:Machinery Monitoring Systems
-
Spare Part Number:3500/05-01-01-00-00-00
-
Estimated shipping dimensions:48.2x28x26.5cm
-
Weight:5.95 kg
-
Tariff Code:8537101190
-
Counliy of origin:USA
-
Product Type:System Rack
-
Series:3500/05
-
Rack Size:19-inch Full-size
-
Available Module Slots:14
-
Mounting Option:Panel Mount
-
Agency Approval:None
-
European Compliance:None
-
Compatible System:3500 Machinery Protection System
Information
Overview
Manuals
Common Applications
Rack Architecture
The 3500/05-01-01-00-00-00 is the standard Full-Size 19-Inch System Rack designed for the Bently Nevada 3500 Machinery Protection System. It serves as the primary hardware foundation, housing and powering all 3500 system modules.
- Supports redundant 3500/15 power supply slot distribution
- Integrates a high-reliability backplane bus for module communication
- Provides physical housing for all 3500 modules
The rugged construction of the 3500/05-01-01-00-00-00 ensures superior electromagnetic shielding and optimal thermal management across dense card deployments. It accommodates standard dual-redundant 3500/15 power supplies to guarantee zero-downtime operations for critical industrial turbomachinery protection loops.
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Bently Nevada 3500/05-01-01-00-00-00 System Rack Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Thermal Power Generation Industry
Houses steam turbine and large axial fan monitoring modules, centrally managing shaft vibration, axial displacement, and low-speed turning gear status to provide hard-interlock trip protection.
Nuclear Power Industry
Serves as the hardware foundation for the safety protection systems of conventional island steam turbine generators and nuclear island main pumps, ensuring critical sensor signals are free from interference through its high-shielding enclosure.
Hydroelectric Power Industry
Houses hydro-generator shaft swing and speed monitoring modules, using the backplane bus to transmit zero-speed signals to relays within milliseconds for safely applying mechanical brakes.
Wind Power Industry
Deployed in large offshore wind power centralized control centers to install dynamic signal acquisition cards for main shafts, multi-stage gearboxes, and generators, executing remote predictive maintenance.
Petrochemical and Refining Industry
Houses monitoring cards for large centrifugal high-capacity compressor trains, instantly tripping the system via the internal backplane bus upon detecting surge or reversal.
Steel and Metallurgical Industry
Installs protection cards for blast furnace core axial blowers and heavy-duty rolling mill drive shafts, isolating high-frequency electromagnetic radiation in the plant to prevent false trips of heavy equipment.
The 3500/05-01-01-00-00-00 provides the mechanical and electrical foundation for the 3500 Machinery Protection System. Its integrated backplane enables communication between installed monitor modules while distributing power from the rack power supply, allowing flexible system configuration for machinery protection and condition monitoring applications.
Alternative Names
3500/05-02-01-00-00-00
3500/05-03-01-00-00-00
3500/05-01-00-00-00-00
3500/05-01-02-00-00-00
3500/05-01-04-00-00-00
3500/05-01-01-01-00-00
3500/05-01-01-02-00-00
3500/05-01-01-00-01-00
3500/05-01-01-00-00-01
Technical notes
3500/05 backplane integrates high-speed logic channels. When a tachometer module detects reverse rotation or a vibration module triggers a Danger alarm, the status is instantly transmitted via the bus to the 3500/32M relay in the same rack. The contacts trip within milliseconds, enabling autonomous, computer-independent hardware-level protection.
