What is the primary purpose of the 3500/92 136180-01 module?

Its purpose is to centrally collect static and dynamic data, as well as alarm statuses, from all monitoring modules in the 3500 rack, and then transmit this information to upper-level plant control and management systems.

What is the maximum number of these gateway modules that can be installed in a single 3500 rack?

To prevent a single point of failure in the communication link, up to two 3500/92 modules can be installed in a single 3500 rack to achieve completely independent communication channel redundancy.

What standard industrial communication protocols are officially supported by 3500/92 136180-01?

It natively supports Modbus RTU (serial link) and Modbus/TCP (industrial Ethernet protocol), as well as Bently Nevada's proprietary primary host communication protocol.

What are the physical dimensions and slot requirements for 3500/92 136180-01?

It is a Full-Height Module and must be installed in a standard main slot on the front of the 3500 rack, typically located next to the rack control module in the dedicated communication slots.

3500/92 136180-01

Name: 3500/92 136180-01
Brand: Bently Nevada
SKU: 3500/92 136180-01

Communication Gateway Module

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe：

Communication Gateway Module
Full-Height Module
Modbus RTU
ProtocolHot-Swappable
4 Analog Input
ChannelsDCS/PLC/SCADA Integration

Ask our team:

Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com

Dispatch Planning
Confirm stock and lead time with our team.

Dedicated Manager
Personalized one-to-one VIP service

ISO 9001:2015 Certified
Trusted quality management

Get a quick price for 3500/92 136180-01

E-mail *

Mobile *

Company

Content *

Quantity *

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

1

Requirement review

We review the part number, quantity and delivery requirements and ask for any missing details.
2

Quotation and availability

We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
3

Order confirmation and dispatch

Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 3500/92 136180-01

Manufacturer:

Bently Nevada
Product Category:

Machinery Monitoring Systems
Spare Part Number:

3500/92 136180-01
Estimated shipping dimensions:

2.5x25x24cm
Weight:

0.82 kg
Tariff Code:

8537101190
Counliy of origin:

USA
Communication Link:

Ethernet, 10Mbps, and conforms to IEEE802.3
Power Consumption:

5.0 W to 5.6 W typical
Protocol:

Ethernet TCP/IP frame and Modbus/TCP
Operating Temperature:

-30°C to +65°C
Humidity:

95%, non-condensing
Storage Temperature:

-40°C to +85°C
I/O Module Operating Temperature:

0°C to +65°C

Ask for Quote

Information

Overview Manuals Common Applications Product Precautions

The 3500/92 136180-01 is a communication gateway module manufactured by Bentley Nevada, USA, and is part of the 3500 large machinery monitoring system. It is primarily used to transmit 3500 frame data to upper-level systems such as DCS or PLC.

Modbus RTU Protocol
Modbus/TCP protocol
Proprietary Bently Nevada protocol

The Bently Nevada 3500/92 Communication Gateway module provides extensive communication capabilities of all rack monitored values and statuses for integration with process control and other automation systems using both Ethernet TCP/IP and serial (RS232/RS422/RS485) communications capabilities. It also permits Ethernet communications with 3500 Rack Configuration Software and Data Acquisition Software.The 3500/92 supports the communication interfaces, communication protocols, and other features from the original 3500/90 with the exception of the primary value Modbus registers. The 3500/92 now has a Configurable Modbus Register Utility, which can provide the same functionality originally addressed by the primary value Modbus registers.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.

Bently Nevada 3500/92 136180-01 Communication Gateway Module Manuals, Datasheets, Drivers, Link

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.

Thermal Power

Maps steam turbine bearing vibrations and generator shaft runout variables into Modbus/TCP registers, allowing the power plant's SCADA system to trending critical startup dynamics.

Petrochemical & Oil

Streams critical vibration, axial displacement, and alarm statuses from large centrifugal compressor trains directly to the refinery's main Distributed Control System (DCS) for centralized asset monitoring.

Liquefied Natural Gas

Integrates high-speed mixed refrigerant (MR) compressor monitoring data with emergency shutdown (ESD) systems, providing high-speed telemetry updates under 1 second.

Nuclear Power

Routes secondary-side telemetry from reactor feed pumps and primary coolant pump diagnostics to independent safety-monitoring networks without disrupting local hardware protection loops.

Pulp & Paper

Monitors high-speed paper machine drying cylinders and vacuum pump lines, streaming event logs and alert changes to local operator workstations.

When using the 3500/92 (136180-01) gateway module, keep these key points in mind. ESD Protection & Smooth Alignment—always wear an anti-static wrist strap before handling, and insert or remove the module vertically and steadily to prevent bending the backplane pins. Interface Port Safeguarding—ensure proper physical surge isolation when wiring RS485 or Ethernet serial buses, and never allow high voltage to enter communication ports. Align Software Address Mapping—after a module swap, download the setup via the 3500 Configuration Software, and verify that the custom internal Modbus registers match your DCS/PLC database perfectly to avoid telemetry mismatch.
