      330196-05-30-10-CN

      Extended-Temperature Reverse-Mount Probe
      In Stock
      Ships by Saturday, November 7
      Fast Shipping Available
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      Product Describe：

      An ETR reverse-mount probe using M10 x 1 threads, 1.0 m PFA cable and FluidLoc connection for a matched 3300 XL 8 mm channel.

      Ask our team:

      Phone: +86 180 3023 5313 E-Mail: sales13@apterpower.com
      Dispatch Planning
      Confirm stock and lead time with our team.
      Dedicated Manager
      Personalized one-to-one VIP service
      ISO 9001:2015 Certified
      Trusted quality management
      Get a quick price for 330196-05-30-10-CN
      E-mail *
      Mobile *
      Company
      Content *
      Quantity *
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy

      What happens after you enquire

      • 1

        Requirement review

        We review the part number, quantity and delivery requirements and ask for any missing details.
      • 2

        Quotation and availability

        We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
      • 3

        Order confirmation and dispatch

        Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

      Technical specifications for 330196-05-30-10-CN

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring Systems
      • Spare Part Number:
        330196-05-30-10-CN
      • Estimated shipping dimensions:
        1.1x1x111cm
      • Weight:
        0.06 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Base series:
        330196
      • Mounting:
        Reverse mount
      • Probe case thread:
        M10 x 1
      • Total cable length:
        1.0 m
      • Cable:
        75 ohm triaxial PFA
      • Connector:
        FluidLoc
      • Approval / country option:
        CN country option
      • Probe-tip temperature:
        -52 to +218 deg C
      • Cable and connector temperature:
        -51 to +260 deg C
      • Linear range:
        2.0 mm (80 mils)
      • Recommended gap:
        About 1.27 mm at -9 Vdc
      • Scale factor:
        7.87 V/mm (200 mV/mil)
      • Frequency response:
        0 to 10 kHz
      • Probe tip:
        Polyphenylene sulfide (PPS)
      • Probe case:
        AISI 303 or 304 stainless steel
      • Minimum bend radius:
        25.4 mm
      View as PDF Ask for Quote

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330196-05-30-10-CN is an extended-temperature reverse-mount 3300 XL 8 mm probe with M10 x 1 threads, 1.0 m total length and the cn country option ordering selection.
      • ETR reverse-mount body
      • M10 x 1 mounting thread
      • 1.0 m total length
      • FluidLoc connector

      The ETR probe preserves the electrical behavior of a matched 3300 XL 8 mm measurement chain while extending the documented temperature capability of the sensing end and cable assembly.

      Important Notice: Keep the complete 330196-05-30-10-CN suffix with its temperature, cable, connector and approval records. Do not use standard-probe limits for this ETR execution.

      Bently Nevada 330196-05-30-10-CN Manuals & Downloads
      Bently Nevada 330196-05-30-10-CN Manufacturer Datasheet Excerpt (PDF)Bently Nevada 330196-05-30-10-CN Installation & Commissioning Guide (PDF)

      The technical reference organizes exact characteristics and engineering boundaries. The installation guide focuses on controlled preparation, restoration, commissioning and handover.

      High-temperature bearing measurement
      Extends the probe-tip temperature capability within the published ETR limits.
      Reverse-mount installations
      Uses the documented M10 x 1 reverse-mount body.
      Fluid-exposed connector service
      Uses the FluidLoc connector execution documented for the ETR family.
      Exact ETR renewal
      Restores 330196-05-30-10-CN without substituting a standard-temperature probe.
      Bently Nevada 330196-05-30-10-CN installation checks: retain the exact identity, installed configuration and witnessed acceptance record throughout the work.
      1
      Confirm the complete 330196-05-30-10-CN label and reverse-mount orientation.
      2
      Verify the M10 x 1 mounting thread and the 1.0 m total cable length.
      3
      Record the existing gap voltage, target material and monitor configuration.
      4
      Protect the PFA cable and maintain the 25.4 mm minimum bend radius.
      5
      Keep the FluidLoc mating surfaces clean and join the connector finger tight.
      6
      Apply the ETR temperature limits separately to probe tip, cable and connector.
      7
      Restore the documented gap and prove static and dynamic response before release.
      8
      Confirm the cn country option marking from the exact ordered identifier.

      Technical notes

      For 330196-05-30-10-CN, retain the exact ordered suffix, installed measurement-chain record and witnessed acceptance result. Return the equipment to service only after model-specific electrical and mechanical checks pass.

      FAQ View All FAQ

      • What mounting style does 330196-05-30-10-CN use?
        It is an extended-temperature reverse-mount probe.
      • Which thread applies to 330196-05-30-10-CN?
        The exact base series selects M10 x 1.
      • What total length is ordered for 330196-05-30-10-CN?
        The suffix selects 1.0 m.
      • Which connector is used?
        The ETR ordering table specifies a FluidLoc connector.
      • What cable construction is documented?
        The ETR probe uses 75 ohm triaxial PFA cable.
      • What probe-tip temperature limit applies?
        The published probe-tip range is -52 to +218 deg C.
      • What approval option applies?
        The exact suffix selects cn country option.
      • How is 330196-05-30-10-CN accepted?
        Verify identity, temperature boundary, gap, calibration and monitor response.
