      Bently Nevada 330103-00-11-10-02-00
      Bently Nevada 330103-00-11-10-02-00
      Bently Nevada 330103-00-11-10-02-00
      Bently Nevada 330103-00-11-10-02-00
      Bently Nevada 330103-00-11-10-02-00
      Bently Nevada 330103-00-11-10-02-00
      Product image is representative; revision or series may vary. Contact us to request a specific version.

      330103-00-11-10-02-00

      8 mm Probe
      In Stock
      Ships by Wednesday, October 14
      Fast Shipping Available

      Product Describe：

      Bently Nevada 330103-00-11-10-02-00 is an unarmored 3300 XL 8 mm proximity probe with an M10 x 1 threaded case and a 1.0 m total length. Its 02 connector option is a miniature coaxial ClickLoc connector on standard cable; verify the matching transducer-system length before installation.

      Ask our team:

      Get a quick price for： 330103-00-11-10-02-00
      Quantity*
      Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Apterpower please read our privacy policy.
      Technical specifications Information Technical notes FAQ

      Technical specifications for 330103-00-11-10-02-00

      Technical specifications for 330103-00-11-10-02-00

      • Manufacturer:
        Bently Nevada
      • Product Category:
        Machinery Monitoring System
      • Spare Part Number:
        330103-00-11-10-02-00
      • Estimated shipping dimensions:
        2.2x12.4x12.6cm
      • Weight:
        0.1 kg
      • Tariff Code:
        8537101190
      • Counliy of origin:
        USA
      • Product family:
        3300 XL 8 mm proximity transducer
      • Probe model:
        330103, M10 x 1 thread, without armor
      • Unthreaded length:
        0 mm (code 00)
      • Overall case length:
        110 mm (code 11)
      • Total length:
        1.0 m (code 10)
      • Connector and cable:
        ClickLoc coaxial connector, standard cable (code 02)
      • Agency approval option:
        00 — no approval option requested
      View as PDF Ask for Quote

      Information

      Information

      Overview Manuals Common Applications Product Precautions
      Bently Nevada 330103-00-11-10-02-00 is an unarmored metric 3300 XL 8 mm probe for a matched one-meter proximity-transducer chain.
      • 330103: M10 x 1 metric probe body without armor
      • AA 00: 0 mm unthreaded length; BB 11: 110 mm overall case
      • CC 10: 1.0 m total probe length for its matching system
      • DD 02: standard-cable miniature ClickLoc connector

      The full article code distinguishes this probe from armored, FluidLoc and alternate-length variants. Use the specified extension cable and Proximitor Sensor configuration when interpreting the installed channel response.

      Important Notice: EE 00 selects no additional agency-approval option; verify site requirements independently.

      Bently Nevada 330103-00-11-10-02-00 Manuals & Downloads
      Bently Nevada 330103-00-11-10-02-00 Technical Reference (PDF)Bently Nevada 330103-00-11-10-02-00 Installation & Commissioning Guide (PDF)

      The first PDF maps this metric probe’s complete order code and matched-system boundary; the second provides its separate isolation, installation and controlled-acceptance checks.

      Relative shaft vibrationA matched 3300 XL 8 mm chain can track shaft movement at an approved fluid-film-bearing position.
      Axial shaft positionStable probe gap supports position observation when the machine layout and monitoring channel are configured for it.
      Keyphasor referenceThe selected shaft feature and channel can provide a once-per-revolution reference for phase measurements.
      Rotational-speed inputA suitable target and channel configuration can use the probe signal for machine-speed observation.
      Read the applicable Bently Nevada 3300 XL 8 mm instructions before work. Verify the complete 330103-00-11-10-02-00 marking and its installed host.
      1
      Confirm the M10 x 1 unarmored 330103 body and all five option fields against the maintenance record.
      2
      Place the machine and monitoring channel in the approved maintenance state before removing the probe.
      3
      Record probe position, target gap, installed extension path and channel configuration as found.
      4
      Verify the case and unthreaded-tip options against the host drawing; do not substitute an armored body by appearance.
      5
      Protect the unarmored standard cable and inspect the miniature ClickLoc mating connection.
      6
      Match the total probe and extension-cable length to the corresponding Proximitor Sensor setup.
      7
      Confirm target material and calibration basis before interpreting gap or vibration output.
      8
      After controlled restoration, check diagnostics and document the intended channel response before release.

      Technical notes

      Technical notes

      Match the 1.0 m 330103-00-11-10-02-00 probe with the corresponding 3300 XL extension cable and Proximitor Sensor total-length configuration. Confirm the installed thread, connector, cable routing and system calibration before release.

      FAQS

      • What thread does 330103-00-11-10-02-00 use?
        It has the 330103 metric probe body with an M10 x 1 thread.
      • Does 330103-00-11-10-02-00 have armored cable?
        No. The 330103 probe body is the unarmored version in the 3300 XL 8 mm family.
      • How long is the unthreaded tip on 330103-00-11-10-02-00?
        Code 00 specifies a 0 mm unthreaded length.
      • What is the case length of 330103-00-11-10-02-00?
        Code 11 specifies a 110 mm overall case length.
      • What total probe length is specified for 330103-00-11-10-02-00?
        Code 10 specifies 1.0 m. Use a matching 3300 XL extension cable and Proximitor Sensor configuration.
      • Which connector is fitted to 330103-00-11-10-02-00?
        Code 02 denotes a miniature coaxial ClickLoc connector on standard cable, without the 01 connector-protector option.
      • What does the final 00 mean on 330103-00-11-10-02-00?
        It is the agency-approval order option listed as “not required”; do not infer a site certification from this code alone.
