1503VC-BMC5-MC1

IntelliVAC Contactor Control Module
Allen-Bradley 1503VC-BMC5-MC1
Allen-Bradley 1503VC-BMC5-MC1
Allen-Bradley 1503VC-BMC5-MC1
Allen-Bradley 1503VC-BMC5-MC1
Allen-Bradley 1503VC-BMC5-MC1
Allen-Bradley 1503VC-BMC5-MC1
Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Describe:

IntelliVAC Contactor Control Module
Bulletin 1503 / IntelliVAC
Multi-Contactor Control
IP00 UL, CSA, CE
Get a quick price for 1503VC-BMC5-MC1
E-mail *
Mobile
Company
Content *
Quantity *
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
For more information on how your data is processed and stored by Apterpower please read our privacy policy

What happens after you enquire

  • 1

    Requirement review

    We review the part number, quantity and delivery requirements and ask for any missing details.
  • 2

    Quotation and availability

    We confirm the proposed item, condition, availability, price and estimated lead time in the quotation.
  • 3

    Order confirmation and dispatch

    Once the quotation and purchasing details are agreed, your contact will coordinate the order and available dispatch information.

Technical specifications for 1503VC-BMC5-MC1

  • Manufacturer:
    Allen-Bradley
  • Product Category:
    PLC Systems
  • Spare Part Number:
    1503VC-BMC5-MC1
  • Estimated shipping dimensions:
    6x17x18.8cm
  • Weight:
    1.2 kg
  • Tariff Code:
    8537101190
  • Counliy of origin:
    USA
  • Voltage Range:
    93.5...264V AC
  • Control Input Voltage:
    110...240V AC (Nominal)
  • Operating Frequency:
    50/60 Hz
  • Response Time:
    < 100 ms (Typical)
  • Ride-Through Time:
    Up to 20 cycles
  • Operating Temperature:
    0°C to 50°C (32°F to 122°F)

Information

Overview Manuals Common Applications Product Precautions
The 1503VC-BMC5-MC1 is an IntelliVAC Intelligent Medium Voltage Contactor Control Module manufactured by Allen-Bradley (Rockwell Automation). Primarily integrated within CENTERLINE 1500 Motor Control Centers (MCC), it utilizes core technologies such as "Intelligent Coil Management" and "Voltage Ride-through" to effectively reduce power consumption and thermal loss while ensuring continuous operation during power fluctuations.
    • Automatically optimize coil current
    • Undervoltage ride-through capability
    • Control multiple contactors with a single module
An IntelliVAC control module can be used to control Bulletin 1502 450 and 800 A medium voltage vacuum contactors. Both electrically held and mechanically latched contactor types can be controlled with IntelliVAC control modules.The Allen-Bradley Bulletin 1503VC IntelliVAC controller (1503VC-BMC5) offers a superior, efficient, and flexible means of controlling Bulletin 1502 vacuum contactors. The IntelliVAC controller offers a scalable solution for multiple medium voltage control applications. A wire harness for 1502 vacuum contactors is generally required.IntelliVAC provides basic control capabilities for 450 A and 800 A contactors (electrically held and mechanical latch) using a single device. It offers enhanced reliability through better diagnostics and coordination between the power fuses and the vacuum contactor drop-out time. Productivity is improved using the power loss ride through (TDUV) and contactor re-closing control features.

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
 Allen-Bradley 1503VC-BMC5-MC1 IntelliVAC Contactor Control Module Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
Oil & Gas
Controlling large MV motors for crude oil transport pumps and LNG compressors.

Pulp & Paper
Driving heavy motors for pulpers and paper machines, ensuring production line continuity.

Steel & Metallurgy
Controlling blast furnace blowers and cooling circulation pumps to ensure reliable motor operation in high-temperature environments.

Marine & Offshore
Controlling ship bow thrusters and dynamic positioning systems for offshore platforms.

Automotive Manufacturing
Driving large wind tunnel testing equipment and MV exhaust systems in paint shops.

Semiconductor
Controlling motors in ultrapure water treatment systems, using its ride-through capability to prevent outages.

 When using the 1503VC-BMC5-MC1, it is critical to ensure the stability of the control power supply (110-240V AC) and the correct configuration of DIP switches for altitude compensation and undervoltage trip delays. Additionally, the use of a dedicated Bulletin 1502 wire harness is mandatory, and the coil health should be monitored regularly via the LED diagnostic indicators. Never perform wiring while the unit is energized to prevent damage to the sensitive intelligent control circuitry.

FAQ View All FAQ

  • What is 1503VC-BMC5-MC1?
    It is an IntelliVAC Contactor Control Module manufactured by Allen-Bradley (Rockwell Automation).
  • Which series does 1503VC-BMC5-MC1 belong to?
    It belongs to the Bulletin 1503 series and is a core component within the CENTERLINE 1500 Medium Voltage Motor Control Centers (MCC).
  • What is the primary function of 1503VC-BMC5-MC1?
    Its main role is to control the closing and holding of vacuum contactors while providing undervoltage protection, status monitoring, and fault diagnostics.
  • How do you use 1503VC-BMC5-MC1?
    It is mounted in the low-voltage wireway of a control cabinet. You connect the control power (110-240V AC) and the contactor coils to its terminals, then trigger it via start/stop input signals.
  • How does 1503VC-BMC5-MC1 differ from a standard relay?
    It features intelligent control technology that optimizes energy for the coils to reduce heat and includes LED indicators to display specific fault codes, which a standard relay cannot do.
